SportsPlay Quick Ship 3 Modified Installation Instructions Manual
  1. Manuals
  2. Brands
  3. SportsPlay Manuals
  4. Play Sets & Playground Equipment
  5. Quick Ship 3 Modified
  6. Installation instructions manual

SportsPlay Quick Ship 3 Modified Installation Instructions Manual

3.5 inch with bracket (no clamp)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
!
!
!"#$%&&%$!'"(!"#$)*+$!'"#(
,--./012."(
3*!+4(#5!2(6(7'8!9!:8(
6;0<(=!$5(>)%+4:$(?"'(+&%72@(
(
2ABCDB(EBCF(GHB(BIGJEB(KCILCA(MBNOEB(MBPJIIJIP(JIDGCAACGJOI;(

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quick Ship 3 Modified and is the answer not in the manual?

Questions and answers

Related Manuals for SportsPlay Quick Ship 3 Modified

Summary of Contents for SportsPlay Quick Ship 3 Modified

  • Page 1 !"#$%&&%$!'"(!"#$)*+$!'"#( ,--./012."( 3*!+4(#5!2(6(7'8!9!:8( 6;0<(=!$5(>)%+4:$(?"'(+&%72@( 2ABCDB(EBCF(GHB(BIGJEB(KCILCA(MBNOEB(MBPJIIJIP(JIDGCAACGJOI;(...
  • Page 3 Value Series Installation Guide TAB SECTION INDEX 1. 3D AND 2D DRAWINGS 2. INSTALLATION GUIDE 3. INSTALLATION STEPS 4. COMPONENT INSTALLATION 5. APPENDIX 6. ORIGINAL COMPONENT MAINTENANCE FORMS 7. COMPLETED COMPONENT MAINTENANCE FORMS 2/28/11 V-C_OUTLINE.V1.0211...
  • Page 5 Value Series Installation Guide Table of Contents HARDWARE DRAWINGS !"#"$%&'() *************************************************************************************** +! COMPONENT INSTALLATION INSTRUCTION SETS ,-.#"-&(#/'0& ******************************************************************************* 1! APPENDIX FINAL INSTALLATION STEPS 2--,'()#/'0&************************************************************************************ 3! .-4,#'"#/'0&************************************************************************************** 5! MAINTENANCE AND INSPECTION '6789:;<: ********************************************************************************************* =! &>?<#@8A9#9?B?CD?#@8A9#7E;@F98A<G ************************************************ = H?I89?#@8A#J?FC< ************************************************************************************** = 4;I?:@#4A9I;BC<F ********************************************************************************KL! ,88EM#;<G#N;:?9C;EM*************************************************************************KK! H02-$0#H0)'(('() ************************************************************************KO! 4',0#$0PQ'$0N0(,4****************************************************************************KO...
  • Page 7 QUICK SHIP 3 MODIFIED Installation Guide...
  • Page 9 Date Project: QS3_MOD 00-00-10 Size: 14' X 18' E. Barron 5642 Natural Bridge Drawing Number: #911-254 Use Zone: 26' X 30' 800-727-8180 CPSC: Compliant Distributor: SportsPlay Age Group: 2-12 Fax: 314-389-9034 ASTM: Compliant www.sportsplayinc.com Scale: 1:60 Sheet 1 of 1...
  • Page 11 Date Project: QS3_MOD 00-00-10 Size: 14' X 18' E. Barron 5642 Natural Bridge Drawing Number: #911-254 Use Zone: 26' X 30' 800-727-8180 CPSC: Compliant Distributor: SportsPlay Age Group: 2-12 Fax: 314-389-9034 ASTM: Compliant www.sportsplayinc.com Scale: 1:60 Sheet 1 of 1...
  • Page 13 Date Project: QS3_MOD 00-00-10 Size: 14' X 18' E. Barron 5642 Natural Bridge Drawing Number: #911-254 Use Zone: 26' X 30' 800-727-8180 CPSC: Compliant Distributor: SportsPlay Age Group: 2-12 Fax: 314-389-9034 ASTM: Compliant www.sportsplayinc.com Scale: 1:60 Sheet 1 of 1...
  • Page 15 Evaluate the site for drainage. To ensure good drainage around the • storage is required you must store the equipment in a controlled equipment consult a local professional. environment away from heat, moisture and sunlight. SportsPlay recommends carefully unpacking the unit and taking an inventory before 2/28/11 V-C_OUTLINE.V1.0211...
  • Page 16 SportsPlay Equipment inc. has provided two warning labels that state: • “WARNING – Installation over a hard surface such as concrete, asphalt or packed earth may result in serious injury or death from falls.”...
  • Page 17 100 Bar harbor drive West Conshohocken PA, 19428-2959 Because accidental falls are likely to occur around play equipment, SportsPlay Equipment Inc. recommends that a resilient safety surfacing that will meet standard ASTM F1292 be placed under and around the structure and extend Call –...
  • Page 18 Value Series Installation Guide Tools and Materials Drills (1/2” and 3/8”) • List is for tools and materials needed that are not included with the Drill bits and spade bits • playground Levels – Magnetic torpedo and 4’ long levels •...
  • Page 19 All SportsPlay Equipment play events have been engineered to meet all The use zone for this equipment shall extend a minimum of 6’ in all directions applicable safety guidelines, but if installed from the perimeter of the equipment.
  • Page 20 Value Series Installation Guide The use zone for adjacent stationary equipment may overlap. If the deck height for that equipment is no more than 30” above the protective surfacing the use zone is 6’. The use zone for adjacent stationary equipment may overlap. If the deck height for that equipment is more than 30”...
  • Page 21 Value Series Installation Guide Installation Punch List Footing Layout Example 2/28/11 V-C_OUTLINE.V1.0211...
  • Page 22 Value Series Installation Guide Step 1: Layout Once the decks are in the desired location within the play area and the decks are flush with each other, mark the locations of the post by inserting a stake into the center of each post location (see drawing below Lay decks on ground in the desired location using the top view layout drawing.
  • Page 23 Value Series Installation Guide FOOTING SIDE VIEW Step 3: Deck, Post & Component Installation The easiest way to install the playground is by starting with the central deck and then work out. We recommend installing the posts and central deck and once the post and deck are square and level you may add the concrete (concrete with a minimum of 2,500 psi should be used).
  • Page 24 Secure playground area to prevent access while the concrete is setting for a minimum of 48 hours. SportsPlay recommends having a CPSI (certified playground safety inspector) present during installation. If that’s not possible you should have the completed playground (after surfacing is in place) inspected by a CPSI.
  • Page 25 Value Series Installation Guide Four Hole Bracket & Panel Bracket Installation FOUR HOLE Tip for installation ATTACHMENT Use the #7 drill bit to pre-drill all holes when connecting the bracket • BRACKET to the post if you are having trouble with the self-tapping screws Installation Always install the brackets with the set screw facing down (refer to •...
  • Page 26 Value Series Installation Guide Direct Bolt Deck While two people position and hold the deck in place, insert the deck bolt and washer through the deck and into the factory installed nut on the post. To ensure proper placement, refer to the layout drawing and the post id drawing at the beginning of this guide.
  • Page 27 Value Series Installation Guide Other Installation Tips When attaching a deck to a post sometimes the factory installed nuts • will spin when tightening the bolt. If this happens simply slide a slim flathead screw driver in between the deck and the post and slightly pry on the installed nut to keep it from spinning.
  • Page 28 Value Series Installation Guide Loose clothing, hoods, strings or jewelry shall be tight or not worn SUPERVISION GUIDE while playing to prevent strangulation. Although the equipment is designed, installed and maintained in accordance with Ensure the temperature of the equipment is not hazardous. Direct all safety guidelines adult supervision is required.
  • Page 30 Value Series Installation Guide COMPONENT INSTALLATION INSTRUCTIONS 2/28/11 V-C_OUTLINE.V1.0211...

  • Page 32: Installation Details

    912-242 SQUARE DECK 46” INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 3  Installation time: 15 min (.75 man hr)  User age: 2-12  Use zone: 72”  Weight: 79 SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.

  • Page 33: Parts List

    912-242 SQUARE DECK 46” INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION Square Deck 46” 913-242 3/8”x1 1/2” Button Head Bolt 126-707BPS 3/8” Flat Washer 316-601 NOTE: Keep a copy of these instructions on file to assist you with maintenance and replacement parts. March 10, 2014...
  • Page 34 912-242 SQUARE DECK 46” INSTALLATION INSTRUCTION March 10, 2014...

  • Page 35: Specifications

    912-242 SQUARE DECK 46” INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING  Deck-12 GA HRPO steel  Should the factory installed nuts on the posts start spinning while trying to attach the decks, simply insert a flat head  Hardware – Stainless steel & tamper resistant screw driver under the lip or the nut and tighten the bolt.

  • Page 36: Before You Begin

    912-242 SQUARE DECK 46” INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a level and blocking material. INSTALLATION STEPS __1) Review all instructions before beginning __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.
  • Page 37 912-242 SQUARE DECK 46” INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __6) Once the concrete has set, back fill dirt over the footing holes; inspect the area and components for tools, hazardous debris and sharp edges. Verify all components are installed and all hardware is tight and then install the safety surfacing.
  • Page 38 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 1.5 hr (3 man hrs)  User age: 2-12  Use zone: 72” from all edges of deck  Weight: 165 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 39 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 3’ Transfer Station Stairs 923-206 923-211 Transfer Station Platform 923-210 Transfer Station Step 923-209 Transfer Station Cover Plate 923-208 Transfer Station Support Post 913-230 Transfer Point Inside Leg 913-426 Transfer Point Handhold Post Transfer Point Handrail Left 3’...
  • Page 40 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION FOOTING INFORMATION  Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
  • Page 41 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION March 13, 2014...
  • Page 42 INSTALLATION TIPS & TROUBLE SHOOTING  Deck and Steps-12 GA HRPO steel  SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a  Deck & Step Coating – Electrostatically applied & oven number #7 drill bit.
  • Page 43 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a level, blocking material, 9/16 wrench, shovel, tape measure and a post hole digger. INSTALLATION STEPS __1) Review all instructions before beginning __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.
  • Page 44 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __6) Install Handrails And Inside step Legs: You will need both the Left (8) and Right (9) Handrails, two Inside Step Legs, four 3/8”x 2 ½” Button Head Bolts, eight 3/8” Flat Washers, four 3/8” Locknuts, two Four Hole Attachment Brackets (15), two Gaskets for Attachment Brackets (16), eight Self tapping Screws (17), and two 3/8”x 3/8”...
  • Page 45 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED Detail D __7) Install Transfer Station Platform: This will install to the bottom part of the Transfer Station Stairs. To do this you will need the Transfer Station Platform (2), Transfer Station Cover Plate (4), Transfer Station Support Post (5), Transfer Point Handhold Post(7), four 3/8”x 1”...
  • Page 46 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __8) Install the Transfer Station Step: To complete this step you will need the Transfer Station step (3), two Transfer Point Inside Legs (6), three 3/8”x 1” Button Head Bolts (10), two 3/8”x 1 ¼” Button Head Bolts (11), ten 3/8”...
  • Page 47 922-135 3’ TRANSFER STATION INSTALLATION INSTRUCTION __10) Once the concrete has set, back fill dirt over the footing holes; inspect the area and components for tools, hazardous debris and sharp edges. Verify all components are installed and all hardware is tight and then install the safety surfacing. __11) Inspect the components: for sharp edges and if necessary file them down and apply touch up paint.
  • Page 48 922-120-3 CORKSCREW 3’ DECK INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 1 hr (2 man hrs)  User age: 2-12  Use zone: 72 in. in front of climber  72 in to right and left of climber ...
  • Page 49 922-120-3 CORKSCREW 3’ DECK INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION Corkscrew 3’ deck 913-443 913-402 Four-Hole Attachment Bracket 905-208 Attachment Bracket Gasket 905-526 Self-Tapping Screw 3/8”x3/8” Set Screw 196-807 3/8”x1” Button Head Bolt 126-703 3/8” Flat Washer 316-601 3/8” Lock Nut 226-602 5/16”x1 ¾”...
  • Page 50 922-120-3 CORKSCREW 3’ DECK INSTALLATION INSTRUCTION FOOTING INFORMATION  Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you were using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to the cutaway view to the right).
  • Page 51 922-120-3 CORKSCREW 3’ DECK INSTALLATION INSTRUCTION March 11, 2014...
  • Page 52 INSTALLATION TIPS & TROUBLE SHOOTING  Paint – Electrostatically applied & oven cured powder coat  SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a  Hardware – Stainless steel & tamper resistant number #7 drill bit.
  • Page 53 922-120-3 CORKSCREW 3’ DECK INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a shovel or post hole digger, cement, drill, and a level. INSTALLATION STEPS __1) Review all instructions before beginning __2) Unpack, organize and identify, all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.
  • Page 54 922-120-3 CORKSCREW 3’ DECK INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __5) Connect four hole brackets to posts: Now you need to install the Four Hole Brackets to the posts. The top of the barrier, NOT THE ARCH, should be 38” from the surface of the deck to the top of the barrier.
  • Page 55 922-120-3 CORKSCREW 3’ DECK INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __8) Install the Corkscrew climber: Place the Corkscrew Climber over the stub on the Arch Wall and secure it with the 5/16” x 1 ¾” Button Head Bolt (9), 5/16” Button Head Nut (10), and 5/16” Lock Washer (11).
  • Page 56 922-126-3 (3’) TRIPLE RAIL SLIDE INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 2 Hours (4 man hours)  User age: 2-12 Years  Use zone: 6’ on all sides  Weight: 92lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 57 922-126-3 (3’) TRIPLE RAIL SLIDE INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION Triple Rail Slide 3’ Deck 435-612 923-330 Triple Rail Slide Guard 903-214 Slide Legs 913-402 4 Hole Attachment Bracket 905-208 Attachment Bracket Gasket 905-526 Self Tapping Screws 3/8x1” Button Head Bolt 126-703 3/8”...
  • Page 58 922-126-3 (3’) TRIPLE RAIL SLIDE INSTALLATION INSTRUCTION FOOTING INFORMATION  You must place the bottom of the support post or slide leg on a suitable flat blocking material to prevent it from sinking further into the soil. We recommend you use a brick, block of wood or several inches of gravel.
  • Page 59 922-126-3 (3’) TRIPLE RAIL SLIDE INSTALLATION INSTRUCTION March 10, 2014...
  • Page 60 INSTALLATION TIPS & TROUBLE SHOOTING  Slide – 3/8” walled rotationally molded LLDPE  SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a  Paint – Electro statically applied & oven cured powder coat number #7 drill bit.
  • Page 61 (Footing depth is 24” less the amount of surfacing used plus the thickness of the blocking material). SportsPlay recommends setting the slide up to the deck and using the slide to mark the position of the slide legs to establish the location of the required footing.
  • Page 62 922-126-3 (3’) TRIPLE RAIL SLIDE INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED Detail C __5. Attach slide legs (3) to the bottom of the slide by inserting a 3/8” x ¾” bolt (9) and 3/8 washer (8) through the plate on the slide leg (3) and into the factory installed nut on the underneath the exit end of the slide (Detail B).
  • Page 63 922-126-3 (3’) TRIPLE RAIL SLIDE INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED INSTALLATION STEPS CONTINUED TIP: It’s easier to install the self tapping screws if you pre drill __9. Insert the 3/8 x 3/8 socket set screws (#10) into the threaded the holes in the post with a #7 drill bit by marking the hole hole on the bottom side of the four-hole attachment brackets (#4) locations with a dry erase marker after you have put the guard and tighten (Detail C on page 7).
  • Page 64 922-127-3 (3’) DOUBLE WALL STRAIGHT SLIDE INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew: 2  Installation time: 2 Hours (4 man hours)  User age: 2-12 Years  Use zone: 6’ on all sides  Weight: 3’ Slide 902-213 – 78 lbs. SURFACING: Use of safety surfacing in compliance with the current ASTM specification F1292 is required.
  • Page 65 922-127-3 (3’) DOUBLE WALL STRAIGHT SLIDE INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 3’ 435-600 Double Wall Slide 923-200 Slide Guard 903-214 Slide Leg 913-402 Four Hole Attachment Bracket 905-208 Gasket for Attachment Bracket ¼” Self Tapping Pinned Screw 905-526 126-706 3/8 x 1 3/4 Button Head Bolt 316-601...
  • Page 66 922-127-3 (3’) DOUBLE WALL STRAIGHT SLIDE INSTALLATION INSTRUCTION FOOTING INFORMATION  You must place the bottom of the support post or slide leg on a suitable flat blocking material to prevent it from sinking further into the soil. We recommend you use a brick, block of wood or several inches of gravel.
  • Page 67 922-127-3 (3’) DOUBLE WALL STRAIGHT SLIDE INSTALLATION INSTRUCTION ELEVATION AND FOOTING LAYOUT March 13, 2014...
  • Page 68 INSTALLATION TIPS & TROUBLE SHOOTING  Slide – 3/8” walled rotationally molded LLDPE  SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a  Paint – Electrostatically applied & oven cured powdercoat number #7 drill bit.
  • Page 69 (Footing depth is 24” less the amount of surfacing used plus the thickness of the blocking material). SportsPlay recommends setting the slide up to the deck and using the slide to mark the position of the slide legs to establish the location of the required footing.
  • Page 70 922-127-3 (3’) DOUBLE WALL STRAIGHT SLIDE INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __5. With help, place the slide legs into the footing holes and attach the slide to the playground deck. __6. Using the 3/8 x 1 ¾ bolts (#7) and 3/8 washers (#8) attach the slide to the deck by inserting the bolts and washers through the holes in the deck and into the factory installed nuts at the entrance to the slide (Detail A on page 6).
  • Page 71 922-127-3 (3’) DOUBLE WALL STRAIGHT SLIDE INSTALLATION INSTRUCTION INSTALLATION INSTRUCTIONS CONTINUED __9. Insert the 3/8 x 3/8 socket set screws (#10) into the threaded hole on the bottom side of the four-hole attachment brackets (#4) and tighten (Detail C on page 7). __10.
  • Page 72 912-807 SAND & WATER PANEL INSTALLATION INSTRUCTION INSTALLATION DETAILS ! Recommended crew (Adult): 2 ! Installation time: ! User age: ! Use zone: ! Weight: 912-807 – 76lbs. SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required. MAINTENANCE: ! As the owner of the playground you are responsible for maintenance of the equipment and play area.
  • Page 73 912-807 SAND & WATER PANEL INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 903-225 Sand & Water Panel 903-229 Bubble Basin 435-810 12” Acrylic Dome 903-816 1” Leg Support 913-417 Panel Attachment Bracket 905-208 Gasket for Attachment Bracket 905-526 Self Tapping Screws 905-803 Corner Bracket 316-501...
  • Page 74 912-807 SAND & WATER PANEL INSTALLATION INSTRUCTION FOOTING INFORMATION ! Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material.
  • Page 75 912-807 SAND & WATER PANEL INSTALLATION INSTRUCTION February 17, 2010...
  • Page 76 INSTALLATION INSTRUCTION INSTALLATION TIPS & TROUBLE SHOOTING SPECIFICATIONS ! SportsPlay Equipment Inc. recommends pre-drilling the ! Panel- "” HDPE UV stabilized plastic holes in the post when attaching a four-hole bracket with a number #7 drill bit. This will make the attachment of the ! Hardware –...
  • Page 77 912-807 SAND & WATER PANEL INSTALLATION INSTRUCTION INSTALLATION STEPS __1) You will need to assemble the panel first. To do this you will need the panel (1) and bubble basin (2), three Corner Brackets (8), six 5/16” Washers (9), six 5/16”x3/4” Button Head Bolt (10), six 5/16”x1”...
  • Page 78 912-807 SAND & WATER PANEL INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __4) Install panel to attachment brackets: Once you have all 4 of the panel attachment brackets installed. Locate the panel, with a helper lift the panel into place and mark the holes in the tab of the panel attachment bracket on the panel.
  • Page 79 912-807 SAND & WATER PANEL INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __7) Install the Acrylic Domes in Bubble Basin To complete this step you will need the two 12” acrylic domes with the drain assemblies installed in the previous step. You will also need sixteen 3/8”...
  • Page 80 922-112 BUBBLE WINDOW INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 1  Installation time: 30 min (1 man hrs)  User age: 2-12  Use zone: NA  Weight: 22 SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required. MAINTENANCE: ...
  • Page 81 922-112 BUBBLE WINDOW INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 435-665 Bubble Window 913-402 Four-Hole Attachment Bracket 905-208 Attachment Bracket Gasket 905-526 Self-Tapping Screw 3/8”x3/8” Set Screw 196-807 NOTE: Keep a copy of these instructions on file to assist you with maintenance and replacement parts.
  • Page 82 INSTALLATION TIPS & TROUBLE SHOOTING  Paint – Electrostatically applied & oven cured powder coat  SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a  Hardware – Stainless steel & tamper resistant number #7 drill bit.

  • Page 83: Before You Begin

    922-112 BUBBLE WINDOW INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a drill with a #7 drill bit, tape measure, and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning: __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.
  • Page 84 922-112 BUBBLE WINDOW INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __5) Secure the Bubble Window to the Attachment Bracket: Install and tighten the 3/8” x 3/8” Set Screw (5) in the Four-Hole Bracket. (See detail A) __6) Center the Bubble Window Panel: You will now need to center the Bubble Window between the posts.
  • Page 85 922-112 BUBBLE WINDOW INSTALLATION INSTRUCTION THIS PAGE WAS INTENTIONALLY LEFT BLANK May 1, 2014...
  • Page 86 922-121-W GUARD WALL WITH WHEEL INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 1  Installation time: 30 min (.5 man hrs)  User age: 2-12  Use zone: NA  Weight: 31 SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 87 922-121-W GUARD WALL WITH WHEEL INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 923-121-W Guard Wall With Wheel 913-402 Four-Hole Attachment Bracket 905-208 Attachment Bracket Gasket 905-526 Self-Tapping Screw 3/8”x3/8” Set Screw 196-807 3/8”x1” Button Head Bolt 126-703 3/8” Flat Washer 316-601 3/8”...
  • Page 88 INSTALLATION TIPS & TROUBLE SHOOTING  Paint – Electrostatically applied & oven cured powder coat  SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a  Hardware – Stainless steel & tamper resistant number #7 drill bit.
  • Page 89 922-121-W GUARD WALL WITH WHEEL INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a drill with a #7 drill bit, tape measure, 7/32” Allen Wrench, 9/16” wrench and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning: __2) Unpack, organize, and identify all components: Be sure to...
  • Page 90 922-121-W GUARD WALL WITH WHEEL INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED 5) Connect Four-Hole brackets to posts: Now you need to install the Four-Hole Brackets to the posts. The top of the, Guard Wall with Wheel should be 38” from the surface of the deck to the top of the panel.
  • Page 91 922-121-W GUARD WALL WITH WHEEL INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __8) Inspect the components: for sharp edges and if necessary file them down and apply touch up paint. DETAIL C March 10, 2014...
  • Page 92 922-175-T TIC TAC TOE PANEL BELOW DECK INSTALLATION INSTRUCTION INSTALLATION DETAILS ! Recommended crew (Adult): 2 ! Installation time: 30 min (1 man hr) ! User age: 2-12 years ! Use zone: 72” in all directions ! Weight: 36 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 93 922-175-T TIC TAC TOE PANEL BELOW DECK INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 923-175-f Tic Tac Toe frame below deck 913-402 Four-Hole Attachment Bracket 905-208 Attachment Bracket Gasket 905-526 Self-Tapping Screw 196-807 3/8”x3/8” Set Screw NOTE: Keep a copy of these instructions on file to assist you with maintenance and replacement parts.

  • Page 94: Installation Instruction

    INSTALLATION INSTRUCTION INSTALLATION TIPS & TROUBLE SHOOTING SPECIFICATIONS ! SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a ! Tube – FloCoat® Galvanized 1 3/8” O.D. and 1” O.D. number #7 drill bit. This will make the attachment of the ! Hardware –...
  • Page 95 922-175-T TIC TAC TOE PANEL BELOW DECK INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, drill with a #7 bit and a 7/32 wrench. INSTALLATION STEPS __1) Review all instructions before beginning: __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.
  • Page 96 922-175-T TIC TAC TOE PANEL BELOW DECK INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __6) Secure the Panel to the Attachment Brackets: Install and tighten the 3/8 x 3/8” Set Screw (5) in the Four-Hole Bracket. (See detail A) __7) Inspect the components: for sharp edges and if necessary file them down and apply touch up paint.
  • Page 97 922-175-T TIC TAC TOE PANEL BELOW DECK INSTALLATION INSTRUCTION THIS PAGE WAS INTENTIONALLY LEFT BLANK February 17, 2010...
  • Page 98 912-275 PYRAMID ROOF INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 1 hr (2 man hrs)  User age: 2-12  Use zone: NA  Weight: 92 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 99 912-275 PYRAMID ROOF INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 435-635 Pyramid Roof 913-430 Roof Bracket 516-200 Zip Togglers 3/8” x 2” Button Head Bolts 116-608 3/8” flat Washers 316-601 905-526 Self Tapping Screws NOTE: Keep a copy of these instructions on file to assist you with maintenance and replacement parts.
  • Page 100 INSTALLATION TIPS & TROUBLE SHOOTING  Paint – Electrostatically applied & oven cured powder coat  SportsPlay Equipment Inc. recommends pre-drilling the holes in the post when attaching a four-hole bracket with a  Hardware – Stainless steel & tamper resistant number #7 drill bit.
  • Page 101 912-275 PYRAMID ROOF INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a drill and 3/4” drill bit, tape measure, marker, and a ladder. INSTALLATION STEPS __1) Review all instructions before beginning: __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.
  • Page 102 912-275 PYRAMID ROOF INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __6) Drill holes into the Pyramid Roof: Rotate the Pyramid Roof to allow access to the marks you made in the previous step. Drill each of the eight marks with the 3/4” drill bit. Install a Zip Toggler (3) into each of the holes.
  • Page 103 912-275 PYRAMID ROOF INSTALLATION INSTRUCTION THIS PAGE WAS INTENTIONALLY LEFT BLANK April 30, 2014...
  • Page 104 VALUE SERIES INSTALLATION APPENDIX INSTALLATION APPENDIX 4/2/10 M-C_APPENDIX.V1.0410...

  • Page 106: Final Installation Steps

    VALUE SERIES INSTALLATION APPENDIX Loose fill surfacing material must be maintained at the required depth within the use zone. Loose fill material must be replaced FINAL INSTALLATION STEPS or added as necessary to maintain its resilient properties. __1. Once the entire playground has been assembled level and square each post, deck and component.

  • Page 107: Label Installation

    VALUE SERIES INSTALLATION APPENDIX LABEL INSTALLATION SportsPlay Equipment Inc. has included multiple labels that must be installed on the playground structure as recommended by ASTM. There are four different labels that, as the owner you are required to install and maintain. If a label becomes damaged please contact your distributor for replacement.

  • Page 108: Maintenance And Inspection Procedures

    The component maintenance sheets and a general inspection SportsPlay Equipment does not manufacture surfacing and checklist are included in the next section of this booklet and as is only providing this information on surfacing as a guide the owner it is your responsibility to ensure that you have a for safety.
  • Page 109 The first form is the General Inspection checklist. This form will cover the basic inspection of the play equipment and area. SportsPlay recommends performing this inspection daily as it covers basic safety of the equipment and area. Documenting this inspection is up to you but you can simply laminate a copy and mark each item with a dry erase marker before allowing access to the area.
  • Page 110 VALUE SERIES INSTALLATION APPENDIX ORIGINAL INSPECTION AND MAINTENANCE FORMS 4/2/10 M-C_APPENDIX.V1.0410...
  • Page 112 VALUE SERIES INSTALLATION APPENDIX ___No loose or missing hardware GENERAL INSPECTION CHECKLIST ___Moving parts (example: swings) are not worn ___Adequate surfacing under and around ___Swing chains are not looped over the top bar of the swing equipment ___Surfacing material is in good condition ___There are no modifications to the playground ___Ensure surfacing materials are not compacted (rake and ___No strings or rope tied to the equipment...
  • Page 113 • You will perform this inspection when performing your component inspections Replacement Parts • Contact your distributor to order new labels. If unable to contact distributor please call SportsPlay Equipment for replacements: 1- 314-389-4140 • Before calling be sure to identify the proper part, part number and quantity needed •...
  • Page 114 GENERAL FOOTING MAINTENANCE Footings • Move surfacing (if loose fill) to expose the footing • Inspect concrete for cracks or loose supports o If cracked footings or loose supports are found you must excavate the soil around the concrete, remove the concrete and pour a new footing •...
  • Page 115 GENERAL FOOTING MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED. ! INCLUDE DATES AND SIGNATURES Inspection Checklist Recommended...
  • Page 116 If any of the labels are worn or • missing order replacements Replacement Parts ! Contact your distributor to order new labels. If unable to contact distributor please call SportsPlay Equipment for replacements: 1-314-389-4140 February 17, 2010...
  • Page 117 LABEL MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED. ! INCLUDE DATES AND SIGNATURES Inspection Checklist Recommended...
  • Page 118 • ! Contact your distributor to order the concrete footing new labels. If unable to contact o Review the footing maintenance distributor please call SportsPlay document for repair procedure Equipment for replacements: should you discover a post is not 1-314-389-4140...
  • Page 119 POST MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED. ! INCLUDE DATES AND SIGNATURES Inspection Checklist Recommended...
  • Page 120 Contact distributor of color matching paint. Contact Distributor for Thermoplastic repair kit. ! Order new hardware from SportsPlay Equipment Inc. Surfacing - Refer to the surfacing maintenance sheet. Replacement Parts ! Reference the parts list on page 2 of the instruction set for this component to identify the part/s correctly.
  • Page 121 922-177 SQUARE DECK EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED. ! INCLUDE DATES AND SIGNATURES Inspection Checklist Recommended...
  • Page 122 Block off access to equipment if necessary. ! Order new hardware from SportsPlay Equipment Inc. Welds ! Inspect all welds for cracks. If a crack is found Surfacing - Refer to the surfacing maintenance sheet.
  • Page 123 922-135 3’ TRANSFER STATION EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.
  • Page 124 922-120-3 (3’) CORKSCREW CLIMBER EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. If a crack is found panel clamps. block access to the playground and contact your ! Ensure the setscrews are tight and distributor for replacement parts immediately.
  • Page 125 922-120-3 (3’) CORKSCREW CLIMBER EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.
  • Page 126 922-124 (3’) TRIPLE RAIL SLIDE EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. If a crack is found panel clamps. block access to the playground and contact your ! Ensure the setscrews are tight and distributor for replacement parts immediately.
  • Page 127 922-124 (3’) TRIPLE RAIL SLIDE EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.
  • Page 128 922-127-3 DOUBLE WALL SLIDE EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. Block access to the panel clamps. playground and contact your distributor for ! Ensure the setscrews are tight and replacement parts immediately. in place.
  • Page 129 922-127-3 DOUBLE WALL SLIDE EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.
  • Page 130 912-807 SAND & WATER PANEL EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. If a crack is found panel clamps. block access to the playground and contact your ! Ensure the setscrews are tight and distributor for replacement parts immediately.
  • Page 131 912-807 SAND & WATER PANEL EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.
  • Page 132 922-112 BUBBLE WINDOW PANEL EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. If a crack is found panel clamps. block access to the playground and contact your ! Ensure the setscrews are tight and distributor for replacement parts immediately.
  • Page 133 922-112 BUBBLE WINDOW PANEL EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.

  • Page 134: Equipment Maintenance

    922-121-W GUARD WALL WITH WHEEL PANEL EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. If a crack is found panel clamps. block access to the playground and contact your ! Ensure the setscrews are tight and distributor for replacement parts immediately.
  • Page 135 922-121-W GUARD WALL WITH WHEEL PANEL EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.
  • Page 136 922-175-T TIC TAC TOE PANEL (BELOW DECK) EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. If a crack is found panel clamps. block access to the playground and contact your ! Ensure the setscrews are tight and distributor for replacement parts immediately.
  • Page 137 922-175-T TIC TAC TOE PANEL (BELOW DECK) EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED.
  • Page 138 922-275 PYRAMID ROOF EQUIPMENT MAINTENANCE Brackets Welds ! Inspect all four-hole clamps and ! Inspect all welds for cracks. If a crack is found panel clamps. block access to the playground and contact your ! Ensure the setscrews are tight and distributor for replacement parts immediately.
  • Page 139 922-275 PYRAMID ROOF EQUIPMENT MAINTENANCE INSPECTION FORM ! MAKE COPIES OF THIS FORM TO USE FOR INSPECTION ! REVIEW THE “MAINTENANCE GUIDE” IN THE APPENDIX TO BETTER UNDERSTAND THE IMPORTANCE OF MAINTENANCE AND HOW TO DEVELOP A MAINTENANCE SCHEDULE. ! DOCUMENT ALL MAINTENANCE ACTIONS ON THE LIST AS WELL AS ANY NOT LISTED. ! INCLUDE DATES AND SIGNATURES Inspection Checklist Recommended...
  • Page 140 VALUE SERIES INSTALLATION APPENDIX COMPLETED INSPECTION AND MAINTENANCE FORMS 4/2/10 M-C_APPENDIX.V1.0410...
