382-404H WHEELCHAIR SWING
Installation Guide
INSTALLATION INSTRUCTIONS
382-404H
ACCESSIBLE WHEELCHAIR SWING
Please read the entire manual before beginning installation.
3 CTN
7 PIPE
2 WF
12 TOTAL PCS
234# WEIGHT
CLASS 70
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 382-404H and is the answer not in the manual?

Questions and answers

Related Manuals for SportsPlay 382-404H

Summary of Contents for SportsPlay 382-404H

  • Page 1 382-404H WHEELCHAIR SWING Installation Guide INSTALLATION INSTRUCTIONS 382-404H ACCESSIBLE WHEELCHAIR SWING Please read the entire manual before beginning installation. 3 CTN 7 PIPE 2 WF 12 TOTAL PCS 234# WEIGHT CLASS 70...
  • Page 2 382-404H WHEELCHAIR SWING Installation Guide...
  • Page 3 382-404H WHEELCHAIR SWING Installation Guide...
  • Page 4 This equipment has been designed for use under STRICT CONTROL BY AN environment away from heat, moisture and sunlight. SportsPlay ADULT. This Equipment does not meet the standards set by ASTM and is recommends carefully unpacking the unit and taking an inventory before designed to allow people who are bound to a wheelchair so swing.
  • Page 5 382-404H WHEELCHAIR SWING Installation Guide Before you begin Review your swing footing and top view drawings to ensure your site is large enough. Read through the entire instruction booklet before beginning the actual installation. Before you begin preparing the site or digging any holes you must first contact you local utility companies so they can visit the site and mark all of the buried utilities.
  • Page 6 100 Bar harbor drive West Conshohocken PA, 19428-2959 Because accidental falls are likely to occur around play equipment, SportsPlay Equipment Inc. recommends that a resilient safety surfacing that will meet standard ASTM F1292 be placed under and around the structure and extend Call –...
  • Page 7 382-404H WHEELCHAIR SWING Installation Guide Tools and Materials Files and sand paper List is for tools and materials needed that are not included with the Safety surfacing playground Spray paint to mark holes Follow manufacturer’s guidelines for proper use of tools and materials.
  • Page 8 All SportsPlay Equipment play events have been engineered to meet all applicable safety guidelines, but if installed improperly, these problems may occur:...
  • Page 9 382-404H WHEELCHAIR SWING Installation Guide FOOTING SIDE VIEW Step 1: Layout Lay structure in the desired location using the top view layout drawing. Measure from each post to ensure there is adequate space for any component and the components fall zone. This drawing is a standard drawing and does not represent the actual playground you are installing.
  • Page 10 382-404H WHEELCHAIR SWING Installation Guide SportsPlay recommends having a CPSI (certified playground safety Step 3: Post & Component Installation inspector) present during installation. If that’s not possible you should have the completed playground (after surfacing is in place) inspected by We recommend installing the posts once the post are square and level a CPSI.
  • Page 11 382-404H WHEELCHAIR SWING Installation Guide Other Installation Tips If you are mocking up components with the intention of removing the hardware at some point, you may want to apply lubricating oil to the hardware. Stainless steel hardware has a tendency to seize so if you are planning on removing the hardware you may want to apply lubricant to prevent this.
  • Page 12 382-404H WHEELCHAIR SWING Installation Guide  Make sure there are no unsafe modifications (especially ropes tied to SUPERVISION GUIDE equipment). Remove all unsafe modifications and close the equipment for play until they are removed. This equipment has been designed for use under STRICT CONTROL BY AN ...
  • Page 13 382-404H WHEELCHAIR SWING Installation Guide Once the is unsnapped of removed, then the front entry platform must be unsnapped from the chain assembly and pulled down. Once the front platform/chain assembly is pulled down, the wheelchair should be placed or rolled onto the platform (Handles facing short platform).
  • Page 14 382-404H WHEELCHAIR SWING Installation Guide ½ X ½ SET 3/16 ALLEN WRENCH (YELLOW BAG) SCREW D-SHACKLE 2 3/8” SWING HANGER ¼ ALLEN WRENCH (BLUE BAG) 5/16 LOCK 5/16 X 1 BUTTON WASHER HEAD NUT 5/16 X 2 ½ BUTTON 5/16 ALLEN WRENCH (RED BAG)
  • Page 15 382-404H WHEELCHAIR SWING Installation Guide COMPONENT INSTALLATION INSTRUCTIONS...

  • Page 16: Installation Details

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 4 hr  User age: 5-12  Use zone: 0’ x 0’  Weight: 123 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.

  • Page 17: Parts List

    226-402 ¼” Lock Nut 342-506 D - Shackle 416-500BPK 5/16” Socket Key 805-532 Warning Label 805-534 SportsPlay Label 516-400 Locktite NOTE: Keep a copy of these instructions on file to assist you with maintenance and replacement parts. March 2, 2016...
  • Page 18 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION Note: The swing hanger’s pivot point to the ground should be 91” which will result an approximate 4” distance from the bottom of the platform to the ground. March 2, 2016...

  • Page 19: Installation Instruction

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING  Hardware – Stainless steel & tamper resistant  Do not tighten bolts all the way until the unit is completely assembled and all components are square and level. ...

  • Page 20: Before You Begin

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning: __2) Unpack, organize, and identify all components: Be sure to place all painted components on a protective surface (cardboard, cloth, etc…) to prevent damage.

  • Page 21: Operational Instructions

    382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Front and Back Restrain Chain: To do this all you have to do is use the swivel snaps and hooks it to the D- Shackle. The small restrain chain goes in back and the long for the front.
  • Page 22 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION OPERATIONAL INSTRUCTION CONTIUDE __6) The front platform/chain assembly should be pushed back into its original position and snapped back on the chain assembly of the platform with the swivel snaps. __7) Finally, the long restraining chain should be placed or snapped back onto the chain assembly by using the swivel snaps.
  • Page 23 382-408 HD WHEELCHAIR SWING PLATFORM INSTALLATION INSTRUCTION This equipment has been designed for use under STRICT CONTROL BY AN ADULT. This Equipment does not meet the standards set by ASTM and is designed to allow people who are bound to a wheelchair to swing. This unit can cause serious injury if used in an un-supervised area where other children are playing.
  • Page 24 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION DETAILS  Recommended crew (Adult): 2  Installation time: 4 hr  User age: 5-12  Use zone: 20’ x 32’  Weight: 234 lbs SURFACING: Use of safety surfacing in compliance with ASTM specification F1292 is required.
  • Page 25 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION PARTS LIST PART # DESCRIPTION 383-511 Swing End 1 7/8” x 8’ Pipe 383-221 2 3/8” x 4’ Pipe 383-220 1 7/8” x 8’ Pipe 503-612 1 7/8” T-Clamp (pair) 425-517 2 3/8” Swing Hanger...
  • Page 26 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION FOOTING INFORMATION  Total footing depth is 24” less the height of the surfacing plus the height of the blocking material. If you are using 12” of surfacing the footing hole would need to be 12” plus the height of the blocking material (refer to both the side and front cutaway views to the right).
  • Page 27 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION ELEVATION AND FOOTING LAYOUT VIEW March 2, 2016...
  • Page 28 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION SPECIFICATIONS INSTALLATION TIPS & TROUBLE SHOOTING  Apply locktite to all bolts during assembly prior to  Tube – FloCoat® Galvanized 1 7/8” O.D. and 2 3/8” O.D. completely tightening them.  Hardware – Stainless steel & tamper resistant ...
  • Page 29 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION BEFORE YOU BEGIN In addition to the components on the packing list you will need a tape measure, post hole digger, level and a dry erase marker. INSTALLATION STEPS __1) Review all instructions before beginning:...
  • Page 30 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTIUDE __6) Attaching Plastic Caps to Base Rail Pipe: To do this you will need four of the red plastic caps (13) and four of the black plastic caps (12). You will need to first slide the black plastic cap onto the base pipe (4).
  • Page 31 382-404H WHEELCHAIR SWING INSTALLATION INSTRUCTION INSTALLATION STEPS CONTINUED __9) Tighten all set screws inspect the area and components for tools, hazardous debris and sharp edges. Inspect for sharp edges and if necessary file them down and apply touch up paint.
