Summary of Contents for Yealink SIP-T46U

  • Page 1: Table Of Contents

    Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Video Tutorial 3 Requirements 3.1 Identifying Phone Model 3.2 Phone Firmware 3.3 DHCP Server 3.4 PBXware Version 4 Installation 4.1 Power Adapter 4.2 Power over Ethernet (PoE) 4.3 Find the phone IP address 4.4 Reset to Factory Settings...

  • Page 2: Video Tutorial

    This Configuration Guide is written as a general guide on how to configure the Yealink phone model SIP-T46U to work with PBXware 5.3.6. Video Tutorial Please refer to the video tutorial explaining the Auto Provisioning setup for the Yealink Phone on PBXware 5.

  • Page 3: Dhcp Server

    To find out the firmware version of your Yealink phone model, open a new browser window and enter your phone IP address in order to access the phone's web administration interface login screen. Example: http://192.168.1.22. Log in to the phone's web administration interface with your username and password. Please note that the factory default login details are as follows: username is admin and password is admin.

  • Page 4: Find The Phone Ip Address

    Do not unplug or remove power from the phone while it is updating firmware and configuration.. Registering Phone This section describes how to identify the Yealink phone model, requirements that must be met, and how to register a phone using Manual configuration or Auto provisioning. The following topics are covered:...

  • Page 5: Manual Configuration

    UAD Settings Navigate to Settings: UAD. Make sure that the Yealink UAD is enabled. To check the UAD status, click the Edit icon corresponding to your Yealink phone. Make sure that Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
  • Page 6 Define the Department to which the Extension belongs to. Example: Sales. Click the Save button. Registering Phone This section describes how to register the Yealink phone using Hostname or IP Address, or DNS SRV. The following topics are covered: Hostname or IP Address...
  • Page 7 REQUIRED FIELDS: Account Active Make sure that the On radio box is selected. Register Name Enter the PBXware Extension number. Example: 1003 User Name Usually refers to the same number as the Phone Number. Password The Secret of the Extension as received in the e-mail associated with this Extension. Example: _%Z4M3*Ts9y7.

  • Page 8: Auto Provisioning

    Click Account. Enter or set the following details into the respective fields. REQUIRED FIELDS: Account Active Make sure that the On radio box is selected. Register Name Enter the PBXware Extension number. Example: 1003 User Name Usually refers to the same number as the Phone Number. Password The Secret of the Extension as received in the e-mail associated with this Extension.
  • Page 9 UAD Settings Navigate to Settings: UAD. Make sure that the Yealink UAD is enabled. To check the UAD status, click the Edit icon corresponding to your Yealink phone. Make sure that Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
  • Page 10 Enter Yealink phone MAC address. Example: 001565FF1536. MAC address can be found at the back of the phone. Click on the Save button. Registering Phone This section describes how to register Yealink phone using DHCP, TFTP, HTTP & HTTPS, or DNS SRV. The following topics are covered: DHCP TFTP or HTTP &...
  • Page 11 Phone's first boot or user initiated reboot The Auto provisioning process will start during the phone's first boot or after the reboot process has been initiated by the user. The DHCP server will instruct the phone from where to pick up an appropriate configuration file. If everything is done as described above, you should have successfully registered your phone to PBXware.

  • Page 12: Using Tls

    Example of an IP Address using HTTPS: https://192.168.1.10/prov Enter the Auto Provisioning username and password into the User Name and Password fields. If you choose to use TFTP server type, enter tftp:// followed by Hostname or IP Address Example of a Hostname: tftp://voip.bicomsystems.com Example of an IP Address: tftp://192.168.1.10 Click the Autoprovision Now button.

  • Page 13: Dns Srv

    Log in to the phone's web administration interface If there is no DHCP in your network, you can still auto provision your Yealink phone. Please refer to your Yealink phone model User Guide for instructions about setting the static IP address.

  • Page 14: Configure Blf

    PBXware. Dial *123 to verify registration. Configure BLF This section describes how to configure BLF (Busy Lamp Field) for Yealink T46U. The following topics are covered: - Extension Settings - Phone Settings...

  • Page 15: Phone Settings

    Click the Confirm button to save changes. Additional Configuration Template If you want to include some additional UAD configuration for Yealink T46U, just add fields to User Agent General Auto Provisioning Template in the Settings -> UAD -> Yealink T46U menu, or add them directly to the Extension in the UAD Auto Provisioning Template section.
