Connections
Video Input Connections
•
VNA (mini D-Sub 15-pin) – Analog video signal connection to a computer. Video only, no audio signal.
•
HDMI – High definition digital video and audio signal connection to a computer, streaming media player, Blu-ray player, game
console, etc.
•
DisplayPort – High definition digital video and audio signal connection to a computer.
Connecting Video
The type of video connections that can be used to connect to a computer depends on the computer's display adapter.
The following table shows the typical factory preset signal timing for each connection type. Some display cards may not be able
to support the required resolution for proper image reproduction with the selected connection. The monitor will show the proper
image by automatically adjusting the factory preset timing signal.
<Major supported timings>
Resolution
Vertical Frequency
H
V
640
x
480
60/72/75 Hz
720
x
400
70 Hz
720
x
480
60 Hz
720
x
576
50 Hz
800
x
600
56/60/72/75 Hz
1024
x
768
60/70/75 Hz
1280
x
960
60/75 Hz
1280
x
1024 60/75 Hz
p: Progressive.
NOTE:
When the selected monitor resolution is not a native panel resolution, the text contents appearance in the monitor
screen is expanded in a horizontal or vertical direction to show the non-native resolution to full screen. This expansion is
done by interpolated resolution technologies, which are normal and widely used in flat panel devices.
Connecting to a Computer with HDMI
•
Please use an HDMI cable with the HDMI logo.
•
It may take a moment for the signal to appear after turning on the computer.
•
Some display cards or drivers may not display an image correctly.
•
If the monitor's power is turned on after a connected computer is turned on, sometimes an image is not displayed. In this
case, please turn off the computer then turn it on again.
Connecting to a Computer with DisplayPort
•
Please use a DisplayPort cable with the DisplayPort compliance logo.
•
It may take a moment for the signal to appear after turning on the computer.
•
When connecting a DisplayPort cable to a component with a signal conversion adapter, an image may not appear.
•
Some DisplayPort cables feature a locking function. When removing this cable, hold down the top button to release the lock.
•
If the monitor's power is turned on after a connected computer is turned on, sometimes an image is not displayed. In this
case, please turn off the computer then turn it on again.
Scan Type
Notes
p
p
p
p
p
SVNA
p
XNA
p
p
SXNA,、Recommended (60 Hz)
English−12
