STEP 4
Attach Bottom Panel(D) to L/R Side
Panel(A)using Chipboard Screw(1).
STEP 5
Attach Back Panel(F)
with Power Pin(4).
Recommended Maximum Weight
20
20
*Unit in Pound(lbs)
（1)x 4pcs
(4)x 16pcs
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
Approx. 30 minutes
Recomm. 2 Person
Tools Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno Pasir 2 Tier Bookcase with
1 Door w/out Handle
11204
MODEL
:
DIMENSION :
15.8"(W) x 21.2"(H) x 9.4"(D)
1120420140423
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Furinno 11204
Summary of Contents for Furinno 11204
- Page 1 STEP 4 （1)x 4pcs Attach Bottom Panel(D) to L/R Side Panel(A)using Chipboard Screw(1). its Space. its Budget Assembly Instruction Furinno Pasir 2 Tier Bookcase with 1 Door w/out Handle 11204 MODEL DIMENSION : 15.8”(W) x 21.2”(H) x 9.4”(D) Approx. 30 minutes...
- Page 2 (3B)x1pcs STEP 1 Hardware List Parts List Insert Screw(3B)and Door Support(2) L/R Side Panel Chipboard Screw 2pcs 12pcs (3A)x1pcs into Door Panel(E). Insert Magnet(3A)into Shelf Panel(C). Top Panel 1pcs Door Support 2pcs Note: Metal Plate on Magnet(3A)should be Magnet/Screw Shelf Panel 1pcs 1pcs pointing outward.
