Network Mini Dome Camera·Quick Start Guide 1 Appearance Description Overview Figure 1-1 Overview of Mobile Network Mini Dome Camera...
Page 12
Network Mini Dome Camera·Quick Start Guide Table 1-1 Description of Mobile Network Mini Dome Camera Description Dome Cover Mounting Base Lens Dome Drive Mic. Serial Port Reset Button Memory Card Slot IR LED Press Reset Button about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.
Network Mini Dome Camera·Quick Start Guide Cables Description This camera series has several camera models, each of which may have different cable group. The following figures and tables show the description of all possible cables in this camera series. Figure 1-2 Cable Overview...
Page 14
Network Mini Dome Camera·Quick Start Guide Table 1-2 Cable Description Description RJ45 Network Cable M12 Aviation Plug Video Out (BNC) Black: power negative Power Supply and Red: power positive Audio Out Cable White and Brown: audio out Power Supply Cable Audio Out (Line Out) Cable The relation between RJ45 wire and M12 wire is shown in the following figure and table.
Page 15
Network Mini Dome Camera·Quick Start Guide Table 1-3 Wire Relation M12 Wire RJ45 Wire...
Network Mini Dome Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches with your camera.
Network Mini Dome Camera·Quick Start Guide Memory Card Installation Camera of this series supports a memory card as the local storage. Follow the following steps to mount the memory card. Steps: 1. Unscrew the dome cover to disassemble the camera with supplied wrench.
Network Mini Dome Camera·Quick Start Guide Camera Mounting Before you start: ● Do not tear off the protection film until the installation is completed. ● Do not touch the inside face of the bubble with your hands. Steps: 1. Paste the drill template to the desired mounting place. Drill Template Hole A: for cables routed through the ceiling Screw hole 1: for Mounting Base...
Page 19
Network Mini Dome Camera·Quick Start Guide If you want to route cable through the side outlet of the mounting base, use a plier to remove the piece of plastic that blocks the side outlet. Plastic Piece Figure 2-4 Clear the Side Outlet 3.
Page 20
Network Mini Dome Camera·Quick Start Guide Figure 2-6 Install the Mounting Base 4. Route and connect cables. Fix the camera to the mounting base with two PM4×8 screws. (Optional) For cameras that are installed outdoor, it is recommended to install water-proof jacket to the network interface. See Section 2.3.
Page 21
Network Mini Dome Camera·Quick Start Guide 5. Adjust the surveillance angle. Pan: -30° to 30° Plastic Ring Rotate: 0° to 360° Tilt: 0° to 80° Figure 2-8 3-Axis Adjustment View the image via the web browser. Slightly loosen the screw beside the RESET button to adjust the surveillance angle.
Network Mini Dome Camera·Quick Start Guide Dome Cover Figure 2-9 Install the Dome Cover 7. Tear off the protection film softly to complete the installation. 2.3 Installation of Network Cable Water-proof Jacket (Optional) Purpose: If the camera is installed outdoor, you can adapt the water-proof accessory for the network cable after the camera is secured on the installation surface.
Page 23
Network Mini Dome Camera·Quick Start Guide Table 2-1 Components Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap Waterproof Rubber Gasket Lock Nut Network Cable from Router/Switch Steps: Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof rubber gasket ⑤...
Page 24
Network Mini Dome Camera·Quick Start Guide Insert the waterproof rubber gasket ⑤ into the waterproof endcap ④, and secure lock nut ⑥ with the waterproof endcap ④. Align the snap on the waterproof endcap ④ with the notch on the camera’s network interface socket ①, and then secure the waterproof endcap ④...
Network Mini Dome Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.
Network Mini Dome Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported.
Network Mini Dome Camera·Quick Start Guide Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your...
Page 28
Network Mini Dome Camera·Quick Start Guide Figure 3-4 SADP Interface Note: The SADP software supports activating the camera in batch. Please refer to the user manual of SADP software for details. 3. Create a password and input the password in the password field, and confirm the password.
Network Mini Dome Camera·Quick Start Guide 4. Click OK to save the password. You can check whether the activation is completed on the popup window. If activation failed, please make sure that the password meets the requirement and try again. Modifying the IP Address Purpose: To view and configure the camera via LAN (Local Area Network), you...
Page 30
Network Mini Dome Camera·Quick Start Guide Figure 3-5 Modify the IP Address 4. Input the password to activate your IP address modification. The batch IP address modification is supported by the SADP; please refer to the User Manual of SADP for details.
Network Mini Dome Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
Page 32
Network Mini Dome Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the plug-in installation.
