As supplied, this appliance is for use with natural gas (G20)
When converted using conversion kit no. 591149 this
appliance is for use with propane gas (G31)
This appliance is for use in the United Kingdom (GB) and
the Republic of Ireland (IE) only.
We trust that this Installer Guide gives sufficient details to enable the appliance to
be installed and maintained satisfactorily. However, if further information is
required, our AdviceLine will be pleased to help.
Please telephone 0345 626341 (Local call rates apply in the United Kingdom).
In the Republic of Ireland call 353 183 75114.
INSTALLER: Please leave this guide with the owner
© Wonderfire
Model BR648 VA
(G.C. 32-032-38)
INSTALLER'S GUIDE
600B731/02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wonderfire Nexus BR648 VA
Summary of Contents for Wonderfire Nexus BR648 VA
- Page 1 However, if further information is required, our AdviceLine will be pleased to help. Please telephone 0345 626341 (Local call rates apply in the United Kingdom). In the Republic of Ireland call 353 183 75114. INSTALLER: Please leave this guide with the owner © Wonderfire...
-
Page 2: Table Of Contents
9.7 To Remove the Main Burner Elbow Injector ............21 9.8 To Remove the Appliance From the Fireplace ............. 21 10 SHORT LIST OF SPARES..................22 Wonderfire, Erdington, Birmingham B24 9QP www.firesandstoves.com.uk Because our policy is one of constant development and improvement, details may vary... -
Page 3: Appliance Data
INSTALLER’S GUIDE 1 A P P L I A N C E D A T A This product uses fuel effect pieces and gaskets containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres. Excessive exposure to these materials may cause temporary irritation to eyes, skin and respiratory tract. -
Page 4: General Installation Requirements
INSTALLER’S GUIDE 2 G E N E R A L I N S T A L L A T I O N R E Q U I R E M E N T S The installation must be in accordance with these instructions. For the user’s protection, in the United Kingdom it is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety (Installation and Use) Regulations. - Page 5 INSTALLER’S GUIDE Note that soft wall coverings (e.g. embossed vinyl, etc.) are easily affected by heat. They may scorch or become discoloured when close to a heating appliance. Please bear this in mind when installing. The minimum allowable distance from the outside of the appliance case to a corner wall or other combustible surface which projects beyond the front of the appliance is 100mm at either side.
- Page 6 INSTALLER’S GUIDE 2.9.2 To a fireplace that has a precast concrete or clay flue block system conforming to BS1289 or BS EN 1806. The appliance is suitable for installations conforming to older versions of BS1289 as well as the current edition. The flue blocks must have a minimum width not less than 63mm and a cross-sectional area not less than 13,000mm...
- Page 7 INSTALLER’S GUIDE 2.9.4 If the fireplace opening is greater than the acceptable dimensions given in this guide, do not use the back of a fire surround or marble to reduce the opening. This may cause cracking of the surround back or marble. 2.10 The following flues are suitable: •...
- Page 8 INSTALLER’S GUIDE 2.16 The appliance must be mounted on a non-combustible hearth in accordance with Figure 4. The hearth material must have a minimum thickness of 12.5mm (1/2”). The periphery of the hearth (or fender) should be at least 50mm above floor level to discourage the placing of carpets or rugs over it.
-
Page 9: Pre-Installation Preparation
INSTALLER’S GUIDE 3 P R E - I N S T A L L A T I O N P R E P A R A T I O N 3.1 Pack Contents The carton contains the following:- 1 Hotbox, Trims and Burner assembly 1 Casting pack 1 Literature Pack 1 Strip of Floor Sealing Tape... -
Page 10: The Gas Supply Pipe
INSTALLER’S GUIDE • The burner assembly is retained by one screw set in the front leg - See Figure 5. Remove the screw and carefully remove the burner assembly by lifting and sliding forward from the firebox. The burner is produced from a soft ceramic material and should be handled carefully. -
Page 11: Firebox Installation
INSTALLER’S GUIDE 4 F I R E B O X I N S T A L L A T I O N 4.1 Cable Retention • Cables and eyebolts are supplied for the retention of the appliance. Ensure that the internal fireplace components are sufficiently sound... -
Page 12: Floor Sealing
INSTALLER’S GUIDE the sealing foam does not fully compress, then the adjusters and nipples may require to be slackened and the cable pulled up tighter before re-tightening the adjuster. • Do not cut off any excess cable, instead coil up the cable against the flange, as it may be required for servicing purposes. -
Page 13: Reference Pressure Check
INSTALLER’S GUIDE is normal and is due to the time required to fill the main burner compartment with sufficient gas for ignition. • When the burner is operating properly, partially depress the control knob and gradually turn it anti-clockwise. The burner flames should gradually increase until the knob reaches the “HIGH”... -
Page 14: Fitting The Ceramics
INSTALLER’S GUIDE 6 F I T T I N G T H E C E R A M I C S 1. Fit the burner tray trim over the front rim of the burner tray. Push the trim fully down. See figure 8. 2. - Page 15 INSTALLER’S GUIDE 5. Place a type “A” coal between the front and rear base coals with its lip to the front and so that the coal is close to the left side of the firebox. See figure 12. Figure 12 6.
-
Page 16: Full Operating Checks
INSTALLER’S GUIDE 7 F U L L O P E R A T I N G C H E C K S 7.1 Recheck Control Settings Now that all the ceramic fuel effects are in position, the control operation must be fully rechecked. -
Page 17: Flame Supervision & Spillage Monitoring System
This monitoring system must not be adjusted, bypassed or put out of operation. This monitoring system, or any of its parts, must only be exchanged using Wonderfire authorised parts. Page 17... -
Page 18: Final Review
INSTALLER’S GUIDE 8 F I N A L R E V I E W • Place the front casting in position between the sides of the front surround and place the bottom front cover casting below the front casting. • Visually inspect the appliance. Clean off any marks incurred during installation. •... -
Page 19: Servicing & Parts Replacement
INSTALLER’S GUIDE 9 S E R V I C I N G & P A R T S R E P L A C E M E N T Always turn off the gas supply before commencing any servicing (The appliance inlet “T”... -
Page 20: To Remove The Complete Burner Unit
INSTALLER’S GUIDE • Place the new right hand plaque in position. Make sure that the centre section of the combination plaque is between the two plaques. If there is any play between the plaques and the end retaining flanges, push the plaques firmly to the left squeezing the centre section of the combination gasket between the two plaques. -
Page 21: To Remove The Piezo Generator
INSTALLER’S GUIDE • Pull off the control knob • Remove the gas tap fixing nut. Pull the tap clear of the control plate. • Replace in the reverse order. 9.5 To Remove the Piezo Generator • Remove the gas tap – See section 9.4. •... -
Page 22: Short List Of Spares
INSTALLER’S GUIDE 1 0 S H O R T L I S T O F S P A R E S DESCRIPTION PART Injector Bray cat 18 size 360 For Natural Gas 541069 Appliances Injector Bray cat 15 size 170 For Propane Appliances 581199 Gas tap &...
