PROGRAMMER'S REFERENCE MANUAL
Label layout definition commands

Bitmap text field (deprecated)

Bitmap text fields are deprecated. This section is kept for backward compatibility reasons.
Use scalable fonts instead.
Syntax
!F T <u> <b> <p> <a> <h> <w> <f> <"text">
Note! Parameters enclosed in <> are required and parameters enclosed in [] are
optional.
The parameters have the following meanings:
<u> Defines the direction of printing as the 'up' direction of the printed characters. One
upper-case character (N, E, S, or W).
<b>
The baseline of the field, in
<p>
The position, in
<a> The alignment relative to the position. One upper-case character.
L = left end of the field aligned at p.
R = right end of the field aligned at p.
C = the field is centered around p.
<h> The height expansion of the characters, 1 – 16.
<w> The width expansion of the characters, 1 – 16.
<f> The logical number of the font to be used for printing, 1 – 7.
<text>
Specifies the text to be printed. The text must be enclosed in double quotes (
Bitmap font name
7x9-dot bold
hv18r
15-dot bold
9-dot
19-dot bold x 18
hc42c
g19 x 12
1
/ mm.
10
1
/ mm
10
Bitmap font number
1
2
3
4
5
6
7
"
).
Page 10
