- Page 1 IPC-L26N WiFi Active Alarm Floodlight Camera Quick Installation Guide V1.0.0 Dahua Technology Co., Ltd...
-
Page 2: Foreword
General This manual offers reference material and general information about the basic operation, maintenance, and troubleshooting for a Dahua Network Camera. Read, follow, and retain the following safety instructions. Heed all warning on the unit and in the operating instructions before operating the unit. - Page 3 Please contact the customer service for the latest program and supplementary documentation. Video loss is inherent to all digital surveillance and recording devices; therefore Dahua cannot be held liable for any damage that results from missing video information. To minimize the occurrence of lost digital information, Dahua recommends multiple, redundant recording systems, and adoption of backup procedure for all data.
- Page 4 Legal Notices Copyright This user guide is ©2019, Dahua Technology Company, LTD. This user guide is the intellectual property of Dahua Technology Company, LTD and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered...
-
Page 5: Important Safeguards And Warnings
Important Safeguards and Warnings This chapter describes the contents covering proper handling of the device, hazard prevention, and prevention of property damage. Read these contents carefully before using the device, comply with them when using, and keep it well for future reference. Installation and Maintenance Professionals Requirements All installation and maintenance professionals must have adequate qualifications or ... - Page 6 have the same characteristics as the original parts. Unauthorized parts may cause fire, electrical shock, or other hazards. Dahua is not liable for any damage or harm caused by unauthorized modifications or repairs. Perform safety checks after completion of service or repairs to the unit.
- Page 7 Use attachments and accessories only specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Dahua, could void the warranty. Internal and external ground connection should be stable. Do not supply power via the Ethernet connection (PoE) when power is already supplied ...
-
Page 8: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity Change Passwords and Use Strong Passwords The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible. - Page 9 Change ONVIF Password Older IP camera firmware does not automatically change the ONVIF password when the system credentials are changed. Update the camera’s firmware to the latest revision or manually change the ONVIF password. Forward Only Ports You Need ...
- Page 10 Connect IP Cameras to the PoE Ports on the Back of an NVR Cameras connected to the PoE ports on the back of an NVR are isolated from the outside world and cannot be accessed directly. Isolate NVR and IP Camera Network ...
-
Page 11: Table Of Contents
Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................IV Cybersecurity Recommendations ......................VII Table of Contents ............................. X 1 Overview ..............................1 Camera Components ........................1 LED Indicators ..........................2 Application Guidelines ........................2 2 Installing the Camera ..........................3 Installation Tips .......................... -
Page 12: Overview
Overview The IPC-L26N WiFi Active Alarm Floodlight camera is a component of the Dahua WiFi camera series. The camera offers Passive IR motion detection and is capable of sounding a siren and turning on a spotlight when an intruder is detected. This device is compatible with Dahua NVRs and with the DMSS mobile application. -
Page 13: Led Indicators
LED Indicators LED Indicator Light Device Status Powered off. Rebooting after reset. Device malfunction. Try resetting the camera (see ‘Camera Steady Red Overview’ for details) and repeating the setup. Network connection failed. Try resetting the camera (see Flashing Red ‘Camera Overview’... -
Page 14: Installing The Camera
Installing the Camera The camera ships with all the components to mount the camera to a wall. Before installing the camera consider the following: Review the “Installation Tips” section to help you choose an ideal mounting location. Decide whether to run the cables through the wall or along the wall. ... -
Page 15: Parts List
Then, remove the existing device, remove any mounting plates, and disconnect the wires. Inspect the junction box to make sure it is watertight. Route the wires through the IPC-L26N mounting plate, then attach the mounting plate to the junction box using the bracket screws. - Page 16 Turn the adjustment knobs for the floodlights to expose the hole for the mounting screw. Attach one end of the hook into the hole on the mounting plate and the other end to the edge of the camera. Ensure the hook is securely attached then release the camera to free both hands.
-
Page 17: Connecting To The Dmss App
Adjust the angles of the floodlights and the camera lens to the desired locations. Ensure the PIR detector is parallel to the ground to ensure optimal detection. Connecting to the DMSS App Install the free mobile app on your smart phone: Apple App Store: iDMSS ... -
Page 18: Troubleshooting
Ensure that you have enabled and configured white The warning light is not switching on automatically light deterrence. The camera siren cannot switch on automatically. You The siren is not switching on can control the camera siren manually using the Dahua automatically DMSS app. -
Page 19: Installation
Installation... - Page 21 Dahua Technology USA 23 Hubble Irvine, CA 92618 Tel: (949) 679-7777 Fax: (949) 679-5760 Support: 877-606-1590 Sales: sales.usa@dahuatech.com Support: support.usa@dahuatech.com © 2019 Dahua Technology USA. All rights reserved. Design and specifications are subject to change without notice.
