Overview; Specifications; Optional Accessories - Altronix Trove1M1R Installation Manual

Altronix Trove1M1R rack mount access & power integration solution accommodates various combinations of Mercury boards with or
without Altronix power supplies and accessories for access systems.
Agency Listings:
• CE European Conformity.
Trove1M1R
Trove1R rack mount enclosure with
TM1R Altronix/Mercury backplane.
• 16 Gauge black enclosure with ample knockouts for
convenient access.
• Modular 2U standard EIA 19" drawer with
extendable slides up to 48".
• Dimensions (H x W x D): 3.25" x 19.0" x 26.5"
(82.6mm x 482.6mm x 673.1mm).
• Includes tamper switch (Altronix Model TS112 or equivalent)
and cam lock.
Backplane Accommodates a Combination of the Following:
Altronix:
• One (1) eFlow4NB, eFlow6NB, eFlow102NB, eFlow104NB,
ACMS8(CB) or ACM8(CB).
• Up to two (2) ACM4(CB), MOM5, PD4UL(CB), PD8UL(CB),
PDS8(CB), or VR6.
Spacer | 5/16" Pan Head Screw |
- 2 -

Overview:

Specifications:

TM1R
Altronix/Mercury backplane.
• 16 Gauge backplane.
• Dimensions (H x W x D): 18.5" x 15.25" x 0.3125"
(469.9mm x 387.4mm x 7.9mm).

Optional Accessories:

RE2: Rack Mount Battery Enclosure accommodates up to four (4)
•
12VDC/7AH batteries
WM5, WM25, WM100: Magnetic Cable Tie Mounts
•
(5, 25, 100 counts).
LC3: 6 ft. three-wire line cord.
•
Mercury:
• Up to four (4) EP1502, MR52, MR16IN or MR16OUT.
• Up to two (2) EP2500 or MUX8.
• Up to two (2) EP1501 or MR51e.
• Up to two (2) MR50.
Hardware and Accessories:
Lock Nut
Trove1M1R
