STEP 5
Attach Panel(E),(D)to completed unit in
Step 4,as shown:
STEP 7
Attach Back Panel(F)to the assembled unit
using Power Pin(4).
Recommended Maximum Weight
15
15
15
*Unit in Pound(lbs)
STEP 6
Install Panel(D)to L/R Side Panel(A)using
Screw(1).
(1)x 4pcs
(4)x 16pcs
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Approx. 20 minutes
Approx. 15 minutes
Approx. 5 minutes
Recomm. 2 Person
Recomm. 1 Person
Tools Required
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Pasir 2 Tier Bookcase with
Door w/out Handle
11205
MODEL
:
DIMENSION :
15.8"(W) x 21.2"(H) x 9.4"(D)
1120520140418
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Furinno 11205
Summary of Contents for Furinno 11205
- Page 1 Attach Panel(E),(D)to completed unit in Install Panel(D)to L/R Side Panel(A)using Step 4,as shown: Screw(1). (1)x 4pcs its Space. its Budget Assembly Instruction Furinno Pasir 2 Tier Bookcase with Door w/out Handle 11205 MODEL DIMENSION : 15.8”(W) x 21.2”(H) x 9.4”(D) Approx. 15 minutes Approx.
- Page 2 STEP 1 STEP 2 Hardware List Parts List 1.1 Insert Screw(3B)and Door Support(2) Attach Top Panel(B)to L/R Side Panel(A) Screw 12pcs L/R Side Panel 2pcs on Panel(E). using Screw(1). 1.2 Insert Magnet(3A)on Panel(B),(C). Top Panel 1pcs Door Support 4pcs Note: 1)Enlarge pre-drilled hole with Screw Shelf Panel 1pcs before attach with Magnet(3).
