  • Page 1 LaFaro DELUXE Double Bass ampli er...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT ENCLOSURE THAT MAY BE OF A SUFFICIENT MAGNITUDE TO CONSI- THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE INSTRUCTIONS IN TO REDUCE THE RISK OF FIRE OR WARNING...
  • Page 3 INTRODUCTION Double bass ampli cation gave the start to the Schertler company in the year 1986, coming out with the rst non-piezo bass-pickup. Over the years, many products has been added to the line, received by the double bassist community as helpers, that changed the playing of this di cult to amplify instrument.
  • Page 4 1. MIC-IN 1.3. 1.7. 1.6. 1.5. 1.1. 1.8. 1.4. 1.2. 1.1. MIC-IN This microphone input is electronically balanced for XLR type connections. It has been optimized for connecting microphones or other transducers having low impedance and low level. The input is perfect for dynamic or condenser vocal microphones.
  • Page 5 2.7. WARM When engaged, this low-pass lter damps higher frequencies to produce a warmer sound when using bridge-mounted pickups such as Schertler STAT-series transducers for violin, cello and double bass.

  • Page 6: Master Section

    4. MASTER SECTION 4.7. 4.6. 4.4. 4.5. 4.2. 4.1. 4.8. 4.3. 4.1. DI-OUT General output. XLR balanced type connector for connections of external systems. The output volume does not depend on the regulation of the MASTER-VOL but is e ected by changes in individual channel volume.

  • Page 7: Rear Panel

    5. REAR PANEL 5.2. 5.4. 5.3. 5.1. 5.1. NET SWITCH This switch changes the main power voltage from 230V~ to 120V~ 5.2. GROUND LIFT This switch connects and disconnects the ground between source and amplifier. Use this switch to suppress hum caused by the power mains.
  • Page 8 WARNINGS PRECAUTIONS Read carefully this manual and WARNING follow these precautions before Keep this manual for possible future needs Pay attention not to pour liquids onto the device and do not operate in conditions of excessive humidity Do not install the device close to sources of excessive heat, do not expose it to direct solar radiation and do not position it without protection in a dusty environment Be sure that the mains voltage does not exceed the value indicated on the back panel Do not use the device if the mains cable or the plug aren’t in a perfect condition (if necessary, replace...

  • Page 9: Technical Description

    Impedance: 4.7kohm / 820kohm ALL SCHERTLER® PRODUCTS ARE COVERED BY A LIMITED TWO-YEAR WARRANTY (FROM THE DATE OF PURCHASE) AGAINST MANUFACTURES DEFECTS. DETAILS CAN BE OBTAINED FROM YOUR LOCAL DEALER/REPRESENTATIVE. SCHERT- LER SA STRONGLY BELIEVES IN “COMMON SENSE” AND THUS, MISUSE OF OUR PRODUCTS ARE NOT COVERED UNDER RIGHTS OBTAINED THROUGH OUR WARRANTY POLICY OR THAT OF INTERNATIONALLY RECOGNIZED TERMS AND CONDITIONS.
