MultiLab 4010-3W
Display (example: pH measurement)
3
2
AutoCal TEC
1
HOLD AR
Info
Jack field /connections
Initial
commissioning
ba76196y01 11/2017
b a c
4
1 2 3 5
1 Connect the power pack.
2 Switch on the meter with the <On/Off> key.
Caution
Follow the safety instructions of the used sensors.
The operating manuals of the sensors are available on the supplied CD and on
the Internet under www.YSI.com.
4
1 Status information
2 Measured value (with unit)
3 Measured parameter
4 Continuous measurement control
(CMC function)
5
5 Sensor symbol
(calibration evaluation)
6
6 Measured temperature (with unit)
7
7 Softkeys and date/time
1 IDS sensors
(pH, U, conductivity, D.O.)
2 USB B interface (device)
3 ProOBOD
4 USB A interface (host)
5 Connection for line adaptor
6
6 Service interface
