STEP 5
Attach Door Panel(E)and Bottom Panel(D)to
the completed unit in Step 4, as shown:
STEP 7
Attach Back Panel(F)to the unit using
Power Pin(6).
(6)x16pcs
Recommended Maximum Weight
10
10
10
*Unit in Pound(lbs)
STEP 6
Attach Shelf Panel(D)to L/R Side Panel(A)
using Screw(1).
(1)x4pcs
STEP 8
Attach Handle(4)on Door Panel(E)using Short
Screw(5).
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 20 minutes
Recomm. 2 Person
Tools Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Pasir 2 Tier Bookcase
w/2 Door w/Round Handle
11201
MODEL
:
DIMENSION :
15.8"(W) x 21.3"(H) x 9.4"(D)
1120120140429
