  • Page 1 Concept 650 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 2: Limited Lifetime Consumer Warranty

    limited lifetime consumer warranty Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the life- time of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorised Directed dealer;...

  • Page 3: Trademarks And Copyrights

    THE CONTROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on how long an implied warranty will last or the exclusion or limitation of incidental or consequential damages. This warranty gives you specific legal rights and you may also have other rights that vary from State to State or Country to Country.

  • Page 4: Table Of Contents

    contents limited lifetime consumer ..warranty ....i trademarks and copyrights ..ii what is included ... . .3 important information .
  • Page 5 blackjax* deactivation sequence ..... . .33 bypass blackjax temporarily . .33 blackjax off warning indicator34 system sensors and adjustments ..... . .35 glossary of terms .

  • Page 6: What Is Included

    : : Your system MUST be installed by an Authorised dealer in accor- dance with the instructions we supply them. The Clifford Concept 650 system is designed to be installed in any petrol or common rail diesel vehicle with a 12-volt battery.

  • Page 7: System Maintenance

    : : Making changes to the existing system will invalidate the certifi- cate of installation. system maintenance The Concept 650 requires no specific maintenance. Your transmitter is powered by a miniature 3V lithium battery that will last approximately one year under normal use. When the battery weakens, operating range will be reduced and the system will provide a low battery warn- ing chirp indication when disarming.

  • Page 8: Transmitter Configurations

    Your Concept 650 system has a 5-button and 4-button remote control. Your system can accept up to 2 additional remotes. Each remote can be used to control the various standard features and options of your system as shown in the following pages.

  • Page 9: Transmitter Functions

    transmitter functions This system uses computer-based code learning to learn the transmitter buttons. This makes it possible to assign any transmitter button to any system function. The transmitter initially comes programmed with stan- dard configuration, but may also be customized using the CliffNet Wizard PC program.

  • Page 10: Standard Configuration For 4-Button Oem Transmitter

    Button, then These buttons activate the optional SmartWindows accessory. Button twice, then These buttons activate remote valet. Button twice, then These buttons disable the sensors. Button twice, then These buttons enter safe start mode for manual transmission vehicles and activate Autostart mode. (Requires optional Intellistart* accessory.) standard configuration for 4-button OEM Transmitter Button The arming and disarming functions are controlled by this button.
  • Page 11 Buttons Silent arm/disarm is controlled by these buttons. Buttons These buttons activate the optional SmartWindows. Buttons These buttons activate remote valet. Buttons These buttons disable the sensors. Buttons These buttons enter safe start mode for manual transmission vehicles and activate Autostart mode. (Requires optional Intellistart* accessory.) * This feature/accessory is not evaluated by Thatcham.

  • Page 12: Using Your System

    using your system The buttons used in the instructions in this manual correspond to the standard transmitter configuration. If your transmitter has been custom configured, the icons on your transmitter buttons may not correspond to the indicated functions. arming You can activate, or arm, the system by pressing on your trans- mitter for one second.

  • Page 13: Disarming

    and programmed for passive locking) at 30 seconds, but the siren will not chirp. The early chirps provide you with a 25-second warning prior to arming. n n o o t t e e : : If any protected entry point (a door or a switch-protected boot or bonnet) is open, the system will not passively arm.

  • Page 14: Disarming Without A Transmitter

    disarming without a transmitter This feature allows you to disarm the system without the transmitter should it be lost, damaged, or disabled. In order to disarm without a transmitter, you must have the vehicle’s ignition key, know where the PlainView 2 Valet switch is located, and have the PIN code. Be sure to check with the installer for the location of the PlainView 2 Valet switch.

  • Page 15: Transmitter Sensor Disable

    transmitter sensor disable To temporarily disable a sensor input, arm the system, press twice and then all warn away trigger zones one, two, three, and eight are bypassed. Press the buttons again; the lights flash four times and both warn away and full trigger zones one, two, three, and eight are bypassed until the system is disarmed.

  • Page 16: Auxiliary Channel Bypass

    auxiliary channel bypass Alarm sensor input zones one, two, three, and eight will be bypassed while a pulsed or timed auxiliary Output is active. disarm/valet mode Entering your pin code using the PlainView 2 Valet switch allows you to disarm the system or enter valet mode without using the transmit- ter.

  • Page 17: Transmitter Valet Mode

    3. After the last digit of the pin code is entered: a. To disarm the system: press and release b. To enter valet mode: Press and hold three seconds. The LED status indicator will illuminate continuously if you are entering Valet Mode and will turn off if you are exiting Valet Mode.

  • Page 18: One-Time Auto-Arming Bypass

    one-time auto-arming bypass This will bypass the auto arm feature once only. With the key, turn the ignition on, then off within two seconds. The siren will chirp once to confirm auto arming bypass. The system will not auto arm. n n o o t t e e : : The system will revert to normal auto arming when the system sees the ignition on for at least three seconds.

  • Page 19: Multiple Event Total Recall

    multiple event total recall This will report the last eight system triggers in reverse chronological order. Press and hold While still holding release the button. The LED will start to flash to indicate the most recent trigger and proceed down to the eighth trigger. If fewer than eight triggers are stored in memory, the LED will flash continuous- ly until the system is armed/disarmed using the transmitter or the ignition is turned on.

  • Page 20: Disarming Diagnostics

    The security system will ignore the input that was active when the sys- tem was armed, until the input goes away. Three seconds later the sys- tem will monitor that input normally. For example, if your vehicle has the boot open, and you arm the system, you will hear Bypass Notification chirps.

  • Page 21: Table Of Zones

    table of zones The zone number is the number of LED flashes used by the system to identify a specific input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed. If the Warning Zone response is triggered, the LED will not report it.

  • Page 22: High Frequency

    high frequency Your system transmits and receives at 433 MHz. This provides a cleaner spectrum with less interference and a more stable signal. smart power up II This security system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory.

  • Page 23: Programming Options

    Power Saver in Valet Mode: When the system enters Valet Mode the LED illuminates steadily. If the vehicle is not used (ignition is not turned on) for a period of one hour while the system is in Valet Mode, the LED will shut off. If the system remains in Valet Mode, the LED will come back on the next time the ignition is turned on and then back off.

  • Page 24: Cliffnet Wizard Installation Software Programming

    system passively arms (after the 30 second countdown). This feature only works if passive arming has been programmed. Reset the system to all factory defaults Entry delay feature on/off Add or remove remote controls. BlackJax* feature on or off. Change PIN code. Custom configure the remote control.

  • Page 25: Manual Programming Instructions

    manual programming instructions It is a good idea to document changes by taking note of all feature changes made in programming mode. To enter the User Selectable Features programming: Ignition on - Turn the ignition to the run position or start the engine.

  • Page 26: User Selectable Features

    n n o o t t e e : : Refer to the Feature Descriptions sections of this guide for impor- tant notes and descriptions of the system features and programming. Exit programming - To exit programming mode turn the igni- tion off or wait 60 seconds without pressing the PlainView 2 Valet switch.

  • Page 27: User Selectable Features Descriptions - Column One

    user selectable features descriptions - column one add new remote (auto learn) Auto-learn new five-button Radar2 remote controls to the system in the standard button configuration. Once you have entered the feature, press on the transmitter until you hear a confirmation chirp. Press again until you hear two chirps indicating the new remote is learned.

  • Page 28: User Selectable Features Descriptions - Column Two

    auto unlock - ignition/off Ignition: The doors will automatically unlock as soon as the ignition is turned off. Off: The doors will not automatically unlock when the igni- tion is turned off auto (passive) arm and lock - on/off On: The doors will lock when the system passively arms. This feature only applies when passive arming is programmed on.
  • Page 29 entry delay on/off On: If the system has passively armed, it will not trigger for 15 seconds after a door is opened allowing the user to enter the vehicle and disarm the system via the PlainView 2 Valet switch. Off: There is no entry delay when armed. The system will trigger instantly when a door is opened.

  • Page 30: User Selectable Features Descriptions - Column Three

    blackjax* on/off On: The system will enter BlackJax mode when triggered. Off: The system cannot enter BlackJax mode. user selectable features descriptions - column three The features in this column pertain to programming individual trans- mitter channels in custom configurations. Following is an explanation of the features.
  • Page 31 accessory b output The transmitter channel programmed into this feature will activate the accessory output. silent mode The transmitter channel programmed into this feature will arm/disarm the system, but the siren will not chirp. remote valet The transmitter channel programmed into this feature will make the system enter/exit valet mode.

  • Page 32: Pin Programming

    pin programming A PIN code can have one to four digits; each digit can be from 0-9. n n o o t t e e : : A PIN code cannot begin with a zero. Programming Procedure Enter the feature location in the installer programming grid. Immediately press and release switch.

  • Page 33: Ultrasecure Auto-Immobiliser

    PIN Code Confirmation Procedure Begin this procedure within 15 seconds of finishing the programming sequence or the new code will not be set. Turn on the ignition. Enter the new PIN code. Press and hold LED turns on: New PIN code is learned and program- ming is complete.

  • Page 34: One-Time Valet Feature

    Disarming auto-immobilisation To disarm auto-immobilisation when active, follow any of the sequences listed below. Turn ignition on and press the arm/disarm button. Arm the alarm and then disarm the alarm. Turn the ignition on and enter the system valet/PIN code. one-time valet feature This feature allows the system to be put in valet mode only until the next time the ignition is turned on.

  • Page 35: Blackjax* Activation Sequence

    blackjax* activation sequence When BlackJax is programmed ON, BlackJax sequence will begin every time the ignition is turned on and must be turned off by entering your PIN code. It will then activate again while driving when triggered as described below. n n o o t t e e : : BlackJax can be turned off by entering PIN code at any time.

  • Page 36: Blackjax* Deactivation Sequence

    If system sees the engine speed return to 1 ½ times idle or lower, the system will immobilise the vehicle as described in step 7. Vehicle Immobilisation: Immobiliser will engage the starter and ignition circuits. The siren will continue to sound and the indicator and brake lights will flash for a maximum of 5 minutes.

  • Page 37: Blackjax Off Warning Indicator

    Bypass BlackJax* temporarily Turn ignition on. Enter PIN code. Do not enter valet or programming mode. Within 10 seconds press Siren chirps 1 time as confirmation of BlackJax bypassed. Turn Ignition Off, siren chirps 3 times as confirmation of exit- ing programming.

  • Page 38: System Sensors And Adjustments

    system sensors and adjustments Your system was installed with one of 3 different sensor configuration options. Either, Digital Dual Zone proximity sensor, Ultrasonic sensor, or Tilt/Motion & Glass Tamper sensor. Proximity Sensor : The digital dual-zone proximity sensor uses dig- ital signal processing to detect mass movement inside the pas- senger compartment and very near the vehicle.

  • Page 39: Glossary Of Terms

    glossary of terms Control Unit: The "brain" of your system. Usually hidden underneath the dash area of the vehicle. It houses the microprocessor which mon- itors your vehicle and controls all of the system's functions. Input : A physical connection to the system. An input can be provided by a sensor, pinswitch or through an existing system in the vehicle, such as ignition or courtesy lights.
  • Page 40 siren sounding and indicator lights flashing. Warning Zone Response: Lighter impacts or movement close to the vehi- cle will generate the Warning Zone response. It consists of a warning siren blast or beep. (Requires either the Omnisensor or Dual Zone Proximity sensor for this to operate.) Zone : A zone is a separate input that the alarm can recognise as unique.

  • Page 41: Security & Convenience Expansions

    security & convenience expansions Here we have listed only some of the many expansion options avail- able. Please contact your dealer for a complete list of all the options available to you. Remote Boot Release : The button can operate an electric release for the vehicle’s boot or hatch.

  • Page 42: Health Check

    health check Directed Electronics recommends you return to your installing Clifford dealer to have your system checked for correct operation. The first check is due one year after the installation date and at yearly intervals thereafter. n n o o t t e e : : There may be a small charge incurred for this service. ©...
  • Page 43 Your factory set 4-digit PIN code is noted below. See page 13 for infor- mation on using your PIN code. place sticker here The company behind this system is Directed Electronics, Inc. E&OE, specification is subject to change without notice. Some vehicles require optional parts/wiring and a few are incompatible with some features.
