PX725HD
DLP Projector
User Guide
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
box in the upper right corner of our website. "Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual"
Model No. VS16965

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX725HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ViewSonic PX725HD

Summary of Contents for ViewSonic PX725HD

  • Page 1 Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// box in the upper right corner of our website. “Antes de operar su equipo lea cu idadosamente las instrucciones en este manual”...
  • Page 2 Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the follow- ing two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 3 Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this unit near water. Clean with a soft, dry cloth. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s instructions.
  • Page 4 Declaration of RoHS2 Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS2 Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance...
  • Page 5 Product Registration To fulfill possible future product needs, and to receive additional product information as it becomes available, please visit your region section on ViewSonic’s website to register your product online. The ViewSonic CD also provides an opportunity for you to print the product registration form.

  • Page 6: Table Of Contents

    Table of contents Important safety Using the 3D functions ...... 32 Using the projector in standby mode . 33 instructions .......2 Adjusting the sound ......33 Introduction......4 Shutting down the projector ....34 Menu operation........35 Projector features ......... 4 Shipping contents.........

  • Page 7: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before you operate your projector.
  • Page 8 Do not block the ventilation holes. If the ventilation holes are seriously obstructed, overheating inside the projector may result in a fire. - Do not place this projector on a blanket, bedding or any other soft surface. - Do not cover this projector with a cloth or any other item. - Do not place inflammables near the projector.

  • Page 9: Introduction

    Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • Dynamic mode adjusting the power consumption of the lamp according to the brightness of the image being projected •...

  • Page 10: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated.

  • Page 11: Projector Exterior View

    Projector exterior view Lamp cover Front/upper Front IR remote sensor Projection lens Focus ring Zoom ring Power button and LED indicators External control panel (See "Projector" on page 7 details.) Vent (air inlet) AC power cord inlet HDMI-1 port HDMI-2 port RGB (PC) /Component video 5 6 7 (YPbPr/YCbCr) signal input socket...

  • Page 12: Controls And Functions

    Controls and functions Projector 4 5 6 10 11 12 13 14 15 Focus ring Exit Adjusts the focus of the projected image. Goes back to previous OSD menu, exits and saves menu settings. Zoom ring Adjusts the size of the projected image. Source Displays the source selection bar.
  • Page 13 Remote control (Keystone keys) Power Manually corrects distorted images Toggles the projector between standby resulting from an angled projection. mode and Power ON. Left/ Right/ Down HDMI 1 Selects the desired menu items and Selects HDMI 1 source for display. makes adjustments.
  • Page 14 Source (Volume down) Displays the source selection bar. Decrease the volume level. Enter (Mute) Enacts the selected On-Screen Display Toggles the projector audio between on and (OSD) menu item. off. Exit Contrast Goes back to previous OSD menu, exits Displays the contrast setting bar. and saves menu settings.
  • Page 15 Replacing the remote control batteries To open the battery cover, turn the remote control over to view its back, press on the finger grip on the cover and pull it up in the direction of the arrow as illustrated. Remove any existing batteries (if necessary) and install two AAA batteries observing the battery polarities as indicated in the base of the battery compartment.

  • Page 16: Positioning Your Projector

    Positioning your projector Choosing a location Your room layout or personal preference will dictate which installation location you select. Take into consideration the size and position of your screen, the location of a suitable power outlet, as well as the location and distance between the projector and the rest of your equipment.

  • Page 17: Projection Dimensions

    Projection dimensions The "screen" mentioned below refers to the projection screen usually consisting of a screen surface and a support structure. • 16:9 image on a 16:9 screen • 16:9 image on a 4:3 screen (e): Screen (f): Center of lens 16:9 image on a 16:9 Screen (a) Screen Size (b) Projection distance...
  • Page 18 16:9 image on a 4:3 Screen (a) Screen Size (b) Projection distance (d) Vertical offset (c) Image height min. max. min. max. inch inch inch inch inch inch 1372 1651 1829 1651 1981 2184 1930 2337 2565 2210 2667 2921 2489 2997 3277...

  • Page 19: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...

  • Page 20: Connecting A Computer Or A Monitor

    Connecting a computer or a monitor Connecting a computer Take the supplied VGA cable and connect one end to the D-Sub output socket of the computer. Connect the other end of the VGA cable to the COMPUTER IN signal input socket on the projector.
  • Page 21 Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly. VGA-Component adapter (ViewSonic P/N: CB-00008906) Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: •...

  • Page 22: Playing Sound Through The Projector

    If the selected video image is not displayed after the projector is turned on and the correct video source has been selected, check that the Video source device is turned on and operating correctly. Also check that the signal cables have been connected correctly. You need only connect to this device using a composite Video connection if Component Video input is unavailable for use.

  • Page 23: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). (If available) Remove the lens cap. Press Power to start the projector. As soon as the lamp lights up, a "Power On Ring Tone"...

  • Page 24: Using The Menus

    Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings. The OSD screenshots below are for reference only, and may differ from the actual design. Below is the overview of the OSD menu. Main menu icon Highlight Status...

  • Page 25: Utilizing The Password Function

    Utilizing the password function For security purposes and to help prevent unauthorized use, the projector includes an option for setting up password security. The password can be set through the On-Screen Display (OSD) menu. For details of the OSD menu operation, please refer to "Using the menus"...
  • Page 26 Entering the password recall procedure Press and hold Auto Sync on the remote control for 3 seconds. The projector will display a coded number on the screen. Write down the number and turn off your projector. Seek help from the local service center to decode the number.

  • Page 27: Switching Input Signal

    Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time. Be sure the Quick Auto Search function in the SYSTEM menu is On if you want the projector to automatically search for the signals.

  • Page 28: Adjusting The Projected Image

    Adjusting the projected image Adjusting the projection angle The projector is equipped with two adjuster foot. It changes the image height and vertical projection angle. Screw the adjuster foot to fine tune the angle until the image is positioned where you want it. If the projector is not placed on a flat surface or the screen and the projector are not perpendicular to each other, the projected image becomes trapezoidal.

  • Page 29: Magnifying And Searching For Details

    Fine-tuning the image clarity Adjust the projected image to the size If necessary, sharpen the image by rotating that you need using the zoom ring. the focus ring. Correcting keystone Keystoning refers to the situation where the projected image becomes a trapezoid due to angled projection.
  • Page 30 With the advent of digital signal processing, digital display devices like this projector can dynamically stretch and scale the image output to a different aspect than that of the image input signal. To change the projected image ratio (no matter what aspect the source is): DISPLAY >...

  • Page 31: Optimizing The Image

    Anamorphic: Scales a 2.35:1 aspect image so that it fills the screen. 2.35:1 picture Optimizing the image Selecting a picture mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. To select an operation mode that suits your need, you can follow one of the following steps.
  • Page 32 Adjusting Brightness Go to the IMAGE > Brightness menu and press The higher the value, the brighter the image. And the lower the setting, the darker the image. Adjust this control so the black areas of the image appear just as black and that detail in the dark areas is visible.
  • Page 33 Selecting a gamma setting Go to the IMAGE > ADVANCED > Gamma menu and select a preferred setting by pressing Gamma refers to the relationship between input source and picture brightness. Selecting a Color Temperature Go to the IMAGE > Color Temp menu and press The options available for color temperature settings vary according to the signal type selected.
  • Page 34 Please refer to the illustration to the right for how the colors relate to each other. For example, if you select Red and set its Yellow range at 0, only pure red in the projected GREEN picture will be selected. Increasing its range will include red close to yellow and red close to magenta.

  • Page 35: Setting The Presentation Timer

    Setting the presentation timer Presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Go to the BASIC > Presentation Timer menu. Press Enter to display the Presentation Timer page. Highlight Timer Period and decide the time period by pressing .

  • Page 36: Hiding The Image

    Hiding the image In order to draw the audience's full attention to the presenter, you can press BLANK to hide the screen image. Press any key on the projector or remote control to restore the image. The word 'BLANK' appears at the lower right corner of the screen while the image is hidden. You can set the blank time in the BASIC >...

  • Page 37: Using The Cec Function

    However, this is not to state that this projector can operate under any and all harsh or extreme conditions. Using the CEC function This projector supports CEC (Consumer Electronics Control) function for synchronized power on/off operation via HDMI connection. That is, if a device that also supports CEC function is connected to the HDMI input of the projector, when the projector’s power is turned off, the power of the connected device will also be turned off automatically.

  • Page 38: Using The Projector In Standby Mode

    Using the projector in standby mode Some of the projector functions are available in standby mode (plugged in but not turned on). To use these functions, be sure you have turned on the corresponding menus under POWER MANAGEMENT > Standby Settings, and the cable connections are correctly made.

  • Page 39: Shutting Down The Projector

    Shutting down the projector Press Power and a confirmation message is displayed prompting you. If you don't respond in a few seconds, the message will disappear. Press Power a second time. Once the cooling process finishes, a "Power Off Ring Tone" will be heard. Disconnect the power cord from the wall socket if the projector will not be used in an extended period of time.

  • Page 40: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. The menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.
  • Page 41 Timer Display Never Top-Left/Bottom-Left/Top- Presentation Timer Position Right/Bottom-Right Timer 4. BASIC Timer Counting Count Down/Count Up Direction Sound Reminder On/Off Start Counting/Off Yes/No Pattern Off/Grid Disable/5 min/10 min/15 min/ Blank Timer 20 min/25 min/30 min Message On/Off Splash Screen Black/Blue/ViewSonic...
  • Page 42 Main menu Sub-menu Options Auto/Off/Frame 3D Sync Sequential/Frame Packing/ 3D Settings Top-Bottom/Side-by-Side 3D Sync Invert Disable/Invert HDMI Format Auto/RGB/YUV HDMI Settings HDMI Range Auto/Enhanced/Normal Normal/Eco/Dynamic/ 5. ADVANCED Lamp Mode SuperEco Lamp Settings Reset Lamp Hours Reset/Cancel Lamp Hours Off/On Closed Caption Off/CC1/CC2/CC3/CC4 Reset Settings Reset/Cancel...
  • Page 43 Description of each menu Function Description "Using Screen Color" on page 26 for details. Screen Color This function is only available when a PC input signal is selected. Aspect Ratio "Selecting the aspect ratio" on page 24 for details. Keystone "Correcting keystone"...
  • Page 44 Function Description Color Mode "Selecting a picture mode" on page 26 for details. Brightness "Adjusting Brightness" on page 27 for details. Contrast "Adjusting Contrast" on page 27 for details. "Selecting a Color Temperature" on page 28 "Setting a Color Temp preferred color temperature"...
  • Page 45 Function Description Signal Selecting All allows the projector to turn on automatically once the VGA/HDMI signal is fed through the VGA/HDMI cable. Auto Power On "Using the CEC function" on page 32 for details. Direct Power On Selecting On allows the projector to turn on automatically once the power is fed through the power cord.
  • Page 46 Function Description Presentation "Setting the presentation timer" on page 30 for details. Timer The projector can display grid test patterns. It helps you adjust Pattern the image size and focus and check that the projected image is free from distortion. Blank Timer "Hiding the image"...
  • Page 47 Function Description Sets the language for the On-Screen Display (OSD) menus. Language "Using the menus" on page 19 for details. Projector "Choosing a location" on page 11 for details. Position Menu Display Time Sets the length of time the OSD will remain active after your last key press.

  • Page 48: Maintenance

    Maintenance Care of the projector You need to keep the lens and/or filter (optional accessory) clean on a regular basis. Never remove any parts of the projector. Contact your dealer when any part of the projector needs replacing. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface.

  • Page 49: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. To obtain the lamp hour information: Open the OSD menu and go to the ADVANCED > Lamp Settings menu. Press Enter and the Lamp Settings page is displayed.
  • Page 50 Press Enter and the Smart Energy page is displayed. Highlight Power Saving and press When Enable is selected, the projector lamp will be changed to Eco mode after no signal is detected for 5 minutes. The lamp power will be changed to SuperEco mode after no signal is detected for 20 minutes.
  • Page 51 Indicators Light Status & Description Blue Power events Lamp Ready Start Flashing Cooling Flashing Scaler Stops Working 2 blinks Case Open 7 blinks DMD Error 8 blinks Color Wheel Error 9 blinks Lamp events Lamp Re-Strike 6 Times Failed 5 blinks Lamp Temperature Shut Down (Ballast Temp.) 5 blinks 1 blinks...

  • Page 52: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the power There is no power from the power cord. outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 53: Specifications

    Specifications Projector specifications • All specifications are subject to change without notice. • Not all models can be purchased in your region. General Product name DLP Projector Optical 1920 x 1080 1080p Resolution Display system 1-CHIP DMD Lamp 240 W lamp Electrical Power supply AC100–240V, 50–60 Hz (Automatic)

  • Page 54: Dimensions

    Dimensions 347.66 mm (W) x 106.9 mm (H) x 233.29 mm (D) 347.66mm (13.6" ) Ceiling mount installation "] 63.50mm Ceiling mount screws: M4 x 8 (Max. L = 8 mm) "] 60.00mm 136.000mm 5.35 Unit: mm "] 2.36...

  • Page 55: Timing Chart

    Timing chart Analog RGB Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) 640 x 480 60/72/75/85 SVGA 800 x 600 60/72/75/85 1024 x 768 60/70/75/85 1152 x 864 1280 x 768 15:9 WXGA 1280 x 800 16:10 60/75/85 1360 x 768 16:9 Quad-VGA 1280 x 960...
  • Page 56 HDMI Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) 640 x 480 SVGA 800 x 600 1024 x 768 1280 x 768 15:9 WXGA 1280 x 800 16:10 1360 x 768 16:9 Quad-VGA 1280 x 960 SXGA 1280 x 1024 SXGA+ 1400 x 1050 WXGA+...
  • Page 57 3D (HDMI signal included) Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) SVGA 800 x 600 60* / 120** 1024 x 768 60* / 120** 1280 x 720 16:9 60* / 120** WXGA 1280 x 800 16:9 60* / 120** for Video Signal Signal Resolution (dots)
  • Page 58 Component video Signal Resolution (dots) Aspect Ratio Refresh Rate (Hz) HDTV (1080p) 1920 x 1080 16:9 50 / 60 HDTV (1080i) 1920 x 1080 16:9 50 / 60 HDTV (720p) 1280 x 720 16:9 50 / 60 SDTV (480p) 720 x 480 4:3 / 16:9 SDTV (576p) 720 x 576...

  • Page 59: Copyright Information

    Copyright 2015. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of ViewSonic Corporation. Disclaimer...

  • Page 60: Appendix

    Appendix IR control table Format Byte1 Byte2 Byte3 Byte4 (with Blue back light) Power ON Power Off COMP HDMI 1 HDMI 2 Auto sync Source Up/V keystone + Left Enter Right Down/V keystone - Menu Info(i) Exit Aspect Pattern Blank Help(?) Mute Volume-...

  • Page 61: Rs232 Command Table

    RS232 command table <Pin assignment for this two end> Description Description RTSZ CTSZ <Interface> RS-232 protocol Baud Rate 115200 bps (default) Data Length 8 bit Parity Check None Stop Bit 1 bit Flow Control None...
  • Page 62 0x06 0x14 0x00 0x04 0x00 0x34 0x11 Write Blue 0x0A 0x01 0x68 Splash Screen 0x06 0x14 0x00 0x04 0x00 0x34 0x11 ViewSonic 0x0A 0x02 0x69 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x11 0x0A 0x68 0x06 0x14 0x00 0x04 0x00 0x34 0x11...
  • Page 63 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x27 0x00 0x84 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x11 Message 0x27 0x01 0x85 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x11 0x27 0x85 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Front Table 0x00 0x00 0x5E 0x06 0x14 0x00 0x04 0x00 0x34 0x12...
  • Page 64 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Decrease 0x03 0x00 0x61 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Brightness Increase 0x03 0x01 0x62 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Get Value 0x00 0x12 0x03 0x62 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Auto 0x04 0x00 0x62...
  • Page 65 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x12 0x09 0x01 0x68 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Blank 0x09 0x00 0x67 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x12 0x09 0x68 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Decrease 0x0A 0x00 0x68 Write...
  • Page 66 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Decrease 0x11 0x00 0x6F Write 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Increase 0x11 0x01 0x70 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Get value 0x00 0x12 0x11 0x70 0x06 0x14 0x00 0x04 0x00 0x34 0x12 Decrease 0x12 0x00 0x70...
  • Page 67 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x13 0x02 0x01 0x62 Write Quick Auto 0x06 0x14 0x00 0x04 0x00 0x34 0x13 Search 0x02 0x00 0x61 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x13 0x02 0x62 0x06 0x14 0x00 0x04 0x00 0x34 0x14 0x00 0x01 0x61 Write...
  • Page 68 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x00 0x61 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x01 0x62 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x02 0x63 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x03 0x64 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x04 0x65...
  • Page 69 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x0d 0x6E 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x0e 0x6F 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x0f 0x70 0x06 0x14 0x00 0x04 0x00 0x34 0x15 0x00 0x10 0x71 0x06 0x14 0x00 0x04 0x00 0x34 0x15 Write...
  • Page 70 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x2B 0x00 0x88 Write 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x2B 0x01 0x89 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x11 0x2B 0x89 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Error status Read Status...
  • Page 71 Function Type Action Command 0x06 0x14 0x00 0x04 0x00 0x34 0x0C code 7 0x48 0x06 0xA6 Write Remote 0x06 0x14 0x00 0x04 0x00 0x34 0x0C code 8 Control code 0x48 0x07 0xA7 0x07 0x14 0x00 0x05 0x00 0x34 0x00 Read Status 0x00 0x0C 0x48 0xA1 0x06 0x14 0x00 0x04 0x00 0x34 0x11...
  • Page 72 Function Type Action Command 0x02 0x14 0x00 0x04 0x00 0x34 0x02 Menu 0x04 0x0F 0x61 0x02 0x14 0x00 0x04 0x00 0x34 0x02 Exit 0x04 0x13 0x65 0x02 0x14 0x00 0x04 0x00 0x34 0x02 0x04 0x0B 0x5D 0x02 0x14 0x00 0x04 0x00 0x34 0x02 Bottom 0x04 0x0C 0x5E 0x02 0x14 0x00 0x04 0x00 0x34 0x02...
  • Page 73 Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Mexico) la/soporte/servicio-tecnico Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F. Tel: 55) 6547-6454 55)6547-6484 Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico Latin America C= http://www.viewsonic.com/ www.viewsonic.com/la/ soporte@viewsonic.com (Peru) la/soporte/servicio-tecnico Macau www.hk.viewsonic.com T= 853-2840-3687 service@hk.viewsonic.com...
  • Page 74 America: Three (3) years warranty for all parts excluding the lamp, three (3) years purchase. Other regions or countries: Please check with your local dealer or local ViewSonic Limited One (1) year Heavy Usage Warranty: Under heavy usage settings, where a projector’s use includes more than fourteen...
  • Page 75 There are no warranties, express or implied, which extend beyond the description particular purpose. Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
  • Page 76 If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
  • Page 77 Tel: (52) 999-925-1916 Tel: 01(52)95-15-15-22-22 E-Mail: rrrb@sureste.com Fax: 01(52)95-15-13-67-00 E-Mail. gpotai2001@hotmail.com Tijuana: FOR USA SUPPORT: ViewSonic Corporation Av Ferrocarril Sonora #3780 L-C 14035 Pipeline Ave. Chino, CA 91710, USA Col 20 de Noviembre Tel: 800-688-6688 Tijuana, Mexico E-Mail: http://www.viewsonic.com Projector Mexico Warranty Term Template In UG...
