Summary of Contents for Schertler ROY
- Page 1 combo amplifier for acoustic instruments...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED “DANGEROUS VOLTAGE” WITHIN THE PRODUCT ENCLOSURE THAT MAY BE OF A SUFFICIENT MAGNITUDE TO CONSITUTE A RISK OF ELECTRIC SHOCK TO PERSONS. - Page 3 PRECAUTIONS WARNINGS Please read this manual carefully before using your ROY amplifier and observe all safety precautions Keep this manual for future reference Do not pour any liquids onto this device, or operate it in excessively humid conditions. Do not use or install this device near sources of excessive heat. Do not expose it to direct sunlight, or position it in a dusty environment without any form of protection.
-
Page 4: Practical Advice
Equipped with a 1” horn, two 8” subwoofers and featuring the same hi- end Class A preamp found in other Schertler amplifiers, ROY delivers the rich, high-quality sound that has become synonymous with this product family, while providing the user with even greater flexibility. - Page 5 1. FRONT PANEL - MIC IN (1, 2) MULTIEFFECT ENCODER Delay + Rev Chorus slow Chorus medium Delay 100ms CLASS-A high voltage preamp, no integrated circuits, no NFB Delay 200ms Chorus fast ¿ Delay 300ms Chorus + Rev WARM GAIN HIGH MULTIEFFECT REV (AUX)
- Page 6 2. FRONT PANEL - MIC or INSTRUMENT IN (3, 4) MULTIEFFECT ENCODER Delay + Rev Chorus slow Chorus medium Delay 100ms CLASS-A high voltage preamp, no integrated circuits, no NFB Delay 200ms Chorus fast ¿ Delay 300ms Chorus + Rev WARM GAIN HIGH...
- Page 7 3.6. WARM When engaged, this low-pass filter damps higher frequencies to produce a warmer sound when using bridge-mounted pickups such as the SCHERTLER STAT-Series for violin, viola, cello and double bass 3.7. HIGH, MID, LOW These controls are devoted to high, medium and low frequency regulation. Offering cut and boost of ±15dB, they allow a wide range of tonal variations to be explored.
- Page 8 4. FRONT PANEL - STEREO IN (6, 7) / MASTER MULTIEFFECT 5.15 ENCODER Delay + Rev Chorus slow 5.17 5.16 Chorus medium Delay 100ms CLASS-A high voltage preamp, no integrated circuits, no NFB Delay 200ms Chorus fast ¿ Delay 300ms Chorus + Rev WARM GAIN...
- Page 9 4. FRONT PANEL - STEREO IN (6, 7) / MASTER 5.8. AUX OUT vol. This rotary control sets the output level on the AUX OUT 5.9 PHONES Phones output. This mono jack plug enables the connection to headphones 5.10. PHONES vol. This rotary control sets the output level on the PHONES output 5.11.
-
Page 10: Rear Panel
5. REAR PANEL 6.1. POWER ON/OFF System ON/OFF switch. 6.2. GROUND LIFT This switch connects and disconnects the ground 6.3. MAIN POWER CONNECTION Connection to mains Fuse carrier 220 - 230 V 50 Hz / 60 Hz T 3.15 A L 250 V 240 V~ 50 Hz T 3.15 A L 250 V... -
Page 11: Technical Specs
TECHNICAL SPECS Frequency response ..........40 Hz - 20 kHz Sensitivity (1W-1m) ............ 95 dB SPL max ..............121 dB Woofer ............... 2x8” Horn ................1” Crossover ..............Active 24 dB / octave Box ................Bass reflex Construction ............... Birch laminated System –... -
Page 12: Signal Flow
“COMMON SENSE” AND THUS, MISUSE OF OUR PRODUCTS ARE NOT COVERED UNDER RIGHTS OBTAINED THROUGH OUR WARRANTY POLICY OR THAT OF INTERNATIONALLY RECOGNIZED TERMS AND CONDITIONS. SCHERTLER SA IS CONSTANTLY AIMING TO IMPROVE ITS RANGE OF PRODUCTS THEREFORE, SCHERTLER SA RESERVES THE RIGHT TO AMEND PRODUCT SPECIFICATIONS WITHOUT NOTICE.
