- Page 1 IPC Lite Series Hardware Instruction Пример как открыть камеру SNR-CI-DMB3.0I DH-IPC-HFW4300EP-0360B DH-IPC-HFW4300EP-0600B DH-IPC-HFW4421EP-0360B DH-IPC-HFW4421EP-0600B...
- Page 2 HFW1000/1200S Reset: Make short circuit between two small holes on the PCB for 5 seconds. Serial port connection: Please use connector(1.2.17.12.0011) and weld it on the package of the serial port. © 2014 DAHUA TECHHNOLOGY...
- Page 3 HDW1000/1200S Reset: Make short circuit between two small holes on the PCB for 5 seconds. Serial port connection: Please use connector(1.2.17.12.0011) and weld it on the package of the serial port. © 2014 DAHUA TECHHNOLOGY...
- Page 4 HD1000/1200C Reset: Press the reset button for 5 seconds. Serial port Serial port connection: Please use Reset connector(1.2.17.12.0011) and weld it on the package of the serial port. © 2014 DAHUA TECHHNOLOGY...
- Page 5 HDBW1000/1200E Reset: Press the reset button for 5 seconds. Serial port connection: Already have connector, just insert a serial line on it Reset directly. Serial port © 2014 DAHUA TECHHNOLOGY...
- Page 6 HFW2100/2200/2300R-Z/VF Reset: Make short circuit between two Reset small holes on the PCB for 5 seconds. Serial port connection: Please use Serial port connector(1.2.17.12.0011) and weld it on the package of the serial port. © 2014 DAHUA TECHHNOLOGY...
- Page 7 HDBW2100/2200/2300R-Z/VF Reset: Press the reset button for 5 seconds. Serial port connection: Please use connector(1.2.17.12.0011) and weld it Reset on the package of the serial port. Serial port © 2014 DAHUA TECHHNOLOGY...
- Page 8 Pay attention that the two gaps on the lateral of the connector should aim the two pits on the package silk print of the PCB. 3. Insert a serial line on the connector After Before © 2014 DAHUA TECHHNOLOGY...
