Page 1 D-Link AirPremier™ DWL-2210AP 802.11g Wireless Adaptive Access Point Manual Building Networks for People...
Page 2: Table Of Contents
Contents Package Contents ... 3 LEDs and Connections... 4 Overview... 5 Features and Beneﬁts ... 6 Prelaunch Checklist... 9 Quick Steps for Setup... 19 Conﬁguring Basic Settings ... 28 Managing Access Points and Clusters ... 35 Managing User Accounts ... 43 Session Monitoring...
Page 3: Package Contents
If any of the above items are missing, please contact your reseller. Note: Using a power supply with a different voltage rating than the one included with the DWL-2210AP will cause damage and void the warranty for this product. System Requirements for Conﬁguration: ...
Page 4: Leds And Connections
Power:Solid green light indicates connection. The LAN Port is Auto-MDI/MDIX. You can insert either a straight-through or a crossover Ethernet cable in this port in order to connect the DWL-2210AP to the local network. Receptor for the Power Adapter WLAN: Blinking green light indicates wireless activity.
Page 5: Overview
The D-Link DWL-2210AP is a single band access point with one radio capable of broadcasting in either IEEE 802.11b or IEEE 802.11g mode.
Page 6: Features And Beneﬁts
Features and Beneﬁts IEEE Standards Support and Wi-Fi Compliance  Support for IEEE  Provides bandwidth of up to 54Mbps* IEEE (11Mbps* for IEEE 802.11b)  Wi-Fi certiﬁcation Wireless Features  Auto channel selection at startup  Transmit power adjustment ...
Page 7 Features and Beneﬁts (continued) Security Features  Inhibit SSID Broadcast  Ignore SSID Broadcast  Weak IV avoidance  Wireless Equivalent Privacy (WEP)  Wi-Fi Protected Access (WPA)  Advanced Encryption Standard (AES)  User based access control with local authentication server ...
Page 8 Features and Beneﬁts (continued) Clustering and Auto-Management (continued)  Self-managed access points with automatic conﬁguration synchronization The access points in a cluster periodically check that the cluster conﬁguration is consistent, and check for the presence and availability of the other members of the cluster. The administrator can monitor this information through the user interface.
Page 9: Prelaunch Checklist
Dynamic IP Addressing  Static IP Addressing D-Link DWL-2210AP The D-Link DWL-2210AP is a wireless communications hub for devices on your network. It provides continuous, high-speed access between your wireless and Ethernet devices 802.11b and 802.11g. The D-Link DWL-2210AP offers an out-of-the-box Guest Interface feature that allows you to conﬁgure access points for controlled guest access of the wireless network.
Page 10: Default Settings
Option Default Settings System Name User Name Password Network Name (SSID) Network Time Protocol (NTP) IP Address Related Information DWL-2210AP admin The user name is read-only. It cannot be modiﬁed. admin Internal interface: “default” Guest interface: “default (guest)” None 192.168.0.50...
Page 11 Prelaunch Checklist Default Settings (continued): Option Default Settings Connection Type Dynamic Host Conﬁguration Protocol (DHCP) If you do not have a the Internal network and do not plan to use one, the ﬁrst thing you must do after bringing up the access point is to change the Connection Type from “DHCP”...
Page 12 WDS Settings None What the Access Point Does Not Provide The D-Link DWL-2210AP is not designed to function as a To connect your wireless LAN (WLAN) to other LANs or to the Internet, you need a gateway device. Related Information “Conﬁguring Radio Settings”...
Page 13 KickStart utility (which you run from the CD) and through a Web-based user interface. The DWL-2210AP must be installed into a DHCP-enabled network in order to use the KickStart utility for conﬁguration. The following table describes the minimum requirements for the administrator’s computer.
Page 14 It must also support HTTP uploads to use the ﬁrmware upgrade feature. You can run the KickStart Wizard on the D-Link CD-ROM on any Windows laptop or computer that is connected to the access point either directly or through a switch. It detects D-Link DWL-2210APs on the network.
Page 15 Prelaunch Checklist Wireless Client Computers The D-Link DWL-2210AP provides wireless access to any client with a properly conﬁgured Wi-Fi client adapter for the 802.11b and 802.11g modes in which the access point is running. Multiple client operating systems are supported. Clients can be laptops or desktops, personal digital assistants (PDAs), or any other hand-held, portable or stationary device equipped with a Wi-Fi adapter and supporting drivers.
Page 16 Prelaunch Checklist Wireless Client Computers (continued) Required Software or Component Client Security Settings Description Security should be disabled on the client used to do initial conﬁguration of the access point. If the Security mode on the access point is set to anything other than plain text, wireless clients will need to set a proﬁle to the authentication mode used by the access point and provide a valid username and password, certiﬁcate, or similar user identity...
Page 17 A DHCP server is a requirement for the Guest network. You must have the DWL-2210AP installed in a DHCP network in order to use the Kickstart Wizard. When you run the KickStart Wizard on the CD-ROM, it discovers the D-Link DWL-2210APs on the network and lists their IP addresses and MAC addresses.
Page 18: Dhcp Server
Web conﬁguration screen will appear. You can change the static IP address of the DWL-2210AP so that it is within the range of your network. If you do this, you must also revert your computer’s IP address to its previous setting within your network’s range.
Page 19: Quick Steps For Setup
Quick Steps for the Setup and Launch ofYour Wireless Network Setting up and deploying one or more D-Link DWL-2210APs is in effect creating and launching a wireless network. The KickStart Wizard (for DHCP-enabled networks) and corresponding Basic Settings Administration Web page simplify this process. Here is a step-by-step guide to setting up your D-Link DWL-2210APs and the resulting wireless network.
Page 20 Quick Steps for Setup Step 1. Unpack the access point (continued) What’s inside the box? D-Link AirPremier DWL-2210AP 802.11g Wireless Adaptive Access Point Power over Ethernet base unit Power Adapter-DC 48V, 0.4A Power cord Manual and Warranty on CD Quick Installation Guide Ethernet Cable Step 2.
Page 21 Connect one end of a Cat5 cable into the LAN(PoE) port on the back of the DWL-2210AP, and connect the other end into the P+DATA OUT port on the PoE base unit. Connect another Cat5 cable into the DATA IN port of the PoE base unit and connect the other end into a LAN port on your computer or switch.
Page 22 IP addresses and conﬂict with each other. (For more information, see “Understanding Dynamic and Static IP Addressing on the D-Link DWL-2210AP” and “How Does the Access Point Obtain an IP Address at Startup?” )
Page 23 Kickstart Back button to search again for access points. 3. Review the list of access points found. KickStart will detect the IP addresses of D-Link DWL- 2210APs. Access points are listed with their locations, Media Access Control (MAC) addresses, and addresses.
Page 24 Step 4a. Log on to the Administration Web pages when using Kickstart in a DHCP network When you follow the link from KickStart to the D-Link DWL-2210AP Administration Web pages, you are prompted for a user name and password. Field Default Setting...
Page 25 When the DWL-2210AP is installed in a network with no DHCP server, after conﬁguring your computer’s static IP address to be within the IP address range of the DWL-2210AP, you will enter the IP address of the DWL-2210AP into the address ﬁeld of your web browser; the browser window shown below will appear.
Page 26 Quick Steps for Setup Step 5. Conﬁgure “Basic Settings” Provide a minimal set of conﬁguration information by deﬁning the basic settings for your wireless network. These settings are all available on the Administration Web interface, and are categorized into steps 1-4 on the Web page. For a detailed description of these “Basic Settings”...
Page 27 3. Connect your computer to the LAN either via Ethernet cable or wireless client card. Test LAN Connectivity with Wireless Clients Test the D-Link DWL-2210AP by trying to detect it and associate with it from some wireless client devices. (See “Wireless Client Computers” in the PreLaunch Checklist: Default Settings and Supported Administrator/Client Platforms for information on requirements for these clients.)
Page 28: Conﬁguring Basic Settings
Conﬁguring Basic Settings The basic conﬁguration tasks are described in the following sections: • Navigating to Basic Settings • Review / Describe the Access Point • Provide Administrator Password and Wireless Network Name • Set Conﬁguration Policy for New Access Points •...
Page 29 Conﬁguring Basic Settings Navigating to Basic Settings Basic Settings. To conﬁgure initial settings, click If you use KickStart Wizard to link to the Administration Web pages, the Basic Settings page is displayed by default. Fill in the ﬁelds on the Basic Settings screen as described on the following page.
Page 30 To see MAC addresses for Guest and Internal interfaces on the AP, see the Status > Interfaces tab. access point. As new versions of the D-Link DWL-2210AP ﬁrmware become available, you can upgrade the ﬁrmware on your access points to take advantages of new features and enhancements. (You can download the most recent ﬁrmware from...
Page 31 Administrator Password (again) Wireless Network Name (SSID) The D-Link DWL-2210AP is not designed for multiple, simultaneous conﬁguration changes. If you have a network that includes multiple access points, and more than one administrator is logged on to the Administration Web pages and making changes to the conﬁguration, all access points in the cluster will stay in synch but there is no guarantee that all conﬁguration changes speciﬁed...
Page 32 Conﬁguring Basic Settings Set Conﬁguration Policy for New Access Points Field New Access Points Description Choose the policy you want to put in effect for adding New Access Points to the network. If you choose “are conﬁgured automatically”, then when a new access point is added to the network it automatically joins the existing cluster.
Page 33 Conﬁguring Basic Settings Update Basic Settings When you have reviewed the new conﬁguration, click Update to apply the settings and deploy the access points as a wireless network. Summary of Settings When you update the Basic Settings, a summary of the new settings is shown along with information about next steps.
Page 34 Conﬁguring Basic Settings Basic Settings for a Standalone Access Point The Basic Settings tab for a standalone access point indicates only that the current mode is standalone and provides a button for adding the access point to a cluster (group). If you click on any of the Cluster tabs on the Administration pages for an access point in standalone mode, you will be redirected to the Basic Settings page because Cluster settings do not apply to standalone APs.
Page 35: Managing Access Points And Clusters
IP address of the access point and by using its IP address in a URL (http:// IPAddressOfAccessPoint). The D-Link DWL-2210AP is not designed for multiple, simultaneous conﬁguration changes. If you have a network that includes multiple access points, and more than one administrator is logged on to the Administration Web pages and making changes to the conﬁguration, all access...
Page 36 What is a Cluster? A cluster is a group of access points which are coordinated as a single group via D-Link DWL-2210AP administration. You cannot create multiple clusters on a single wireless network (SSID).
Page 37 Managing Access Points and Clusters What Kinds of APs Can Cluster Together? A single D-Link DWL-2210AP can form a cluster with itself (a “cluster of one”) and with other D-Link DWL-2210APs. In order to be members of the same cluster, access points must be: •...
Page 38: Standalone Mode
Many APs Can a Cluster Support?” in this manual. Standalone Mode The D-Link DWL-2210AP can be conﬁgured in standalone mode. In standalone mode, an access point is not a member of the cluster and does not share the cluster conﬁguration, but rather requires manual conﬁguration that is not shared with other access points.
Page 39 You can re-enable cluster mode on a standalone access point. (See “Adding an Access Point to a Cluster” in this manual.) Cluster Formation A cluster is formed when the ﬁrst D-Link DWL-2210AP is conﬁgured. (See “Quick Steps for Setup and Launch of Your Wireless Network” and “Conﬁguring Basic Settings” in this manual.) If a cluster conﬁguration policy is in place, when a new access point is deployed, it...
Page 40 Managing Access Points and Clusters The progress bar indicates that the system is busy performing an auto-synch of the updated conﬁguration to all APs in the cluster. The Administration Web pages are not editable during the auto-synch. Note that auto-synchronization always occurs during conﬁguration updates that affect the cluster, but the processing time is usually negligible.
Page 41: Removing An Access Point From The Cluster
Managing Access Points and Clusters The following table describes the access point settings and information display in detail. Modifying the Location Description To make modiﬁcations to the location description: Basic Settings 1. Navigate to the 2. Update the Location description in section 1 under “Review Description of this Access Point.”...
Page 42 Navigating to Conﬁguration Information for a Speciﬁc AP and Managing Standalone APs In general, the D-Link DWL-2210AP is designed for central management of clustered access points. For access points in a cluster, all access points in the cluster reﬂect the same conﬁguration.
Page 43: Managing User Accounts
• WPA with RADIUS mode (see “WPA with RADIUS” in the Conﬁguring Security section) You have the option of using either the internal RADIUS server embedded in the D-Link DWL-2210AP or an external RADIUS server that you provide. If you use the embedded RADIUS server, use this Administration Web page on the access point to set up and manage user accounts.
Page 44: Adding A User
Managing User Accounts Navigating to User Management for Clustered Access Points To set up or modify user accounts, click the Viewing User Accounts User accounts are shown at the top of the screen under “User Accounts” User name, real name and status (enabled or disabled) are shown. You make modiﬁcations to an existing user account by ﬁrst selecting the checkbox next to a user name and then choosing an action.
Page 45 Managing User Accounts Fields Real Name Password Field Description 2. When you have ﬁlled in the ﬁelds, click Add Account to add the account. The new user is then displayed in the “User Accounts.” The user account is enabled by default when you ﬁrst create it.
Page 46 Managing User Accounts This can come in handy in situations where users have an occasional need to access the network. For example, contractors who do work for your company on an intermittent but regular basis might need network access for 3 months at a time, then be off for 3 months, and back on for another assignment.
Page 47: Session Monitoring
Session Monitoring The D-Link DWL-2210AP provides real-time session monitoring information including which clients are associated with a particular access point, data rates, transmit/receive statistics, signal strength, and idle time. The following Session Monitoring topics are covered here: • Navigating to Session Monitoring •...
Page 48 Session Monitoring Understanding Session Monitoring Information The Sessions page shows information on client stations associated with access points in the cluster. Each client is identiﬁed by user name and user the AP (location) to which it is currently connected. To view a particular statistic for client sessions, select an item from the Display drop-down list and click Go.
Page 49: Sorting Session Information
Session Monitoring Field Data Rate (continued) Signal Utilization Receive Total Transmit Total Error Rate Viewing Session Information for Access Points Field Description You can view session information for all access points on the network at the same time, or set the display to show session information for a speciﬁed access point chosen from the drop-down menu at the top of the screen.
Page 50: Setting The Ethernet (Wired) Interface
“Which Settings are Shared as Part of the Cluster Conﬁguration and Which Are Not?” in this manual. The following sections describe how to conﬁgure “Wired” address and related settings on the D-Link DWL-2210AP: • Navigating to Ethernet • Setting the DNS Name •...
Page 51 Setting the Ethernet (Wired) Interface Navigating to Ethernet Advanced > Ethernet To set the wired address for an access point, navigate to the tab, and update the ﬁelds as described in the following pages.
Page 52 LAN. very popular LAN technology. The D-Link DWL-2210AP allows you to conﬁgure two different LANs on the same access point: one for a secure internal LAN and another for a public guest network with no security and little or no access to internal resources.
Page 53 Then, reconnect via the Administration Web pages to the new IP address. (If necessary, check with the infrastructure support administrator regarding the VLAN and DHCP conﬁgurations.) Description By default, the D-Link DWL-2210AP ships with Guest Access disabled. • To enable Guest Access, click Enabled. • To disable Guest Access, click Disabled.
Page 54 Static IP indicates that all network settings are provided manually. You must provide the IP address for the D-Link DWL-2210AP, its subnet mask, the IP address of the default gateway, and the IP address of at least one DNS nameserver. If you select “DHCP Client”, the D-Link DWL-2210AP will acquire its IP Address, subnet mask, and DNS and gateway information from the DHCP Servers.
Page 55 Setting the Ethernet (Wired) Interface Field Static IP Address If you chose “Static IP” as the Connection Type, these ﬁelds will be enabled. Enter the Static IP Address in the text boxes. Subnet Mask Enter the information from your ISP or network administrator. Default Gateway Enter the DNS Nameservers...
Page 56: Setting The Wireless Interface
SSID). The following sections describe how to conﬁgure the “Wireless” address and related settings on the D-Link DWL-2210AP: • Navigating to Wireless Settings • Conﬁguring the Radio Interface • Conﬁguring “Internal” LAN Wireless Settings •...
Page 57 Setting the Wireless Interface Navigating to Wireless Settings To set the wireless address for an access point, navigate to the and update the ﬁelds as described below. The following ﬁgure shows the Wireless settings page for a two-radio AP. The Administration Web page for the single-radio AP will look slightly different.
Page 58 Setting the Wireless Interface Conﬁguring the Radio Interface The radio interface allows you to set the radio described below. Field MAC Addresses (Shown on two-radio AP only) Mode Channel Channel Description Indicates the Media Access Control (MAC) addresses for the interface. A MAC address is a permanent, unique hardware address for any device that represents an interface to the network.
Page 59 Setting the Wireless Interface Conﬁguring “Internal” LAN Wireless Settings The Internal Settings describe the (also known as the SSID) for the internal Wireless LAN (WLAN) as described below. Field Field Description Field Description MAC Address Shows the This a read-only ﬁeld that you cannot change. Although this access is point is physically a single device, it can be represented on the network as two or more nodes each with a unique MAC Address.
Page 60 (SSID) for the Guest Network as described below. Conﬁguring an access point with two different network names (SSIDs) allows you to leverage the Guest interface feature on the D-Link DWL-2210AP. For more information, see “Setting up Guest Access” in this manual.
Page 61: Enabling The Network Time Protocol Server
. http://www.ntp.org for more general information on NTP. The following sections describe how to conﬁgure the D-Link DWL-2210AP to use a speciﬁed NTP server: • Navigating to Time Protocol Settings • Enabling or Disabling a Network Time Protocol (NTP) Server...
Page 62 Enabling the Network Time Protocol Server Navigating to Time Protocol Settings To enable an server, navigate to the ﬁelds as described below. Advanced > Time Protocol tab, and update the...
Page 63 Enabling the Network Time Protocol Server Enabling or Disabling a Network Time Protocol (NTP) Server To conﬁgure your access point to use a network time protocol (NTP) server, ﬁrst enable the use of NTP, and then select the NTP server you want to use. (To shut down NTP service on the network, disable NTP on the access point.) Field Field Description...
Page 64: Conﬁguring Security
Conﬁguring Security The following sections describe how to conﬁgure Security settings on the D-Link DWL-2210AP: • Understanding Security Issues on Wireless Networks • How Do I Know Which Security Mode to Use? • Comparison of Security Modes for Key Management, Authentication and Encryption Algorithms •...
Page 65 Conﬁguring Security How Do I Know Which Security Mode to Use? In general, we recommend that on your Internal network you use the most robust security mode that is feasible in your environment. When conﬁguring security on the access point, you ﬁrst must choose the security mode, then in some modes an authentication algorithm, and whether to allow clients not using the speciﬁed security mode to associate.
Page 66 Conﬁguring Security Following is a list of the security modes available on the D-Link DWL-2210AP along with a description of the key management, authentication, and encryption algorithms used in each mode. We include some suggestions as to when one mode might be more appropriate than another.
Page 67 Static uses a ﬁxed key that is provided by the administrator. WEP keys are indexed in different slots (up to four on the D-Link DWL -2210AP). The client stations must have the same key indexed in the same slot to access data on the access point.
Page 68 Kerberos, and public key authentication with a RADIUS server. You have a choice of using the D-Link DWL-2210AP embedded RADIUS server or an external RADIUS server. The embedded RADIUS server supports Protected (PEAP) and MSCHAP V2.
Page 69 Multicast Unicast Unicast Keentication Remote Authentication Dial-In User Service (RADIUS). You have a choice of using the D-Link DWL-2210AP embedded RADIUS server or an external RADIUS server. The embedded RADIUS server supports Protected (PEAP) and MSCHAP V2. CCMP (AES) and...
Page 70 Conﬁguring Security If there are older client stations on your network that do not support WPA, you can conﬁgure WPA with RADIUS (with Both, CCMP, or TKIP) and check the “Allow non-WPA IEEE 802.1x clients” checkbox to allow non-WPA clients. This way, you get the beneﬁt of IEEE 802.1x key management for non-WPA clients along with even better data protection of TKIP and CCMP (AES) key management and encryption algorithms for your WPA clients.
Page 71 Conﬁguring Security Recommendations WPA w/PSK not recommended for use with the D-Link DWL-2210AP when WPA with RADIUS is an option. We recommend that you use WPA with RADIUS mode instead, unless you have interoperability issues that prevent you from using this mode.
Page 72 Conﬁguring Security Navigating to Security Settings To set the security mode, navigate to the ﬁelds as described below. Conﬁguring Security Settings The following conﬁguration information explains how to conﬁgure security modes on the access point. Keep in mind that each wireless client that wants to exchange data with the access point must be conﬁgured with the same security mode and encryption key settings consistent with access point security.
Page 73: Guest Network
Security Mode Plaintext mode. Plaintext Plain Text means any data transferred to and from the D-Link DWL-2210AP is not encrypted. There are no further options for “Plaintext” mode. Plain text mode can be useful during initial network conﬁguration or for problem solving, but it is not recommended for regular use on the Internal network because it is not secure.
Page 74 Conﬁguring Security The absence of security on the Guest AP is designed to make it as easy as possible for guests to get a connection without having to program any security settings in their clients. For a minimum level of protection on a guest network, you can choose to suppress (prohibit) the broadcast of the SSID (network name) to discourage client stations from automatically discovering your access point.
Page 75 Conﬁguring Security Field Transfer Key Index Key Length Key Type Characters Required WEP Keys Description Select a key index from the drop-down menu. Key indexes 1 through 4 are available. The default is 1. The Transfer Key Index indicates which WEP key the access point will use to encrypt the data it transmits.
Page 76 Conﬁguring Security Field Authentication Algorithm Description The authentication algorithm deﬁnes the method used to determine whether a client station is allowed to associate with an access point when static WEP is the security mode. Specify the authentication algorithm you want to use by choosing one of the following from the drop-down menu: •...
Page 77 Conﬁguring Security Rules to Remember for Static WEP All client stations must have the Wireless LAN (WLAN) security set to WEP and • all clients must have one of the WEP keys speciﬁed on the AP in order to decode AP-to-station data transmissions.
Page 78 Conﬁguring Security Providing a Wireless Client with a WEP Key If you have a second client station, that station also needs to have one of the WEP keys deﬁned on the You could give it the same WEP key you gave to the ﬁrst station.
Page 79 MSCHAP When conﬁguring IEEE 802.1x mode, you have a choice of whether to use the embedded RADIUS server or an external RADIUS server that you provide.The D-Link DWL-2210AP embedded RADIUS server supports Protected If you use your own RADIUS server, you have the option of using any of a variety of authentication methods that the IEEE 802.1x mode supports, including certiﬁcates,...
Page 80 On the current release of the D-Link DWL-2210AP, the RADIUS server User Datagram Protocol (UDP) ports used by the access point are not conﬁgurable. (The D-Link DWL-2210AP is hard-coded to use RADIUS server UDP port 1812 for authentication and port 1813 for accounting.)
Page 81 Cluster > Users tab. When conﬁguring WPA with RADIUS mode, you have a choice of whether to use the embedded RADIUS server or an external RADIUS server that you provide. The D- Link DWL-2210AP embedded RADIUS server supports Protected (PEAP) and MSCHAP V2.
Page 82 Conﬁguring Security Field Cipher Suites Select the cipher you want to use from the drop-down menu: • TKIP • CCMP • Both Temporal Key Integrity Protocol (TKIP) is the default. TKIP provides a more secure encryption solution than WEP keys. The TKIP process more frequently changes the encryption key used and better ensures that the same key will not be reused to encrypt data (a weakness of WEP).
Page 83 Description Built-in - To use the authentication server provided with the D- Link DWL-2210AP. If you choose this option, you do not have to provide the Radius IP and Radius Key; they are automatically provided. External - To use an external authentication server. If you choose this option you must supply a Radius IP and Radius Key of the server you want to use.
Page 84 Conﬁguring Security WPA-PSK Wi-Fi Protected Access (WPA) with Pre-Shared Key (PSK) is a Wi-Fi Alliance subset of IEEE 802.11i, which includes Temporal Key Integrity Protocol (TKIP), Advanced Encryption Algorithm (AES), and Counter mode/CBC-MAC Protocol (CCMP) mechanisms. PSK employs a pre-shared key. This is used for an initial check of credentials only.
Page 85: Conﬁguring Radio Settings
(amount of time between AP beacon transmissions), transmit power, IEEE 802.11 mode in which the radio operates, and so on. The D-Link DWL-2210AP is a single band access point with one radio capable of broadcasting in either IEEE 802.11b or IEEE 802.11g mode.
Page 86 Conﬁguring Radio Settings Navigating to Radio Settings To specify radio settings, navigate to described below. Advanced > Radio tab, and update the ﬁelds as...
Page 87 Conﬁguring Radio Settings Conﬁguring Radio Settings Field Field Description Status (On/Off) Mode Channel Beacon Interval DTIM Period Description Specify whether you want the radio on or off by clicking On or Off. The Mode deﬁnes the Physical Layer (PHY) standard being used by the radio.
Page 88 Conﬁguring Radio Settings Field Fragmentation Threshold RTS Threshold Maximum Stations Description Specify a number between 256 and 2,346 to set the frame size threshold in bytes. The fragmentation threshold is a way of limiting the size of packets (frames) transmitted over the network. If a packet exceeds the fragmentation threshold set here, the fragmentation function will be activated and the packet will be sent as multiple 802.11 frames.
Page 89 To apply your changes, click Update. If you are using the two-radio version of the D-Link DWL-2210AP, keep in mind that both Radio One and Radio Two are conﬁgured on this tab. The displayed settings apply to either Radio One or Radio Two, depending on which radio you choose in the Radio ﬁeld (ﬁrst ﬁeld on tab).
Page 90: Controlling Access By Mac Address Filtering
MAC addresses. When MAC Filtering is on, only clients with a listed MAC address can access the network. The following sections describe how to use MAC address ﬁltering on the D-Link DWL-2210AP: • Navigating to MAC Filtering Settings • Using MAC Filtering...
Page 91 Controlling Access by MAC Address Filtering Navigating to MAC Filtering Settings Advanced > MAC Filtering To enable ﬁltering by MAC address, navigate to the tab, and update the ﬁelds as described below.
Page 92: Using Mac Filtering
Controlling Access by MAC Address Filtering Using MAC Filtering This page allows you to control access to D-Link DWL-2210AP based on Media Access Control (MAC) addresses. Based on how you set the ﬁlter, you can allow only client stations with a listed MAC address or prevent access to the stations listed.
Page 93: Load Balancing
Load Balancing The D-Link DWL-2210AP allows you to balance the distribution of wireless client connections across multiple access points. Using load balancing, you can prevent scenarios where a single access point in your network shows performance degradation because it is handling a disproportionate share of the wireless trafﬁc.
Page 94 Load Balancing Specifying Limits for Utilization and Client Associations You can correct for imbalances in network AP utilization by enabling load balancing and setting limits on utilization rates and number of client associations allowed per access point. Load Balancing and QoS Load balancing also plays a part in contributing to Quality of Service (QoS) for Voice Over IP (VoIP) and other such time-sensitive applications competing for bandwidth and timely access to the air waves on a wireless network.
Page 95 Load Balancing Conﬁguring Load Balancing To conﬁgure load balancing, enable “Load Balancing” and set limits and behavior to be triggered by a speciﬁed utilization rate of the access point. To view the current Utilization Rates for access points, click Cluster > Sessions on the •...
Page 96: Conﬁguring Queues For Quality Of Service
Quality of Service (QoS) provides you with the ability to specify parameters on multiple queues for increased throughput and better performance of differentiated wireless trafﬁc like Voice-over-IP (VoIP), video, and streaming media as well as traditional IP data over the D-Link DWL-2210AP. Description We recommend setting the maximum to between 30 and 50 client stations.
Page 97 Conﬁguring Queues for Qualty of Service (QoS) The following sections describe how to conﬁgure Quality of Service queues on the D-Link DWL-2210AP: • Understanding QoS • QoS and Load Balancing • 802.11e and WME Standards Support • QoS Queues and Parameters to Coordinate Trafﬁc Flow •...
Page 98 IP data which are less time-sensitive but often more data-intensive are expected to tolerate longer wait times. The D-Link DWL-2210AP implements QoS with a custom extension to the trafﬁc control mechanism in the Linux kernel. Our Linux-based queuing class is used to tag packets and establish multiple queues.
Page 99 • Downstream from network to access point QoS settings on the D-Link DWL-2210AP affect only the ﬁrst of these; downstream trafﬁc ﬂowing from the access point to client station. The other phases of the trafﬁc ﬂow are not under control of the QoS settings on the AP.
Page 100 Management and control frames wait a minimum amount of time for transmission; they wait a short interframe space (SIF). These wait times are built-in to 802.11 as infrastructure support and are not conﬁgurable. The D-Link DWL-2210AP supports the Distribution Coordination Function (DCF) as deﬁned by the 802.11e standard.
Page 101 Maximum Contention Window size is reached. Packet Bursting for Better Performance The D-Link DWL-2210AP includes 802.11e based packet bursting technology that increases data throughput and speed of transmission over the wireless network. Packet bursting enables the transmission of multiple packets without the extra overhead of header information.
Page 102 Conﬁguring QoS Queues Conﬁguring Quality of Service (QoS) on the D-Link DWL-2210AP consists of setting parameters on existing queues for different types of wireless trafﬁc, and effectively specifying minimum and maximum wait times (via Contention Windows) for transmission.
Page 103 Conﬁguring Queues for Qualty of Service (QoS) Field Queue AP-to-station: maximum throughput and is not time-sensitive is sent to this queue (FTP data, for example). this queue are in the following ranges: this queue are in the following ranges: this queue are in the following ranges: Inter-Frame Space Description Queues are deﬁned for different types of data transmitted from...
Page 104 Conﬁguring Queues for Qualty of Service (QoS) Field Min. Contention Window Max. Contention Window Max. Burst Length Updating Settings To apply your changes, click Update Settings. Description This parameter is input to the algorithm that determines the initial random backoff wait time (“window”) for retry of a transmission.
Page 105: Conﬁguring The Wireless Distribution System
Conﬁguring the Wireless Distribution System (WDS) The D-Link DWL-2210AP lets you connect multiple access points using a Wireless Distribution System (WDS).WDS allows access points to communicate with one another wirelessly in a standardized way. This capability is critical in providing a seamless experience for roaming clients and for managing multiple wireless networks.
Page 106 Conﬁguring the Wireless Distribution System (WDS) Using WDS to Bridge Distant Wired LANs In an ESS, a network of multiple access points, each access point serves part of an area which is too large for a single access point to cover. You can use WDS to bridge distant Ethernets to create a single LAN.
Page 107 Another use for WDS bridging, the creation of backup links, is not supported in this release of the D-Link DWL-2210AP. The topic is included here to emphasize that you should not try to use WDS in this way; backup links will result in unwanted, endless loops of data trafﬁc.
Page 108 Conﬁguring the Wireless Distribution System (WDS) Navigating to WDS Settings To specify the details of trafﬁc exchange from this access point to others, navigate to Advanced > WDS tab, and update the ﬁelds as described below. The following ﬁgure shows the WDS settings page for the two-radio AP. The Administration Web page for the one-radio AP will look slightly different.
Page 109 WDS bridges. Spanning Tree Protocol (STP), which manages path redundancy and prevent unwanted loops, is not enabled for this release. Keep these rules in mind when working with WDS on this release of the D-Link DWL-2210AP: • Any two access points can be connected by only a single path; either a WDS bridge (wireless) or an Ethernet connection (wired), but not both.
Page 110 “handed-off” and from which data will be received. The D-Link DWL-2210AP provides the capability of setting up and internal networks on the same access point. (See “Setting up Guest Access” in this manual.) The guest network typically provides internet access but isolates guest clients from more sensitive areas of your internal network.
Page 111 Conﬁguring the Wireless Distribution System (WDS) Field Key Type Characters Required WEP Key Example of Conﬁguring a WDS Link When using WDS, be sure to conﬁgure WDS settings on both access points on the WDS link. For example, to create a WDS link between a pair of access points “MyAP1” and “MyAP2” do the following: Description If WEP is enabled, specify the WEP key type:...
Page 112 Conﬁguring the Wireless Distribution System (WDS) 1. Open the Administration Web pages for MyAP1, by entering the IP address for MyAP1 as a URL in the Web browser address bar in the following form: http://IPAddressOfAccessPoint where IPAddressOfAccessPoint is the address of MyAP1. Navigate to the WDS tab on MyAP1 Administration Web pages.
Page 113: Setting Up Guest Access
ﬁrewall and requires secure logins or certiﬁcates for access. The Guest and Internal interfaces are set up on VLANs in the Advanced > Ethernet (Wired) Settings on the Administration Web pages for the D-Link DWL-2210AP as described below. The Guest Access feature leverage multiple BSSID and Virtual LAN (VLAN) technologies that are built-in to the D-Link DWL-2210AP.The Internal and Guest...
Page 114 Setting up Guest Access 1. Conﬁgure the access point to represent two virtually separate networks as described in the section below, “Conﬁguring Internal and Guest VLANs” in this manual. 2. Set up the guest Welcome screen for the guest captive portal as described in the section below, “Conﬁguring the Welcome Screen (Captive Portal)”...
Page 115 Setting up Guest Access Conﬁguring the Welcome Screen (Captive Portal) You can set up or modify the Welcome screen guest clients see when they open a Web browser or try to browse the Web. To set up the captive portal, do the following. Advanced >...
Page 116 Setting up Guest Access Deployment Example In the ﬁgure below, the dotted red lines indicate dedicated guest connections. All access points and all connections (including guests) are administered from the same D-Link DWL-2210AP Administration Web pages.
Page 117: Maintenance And Monitoring
Maintenance and Monitoring The maintenance and monitoring tasks described here all pertain to viewing and modifying settings on speciﬁc access points; not on a cluster conﬁguration that is automatically shared by multiple access points. Therefore, it is important to ensure that you are accessing the Administration Web pages for the particular access point you want to conﬁgure.
Page 118 Two are shown. On a one-radio access point, settings are shown for one radio. The Interfaces page for a two-radio AP is shown in the following ﬁgure. This page displays the current settings of the D-Link DWL-2210AP. It displays the (Wired) Settings...
Page 119: Wireless Settings
It provides a Kernel Log, which lists error conditions, such as dropping frames. The D-Link DWL-2210AP acquires its date and time information using the network time protocol (NTP).This data is reported in UTC format (also known as Greenwich Mean Time). You need to convert the reported time to your local time.
Page 120 Maintenance and Monitoring Statistics To view transmit/receive statistics for a particular access point, navigate to Status > Statistics on the Administration Web pages for the access point you want to monitor. The following ﬁgure shows the Transmit / Receive page for a two-radio AP.
Page 121 The MAC address is assigned by the manufacturer. The D-Link DWL-2210AP has a unique MAC address for each interface. A two-radio access point has a different MAC address for each interface on each of its two radios.
Page 122: Associated Wireless Clients
Link Integrity Monitoring The D-Link DWL-2210AP provides link integrity monitoring to continually verify its connection to each associated client (even when there is no data exchange occurring). To do this, the AP sends data packets to clients every few seconds when no other trafﬁc is passing.
Page 123: Rebooting The Access Point
Maintenance and Monitoring Rebooting the Access Point For maintenance purposes or as a troubleshooting measure, you can reboot the D-Link DWL-2210AP as follows. Advanced > Reboot 1. Click the tab. 2. Click the Reboot button. The AP reboots.
Page 124 Maintenance and Monitoring Resetting the Conﬁguration If you are experiencing extreme problems with the D-Link DWL-2210AP and have tried all other troubleshooting measures, use the Reset Conﬁguration function.This will restore factory defaults and clear all settings, including settings such as a new password or wireless settings.
Page 125: Upgrading The Firmware
Maintenance and Monitoring Upgrading the Firmware As new versions of the D-Link DWL-2210AP ﬁrmware become available, you can upgrade the ﬁrmware on your devices to take advantages of new features and enhancements. You must do this per access point; you cannot upgrade ﬁrmware automatically across the cluster.
Page 126 Maintenance and Monitoring The ﬁrmware upgrade ﬁle supplied must be in the format <FileName>.upgrade.tar. Do not attempt to use <FileName>.bin ﬁles or ﬁles of other formats for the upgrade; these will not work. Update Click Update to apply the new ﬁrmware image. Upon clicking Update for the ﬁrmware upgrade, a popup conﬁrmation window is displayed that describes the upgrade process.
Page 127 Maintenance and Monitoring Neighbors The status page for “neighboring access points” provides real-time statistics for all access points within range of the access point on which you are viewing the Administration Web pages. To view information about other access points on the wireless network, Status >...
Page 128 Maintenance and Monitoring Information provided on neighboring access points is described in the following table: Field MAC Address Beacon Interval Type SSID Privacy Description Shows the address of the neighboring access point. address is a hardware address that uniquely identiﬁes each node of a network.
Page 129 Maintenance and Monitoring Field Band This indicates the IEEE 802.11 mode being used on this access point. (For example, IEEE The number shown indicates the mode according to the following map: • 2.4 indicates IEEE 802.11b mode or IEEE 802.11g mode Channel Shows the channel on which the access point is currently broadcasting.
Page 130: Appendix A: Conﬁguring Security Settings For Wireless Clients
Therefore, you must have a backup Ethernet (wired) connection. The following sections describe how to set up each of the supported security modes on wireless clients of a network served by the D-Link DWL-2210AP. • Network Infrastructure and Choosing Between Built-in or External Authentication Server •...
Page 131 AP to use either IEEE 802.1x or WPA with RADIUS security mode. (The built-in authentication server uses EAP-PEAP authentication protocol.) If the D-Link DWL-2210AP is set up to use IEEE 802.1x mode and the Built-in •...
Page 132: Security Settings
Appendix A: Conﬁguring Security Settings on Wireless Clients Make Sure the Wireless Client Software is Up-to-Date Before starting out, please keep in mind that service packs, patches, and new releases of drivers and other supporting technologies for wireless clients are being generated at a fast pace.
Page 133 Appendix A: Conﬁguring Security Settings on Wireless Clients List of available networks will change depending on client location. Each network (or access point) that is detected by the client shows up in this list. (“Refresh” updates the list with current information.) For each network you want to connect to, configure security...
Page 134 Appendix A: Conﬁguring Security Settings on Wireless Clients Conﬁguring a Client to Access an Unsecure Network (Plain Text mode) If the access point or wireless network to which you want to connect is conﬁgured as “Plain Text” security mode (no security), you need to conﬁgure the client accordingly. A client using no security to connect is conﬁgured with Network Authentication “Open”...
Page 135 (Or they can all use the same key, but this is less secure because it means one station can decrypt the data being sent by another.) If you conﬁgured the D-Link DWL-2210AP to use Static WEP security mode . . .
Page 136 Appendix A: Conﬁguring Security Settings on Wireless Clients . . . then conﬁgure WEP security on each client as follows. Choose Open or Shared Choose WEP as the Data Encryption mode Enter a network key that matches the WEP key on the access point in the position set to the transfer key index (and retype to conﬁrm) Optionally set a different transfer key...
Page 137 Appendix A: Conﬁguring Security Settings on Wireless Clients Authentication Tab Enable IEEE 802.1x authentication for this network Click OK on the Wireless Network Properties dialog to close it and save your changes. Connecting to the Wireless Network with a Static WEP Client Static WEP clients should now be able to associate and authenticate with the access point.
Page 138 • Additionally, you may have an external RADIUS server that uses EAP/PEAP. If so, you will need to (1) add the D-Link DWL-2210AP to the list of RADIUS server clients, and (2) conﬁgure your IEEE 802.1x wireless clients to use PEAP.
Page 139 Appendix A: Conﬁguring Security Settings on Wireless Clients Choose Open Enable auto key option Disable (click to uncheck) “Validate server certiﬁcate” Choose “secured . . . then click password (EAP- “Conﬁgure” MSCHAP v2)” Enable (click to check) IEEE 802.1x authentication Choose WEP Data Encryption...
Page 140 Appendix A: Conﬁguring Security Settings on Wireless Clients 1. Conﬁgure the following settings on the Association tab on the Network Properties dialog. Association Tab Network Authentication Data Encryption This key is provided for me automatically 2. Conﬁgure this setting on the Authentication tab. Authentication Tab EAP Type 3.
Page 141 Certiﬁcate Server at http://support.microsoft.com/default.aspx?scid=kb;en-us;318710#3. To use this type of security, you must do the following: 1. Add the D-Link DWL-2210AP to the list of RADIUS server clients. (See “Conﬁguring an External RADIUS Server to Recognize the D-Link DWL-2210AP” in this manual.) 2.
Page 142 Appendix A: Conﬁguring Security Settings on Wireless Clients If you conﬁgured the D-Link DWL-2210AP to use IEEE 802.1x security mode with an external RADIUS server ..then conﬁgure IEEE 802.1x security with certiﬁcate authentication on each client as follows.
Page 143 Appendix A: Conﬁguring Security Settings on Wireless Clients 1. Conﬁgure the following settings on the Association tab on the Network Properties dialog. Association Tab Network Authentication Data Encryption This key is provided for me automatically 2. Conﬁgure these settings on the Authentication tab. Authentication Tab Enable IEEE 802.1x authentication for this network...
Page 144 Appendix A: Conﬁguring Security Settings on Wireless Clients 3. Click Properties to bring up the Smart Card or other Certiﬁcate Properties dialog and enable the “Validate server certiﬁcate” option. Smart Card or other Certiﬁcate Properties Dialog Validate Server Certiﬁcate Certiﬁcates Click OK on all dialogs to close and save your changes.
Page 145 Extensible Authentication Protocol (EAP) known as “EAP/PEAP”. • If you are using the Built-in Authentication server with “WPA with RADIUS” security mode on the D-Link DWL-2210AP, then you will need to set up wireless clients to use PEAP. • Additionally, you may have an external RADIUS server that uses EAP/PEAP. If so, you will need to (1) add the D-Link DWL-2210AP to the list of RADIUS server clients, and (2) conﬁgure your “WPA with RADIUS”...
Page 146 Appendix A: Conﬁguring Security Settings on Wireless Clients If you conﬁgured the D-Link DWL-2210AP to use WPA with RADIUS security mode and to use either the Built-in Authentication Server or an external RADIUS server that uses EAP/PEAP . . .
Page 147 Appendix A: Conﬁguring Security Settings on Wireless Clients Choose WPA Disable (click to uncheck) “Validate server certiﬁcate” Choose “secured . . . then click password (EAP- “Conﬁgure” MSCHAP v2)” Choose either TKIP or AES for the Data Encryption mode Choose Protected EAP (PEAP) Disable (click to uncheck) option to automatically use Windows logon name and password...
Page 148 Appendix A: Conﬁguring Security Settings on Wireless Clients 1. Conﬁgure the following settings on the Association and Authentication tabs on the Network Properties dialog. Association Tab Network Authentication Data Encryption 2. Conﬁgure this setting on the Authentication tab. Authentication Tab EAP Type 3.
Page 149 Certiﬁcate Server at http://support.microsoft.com/default.aspx?scid=kb;en-us;318710#3. To use this type of security, you must do the following: 1. Add the D-Link DWL-2210AP to the list of RADIUS server clients. (See “Conﬁguring an External RADIUS Server to Recognize the D-Link DWL-2210AP” in this manual.) 2.
Page 150 Appendix A: Conﬁguring Security Settings on Wireless Clients Choose WPA Choose either TKIP or AES for the Data Encryption mode Choose Smar t Card or other certiﬁcate and enable “Authenticate as computer when info is available” Enable (click to check) “Validate server certiﬁcate”...
Page 151 Appendix A: Conﬁguring Security Settings on Wireless Clients 1. Conﬁgure the following settings on the Association tab on the Network Properties dialog. Association Tab Network Authentication Data Encryption 2. Conﬁgure these settings on the Authentication tab. Authentication Tab Enable IEEE 802.1x authentication for this network EAP Type 3.
Page 152 Encryption Algorithm (AES), and Counter mode/CBC-MAC Protocol (CCMP) mechanisms. PSK employs a pre-shared key for an initial check of client credentials. If you conﬁgured the D-Link DWL-2210AP to use WPA-PSK security mode ..then conﬁgure WPA-PSK security on each client as follows.
Page 153 Appendix A: Conﬁguring Security Settings on Wireless Clients Association Tab Network Authentication Data Encryption Network Key The key is provided for me automatically Authentication Tab Enable IEEE 802.1x authentication for this network Click OK on the Wireless Network Properties dialog to close it and save your changes.
Page 154 Please consult the documentation for your RADIUS server for information on setting up user accounts. The purpose of this procedure is to identify your D-Link DWL-2210AP as a “client” to the RADIUS server. The RADIUS server can then handle authentication and authorization of wireless clients for the AP.
Page 155 The RADIUS server is identiﬁed by its IP address and UDP port numbers for the different services it provides. On the current release of the D-Link DWL-2210AP, the RADIUS server User Datagram Protocol (UDP) ports used by the access point are not conﬁgurable. (The D-Link DWL-2210AP is hard-coded to use RADIUS server UDP port 1812 for authentication and port 1813 for accounting.)
Page 156 Appendix A: Conﬁguring Security Settings on Wireless Clients • IP address for the access point. Click Next. 4. For the “Shared secret” enter the RADIUS Key you provided to the access point (on the Advanced >Security page). Retype the key to conﬁrm.
Page 157 Appendix A: Conﬁguring Security Settings on Wireless Clients 5. Click Finish. The access point is now displayed as a client of the Authentication Server.
Page 158 Appendix A: Conﬁguring Security Settings on Wireless Clients Obtaining a TLS-EAP Certiﬁcate for a Client f you want to use IEEE 802.1x mode with EAP-TLS certiﬁcates for authentication and authorization of clients, you must have an external RADIUS server and a Public Key Authority Infrastructure (PKI), including a Certiﬁcate Authority (CA), server conﬁgured on your network.
Page 159 Appendix A: Conﬁguring Security Settings on Wireless Clients The Welcome screen for the Certiﬁcate Server is displayed in the browser. 3. Click “Request a certiﬁcate” to get the login prompt for the RADIUS server. 4. Provide a valid user name and password to access the RADIUS server. 5.
Page 160 Appendix A: Conﬁguring Security Settings on Wireless Clients 6. Click “Yes” on the dialog displayed to install the certiﬁcate. 7. Click “Submit” to complete and click “Yes” to conﬁrm the submittal on the popup dialog.
Page 161 Appendix A: Conﬁguring Security Settings on Wireless Clients 8. Click “Install this certiﬁcate” to install the newly issued certiﬁcate on your client station. (Also, click “Yes” on the popup windows to conﬁrm the install and to add the certiﬁcate to the Root Store.)
Page 162: Appendix B: Troubleshooting
Appendix B. Troubleshooting This section provides information about how to solve common problems you might encounter in the course of updating network conﬁgurations on networks served by multiple, clustered access points. Cluster Recovery In cases where the access points in a cluster become out of sync or an access point cannot join or be removed from a cluster, the following methods for cluster recovery are recommended.
Page 163 Appendix B: Troubleshooting The Stop Clustering page for this access point is displayed. Click the Stop Clustering button. Repeat this “stop clustering” step for every access point in the cluster. Table 1: Do not proceed to the next step of resetting any access points until you have stopped clustering on all of them.
Page 164 Appendix B: Troubleshooting On the Administration UI left-hand tabs, click Advanced > Reset to bring up the Reset page. Click Reset to restore the factory defaults on the access point. (This will clear all of your previous settings, including updated passwords.) Repeat this “reset”...
Page 165 Appendix B: Troubleshooting At this point you should see all previous cluster members displayed in the list. Before proceeding to the last step, verify that the cluster has reformed by making sure all are access points are listed. 4. Review all conﬁguration settings and make modiﬁcations as needed. Pay special attention to the security settings because after a reset, Access Points run without any security in place.
Page 166: Glossary
Glossary IEEE 802 (IEEE Std. 802-2001) is a family of standards for peer-to-peer communication over a LAN. These technologies use a shared-medium, with information broadcast for all stations to receive. The basic communications capabilities provided are packet-based. The basic unit of transmission is a sequence of data octets (8-bits), which can be of any length within a range that is dependent on the type of LAN.
Page 167: Access Point
Glossary 802.11b IEEE 802.11b (IEEE Std. 802.11b-1999) is an enhancement of the initial 5.5 Mbps and 11 Mbps data rates. It uses direct sequence spread spectrum (DSSS) or frequency hopping spread spectrum (FHSS) in the 2.4 GHz ISM band as well as complementary code keying (CCK) to provide the higher data rates.
Page 168 Glossary When one access point is connected to a wired network and supports a set of wireless stations, it is referred to as a basic service set (BSS). An extended service set (ESS) is created by combining two or more BSSs. Ad hoc Mode Ad hoc mode is a Wireless Networking Framework...
Page 169 Glossary Broadcast A Broadcast sends the same message at the same time to everyone. In wireless networks, broadcast usually refers to an interaction in which the access point sends data trafﬁc in the form IEEE 802.1x Frames to all client stations on the network. Some wireless security modes distinguish between how unicast, multicast, and broadcast frames are encrypted or whether they are encrypted.
Page 170 Glossary CSMA/CA Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA) is a low-level network arbitration/contention protocol. A station listens to the media and attempts to transmit a packet when the channel is quiet. When it detects that the channel is idle, the station transmits the packet.
Page 171: Dynamic Ip Address
Glossary The Document Object Model (DOM) is an interface that allows programs and scripts to dynamically access and update the content, structure, and style of documents. The DOM allows you to model the objects in an HTML or XML document (text, links, images, tables), deﬁning the attributes of each object and how they can be manipulated.
Page 172 Glossary Legacy IEEE 802.11b devices cannot detect the ERP-OFDM signals used by IEEE 802.11g stations, and this can result in collisions between data frames from IEEE 802.11b and IEEE 802.11g stations. If there is a mix of 802.11b and 802.11g nodes on the same channel, the IEEE 802.11g stations detect this via an ERP ﬂag on the access point and enable request to send (RTS) and clear to send (CTS) protection before sending data.
Page 173: Infrastructure Mode
Glossary IBSS An independent basic service set (IBSS) is an Ad hoc Mode Wireless Networking Framework which stations communicate directly with each other. IEEE The Institute of Electrical and Electronic Engineers (IEEE) is an international standards body that develops and establishes industry standards for a broad range of technologies, including the 802 family of networking and wireless standards.
Page 174 Glossary • The Broadcast Address 192.168.2.255). There are a ﬁnite number of IP addresses that can exist. Therefore, a local area network typically uses one of the IANA-designated address ranges for use in private networks. These address ranges are: 10.0.0.0 to 10.255.255.255 172.16.0.0 to 172.31.255.255 192.168.0.0 to 192.168.255.255 Dynamic IP Address...
Page 175 Glossary connects multiple computers and other network devices such as storage and printers. Ethernet is the most common technology implementing a LAN. Wireless Ethernet (802.11) is another very popular LAN technology (also see WLAN). LDAP The Lightweight Directory Access Protocol (LDAP) is a protocol for accessing online directory services.
Page 176 Glossary Multicast A Multicast sends the same message to a select group of recipients. Sending an e-mail message to a mailing list is an example of multicasting. In wireless networks, multicast usually refers to an interaction in which the access point sends data trafﬁc in the form of speciﬁed set of client stations Some wireless security modes distinguish between how unicast, multicast, and broadcast frames are encrypted or whether they are encrypted.
Page 177: Port Forwarding
Glossary • Layer 3, the Network layer, deﬁnes the how to determine the best path for information traversing the network. Packets and logical Addresses operate on the network layer. • Layer 4, the Transport layer, deﬁnes connection oriented protocols such as and UDP.
Page 178 Glossary The Point-to-Point Protocol is a standard for transmitting network layer datagrams over serial point-to-point links. PPP is designed to operate both over asynchronous connections and bit-oriented synchronous systems. PPPoE Point-to-Point Protocol over Ethernet (PPPoE) is a speciﬁcation for connecting the users on to the Internet through a common broadband medium, such as a single DSL or cable modem line.
Page 179 Glossary Router A router is a network device which forwards packets between networks. It is connected to at least two networks, commonly between two local area networks (LANs) or between a a wide-area network (WAN), for example, the Internet. Routers are located at gateways—places where two or more networks connect.
Page 180 Glossary SNMP consists of managed devices and their agents, and a management system. The agents store data about their devices in Management Information Bases (MIBs) and return this data to the SNMP management system when requested. SSID The Service Set Identiﬁer (SSID) is a thirty-two character alphanumeric key that uniquely identiﬁes a wireless local area network.
Page 181 “best-effort” settings depending upon the requirements of the data. The ToS ﬁeld is used by the D-Link DWL-2210AP to provide conﬁguration control over Quality of Service (QoS) queues for data transmitted from the AP to client stations.
Page 182 The nodes in a VLAN share resources and bandwidth, and are isolated on that network. The D- Link DWL-2210AP supports the conﬁguration of a wireless VLAN. This technology is leveraged on the access point for the “virtual” guest network feature.
Page 183 Glossary WINS The Windows Internet Naming Service (WINS) is a server process for resolving Windows-based computer names to IP addresses. It provides information that allows these systems to browse remote networks using the Network Neighborhood. Wireless Networking Framework There are two ways of organizing a wireless network: •...
Page 184: Technical Speciﬁcations
Technical Speciﬁcations Standards • IEEE 802.11b • IEEE 802.11g • IEEE 802.3 • IEEE 802.3af • IEEE 802.3u • IEEE 802.3x Device Management • Web-Based – Internet Explorer v6 or later; Netscape Navigator v6 or later; or other Java-enabled browsers. •...
Page 185 Technical Speciﬁcations (continued) Wireless Operating Range* 802.11g (Full Power with 5dBi gain diversity dipole antenna) Indoors: • 98ft (30m) @ 54Mbps • 108ft (33m) @ 48Mbps • 121ft (37m) @ 36Mbps • 151ft (46m) @ 24Mbps • 203ft (62m) @ 18Mbps •...
Page 186 Technical Speciﬁcations (continued) Transmit Output Power For 802.11b: • 63mW (18dBm) • 40mW (16dBm) • 32mW (15dBm) • 23mW (13dBm) • 10mW (10dBm) • 6mW (7dBm) • 1mW (0dBm) For 802.11g: • 63mW (18dBm) • 40mW (16dBm) • 32mW (15dBm) •...
Page 187 Technical Speciﬁcations (continued) LEDs • Power • 10M/100M • WLAN Temperature • Operating: 32ºF to 104ºF (0ºC to 40ºC) • Storing: -4ºF to 149ºF (-20ºC to 65ºC) Humidity • Operating: 10%~90% (non-condensing) • Storing: 5%~95% (non-condensing) Certiﬁcations • FCC Part 15 •...
Page 188: Contacting Technical Support
Technical Support You can ﬁnd software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our web site, or by phone.
Page 189: Warranty
Warranty Period from the date of original retail purchase. If a material defect is incapable of correction, or if D-Link determines in its sole discretion that it is not practical to repair or replace the defective Hardware, the price paid by the original purchaser for the defective Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware.
Page 190 Products shall be fully insured by the customer. D-Link will not be held responsible for any packages that are lost in transit to D-Link. The repaired or replaced packages will be shipped to the customer via UPS Ground or any common carrier selected by D-Link, with shipping charges prepaid. Expedited shipping is available if shipping charges are prepaid by the customer and upon request.
Page 191 Trademarks: D-Link is a registered trademark of D-Link Systems, Inc. Other trademarks or registered trademarks are the property of their respective manufacturers or owners.
Page 192: Registration
Registration Register your D-Link product online at http://support.dlink.com/register/ (5/12/05)

D-Link AirPremier DWL-2210AP Manual

Quick Links

Related Manuals for D-Link AirPremier DWL-2210AP

Summary of Contents for D-Link AirPremier DWL-2210AP

Table of Contents
