Handlebar Set Up - ISLABIKES Beinn Owner's Manual

Step 3 of 6
Re-connecting front brake
1. Re-connect front brake by hooking the silver metal cable hose
(noodle) back into the hinge. Check this matches the rear.
2. Pull the right brake lever on to check brake works correctly.
Both brake blocks should contact the rim.
Check front brake operates correctly before allowing child to ride.
If unsure contact our technical support team
on +44 (0)800 008 6297 or email techsupport@islabikes.co.uk.
Beinn 20 Small / Beinn 20 Large / Beinn 24 / Beinn 26 / Beinn 27
Step 4 of 6

Handlebar set up

(Only required if mudguards are fitted)
1. Turn
1. Turn handlebars clockwise and align with front wheel
2. Tighten stem clamp bolt max. 7Nm
Failure to correctly tighten stem clamp bolt may result in serious
injury or death. If in doubt, please consult our technical support
team on +44 (0)800 008 6297 or email techsupport@islabikes.co.uk..
Do Not
Tighten
2. Tighten
