NOTE: • Adjustment of the volume control as well as the equalizer to other settings than the center position may
increase the ear-/headphones output voltage and therefore the sound pressure level.
•

Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor lowers the sound.
•

Incorrect cable connections may result in irregular operation, damage display quality/components of the LCD
module and/or shorten the module's life.
4. Attach the cable holder.
Insert the tabs of the cable holder into the holes of monitor stand and slide the cable holder downward into place (Figure 3).

NOTE: •
Please confirm that the tabs are completely secured.
•

To prevent damage to the cables, cable cover, and monitor, spread the cables under the cable holder so that
the cables rest side-by-side.
5. Connect the power cord to a power outlet.


NOTE: • Please refer to the Caution section of this manual for proper selection of the AC power cord (see
•

Please make sure that enough power is supplied to the monitor. Please refer to
"Chapter 4 Specifications" on page
6. Turn on the monitor by pressing the
7. When using the analog (VNA) input, No Touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial
setup. For further adjustments, use the following OSD controls:
• AUTO CONTRAST
• AUTO ADJUST
Refer to the "Basic Operation"
NOTE:

If you have any problems, please refer to the

Adjustable Monitor Stand Capability

Hold the monitor on each side and lift or lower to the desired height, and adjust the tilt as desired.
Stand
Base
Figure 3
22.
button and then turn on the computer.
section of this User's Manual for a full description of these OSD controls.
"Troubleshooting"
English−14
Cable holder
section of this User's Manual.
page 6).
"Power Supply" in the
