STEP 5
Attach Panel(H),(F),(E)to the completed
unit in Step 4 using Long Screw(1).
(1)x 4pcs
E
A
C
H
G
F
D
A
C
H
G
F
B
Recommended Maximum Weight
15
15
15
15
*Unit in Pound(lbs)
STEP 6
Attach Back Panel(I)to assembled unit
with Power Pin(6).
(6)x 22pcs
E
STEP 7
Attach Handle(4)on Door Panel using Short
Screw(5).
B
G
H
D
A
C
G
H
E
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Recomm.2 Person
Tools Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Pasir 4-Tier Shelf w/4 Door
w/Round Handle
11237
MODEL
:
DIMENSION :
23.6"(W) x 41.7"(H) x 9.4"(D)
1123720140417
