PROGRAMMER'S REFERENCE MANUAL
Label layout definition commands
21 USS Codabar – 2:1
22 USS Codabar – 3:1
23 USS Codabar – 5:2
24 USS Codabar – 8:3
25 USS Codabar – 13:5
26 USS Codabar – 11:4
27 USS Codabar – 7:3
31 UPC-A
32 EAN 13
33 EAN 8
34 UPC-E
35 EAN/UPC extension
41 Code 128
43 EAN 128
Numeric code, variable length. The start and
stop characters ('A', 'B', 'C' or 'D') must be
included in the input data.
Numeric code. Requires 11 digits of input
data. The printer automatically appends the
check digit.
An EAN/UPC extension field could be
automatically appended by adding 2 or 5
digits to the input data.
Numeric code. Requires 12 digits of input
data. The printer automatically appends the
check digit.
An EAN/UPC extension field could be
automatically appended by adding 2 or 5
digits to the input data.
Numeric code. Requires 7 digits of input
data. The printer automatically appends the
check digit.
Numeric code. Requires 6 digits of input
data. The printer automatically appends the
check digit.
Numeric code. Requires 2 or 5 digits of
input data.
This code could maunally inserted with a
EAN/UPC extension barcode field, or
automatically inserted by adding 2 or 5
digits to a EAN 13 or UPC-A barcode field.
All 128 ASCII characters plus control
characters can be encoded. The control
characters are explained further in - Code
128 function codes -. Variable length.
The same as Code 128, except that the
printer automatically inserts a FNC1 as the
first character. This is unique for the EAN
128 code.
(, ) and space characters are filtered in the
barcode, but printed in the human readable
text.
Page 17
