Summary of Contents for Vermeiren D100

  • Page 1 V RM IR N D100 I N S T R U C T I O N M...
  • Page 2 No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without written permission of the publisher, or processed, duplicated or distributed by using electronic systems. © N.V. Vermeiren N.V. 2014...
  • Page 3: Table Of Contents

    D100 2014-07 Contents Preface ....................2   Product description ..............3         Intended Use ........................ 3   Technical specifications ....................4     Drawing ........................5     Accessories ........................5     Location identification plate ..................5  ...
  • Page 4: Preface

    First of all we want to thank you for putting your trust in us by selecting one of our wheelchairs. The Vermeiren wheelchairs are the result of many years of research and experience. During the development, special attention was given to the ease of use and the serviceability of the wheelchair.
  • Page 5: Product Description

    When used on mats, carpeted floors or loose floor coverings, the floor covering can get damaged. Use only Vermeiren approved accessories. The manufacturer is not liable for damage caused by the lack of or improper service or as a result of not following instructions from this manual.
  • Page 6: Technical Specifications

    D100 2014-07 Technical specifications Technical terms below are valid for the wheelchair in standard settings. If other footrest / armrest or other accessories are used, the tabulated values will change. Make Vermeiren Address Vermeirenplein 1/15, B-2920 Kalmthout Type Manual wheelchair...
  • Page 7: Drawing

    8 = Back 9 = Tip cap 10 = Cross 11 = Handgrips Accessories The following accessories are available for the D100:  Anterior pelvic belt (B20) for mounting on the tubes of the back (see according manual)  Anti-tipping device (B78) for mounting on the bottom frame (see according manual)
  • Page 8: Explanation Of Symbols

    D100 2014-07 Explanation of symbols Maximum mass Indoor and outdoor use Maximum Safe Slope CE conformity Type designation Safety rules To prevent injury and/or damage to your wheelchair, make sure that no objects and/or body parts are caught in the spokes of the driving wheels.
  • Page 9: Carrying The Wheelchair

    D100 2014-07 Carrying the wheelchair The best way to carry the wheelchair is to make use of the wheels and roll the wheelchair. If this is not possible (e.g. when the rear wheels are taken off for transportation in a car), firmly grasp the frame on the front and the grips.
  • Page 10: Operating The Brakes

    D100 2014-07 Operating the brakes WARNING: The brakes are not used to slow down the wheelchair during movements – Use the brake only to prevent the wheelchair from unintended movements. WARNING: Good operation of the brakes is influenced by wear and contamination of the tires (water, oil, mud, …) –...
  • Page 11 D100 2014-07 4. Click the front tube of the armrest in tube  hood To open and remove the armrest:  1. Press lever and pull the front of the armrest upwards. 2. Fold the armrest backwards.  To remove the armrest, press button and pull the rear of the armrest from tube hood .
  • Page 12: Transfer In And Out The Wheelchair

    D100 2014-07 Transfer in and out the wheelchair CAUTION: In case you cannot perform the transfer in a safe manner, ask someone to assist you. CAUTION: Risk of tipping over of the wheelchair – Do not stand on the foot plate.
  • Page 13: Negotiating Steps Or Curbs

    D100 2014-07 If available on the wheelchair, wear the safety belt. Do not attempt moving on too high slopes. The maximum slope angles (upwards and downwards) are mentioned in table 1. Ask an attendant to help you moving on the slope.
  • Page 14: Fold Up The Wheelchair

    D100 2014-07 An experienced user can negotiate curbs by himself: WARNING: Risk of tipping over – If you have not enough experience to control the wheelchair, get help from an attendant. Drive until the curbs. Ensure that the footrest do not touch the curbs.
  • Page 15: Transport In The Car

    D100 2014-07 2.14 Transport in the car WARNING: Risk of injury – See that the wheelchair is attached properly. So you can avoid injury from the passengers during collision or sudden braking. WARNING: Risk of injury – Use for attaching the wheelchair and passenger NEVER the same seatbelt.
  • Page 16 D100 2014-07 7. Mount the front securement straps according to the instructions of the strap-system manufacturer at the indicated place. (figure 3) This place is marked on the wheelchair with a symbol. (figure 4) 8. Roll back the wheelchair until the front straps are tight.
  • Page 17: Installation And Adjustment

    Installation and adjustment The instructions in this chapter are for the specialist dealer. The Vermeiren D100 has been designed to be adjust with a minimum of replacements parts. There is no need for extra stock of spare parts. To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility.
  • Page 18: Adjusting The Seat Height

    D100 2014-07 Adjusting the seat height The Vermeiren D100 is adjustable in 3 seat heights by changing the wheels position. At each height there is a different setting of the front and rear wheels. WARNING: The top hole of the axle plate is not intended for mounting the rear axle - This hole is for mounting the drum brake.
  • Page 19: Adjust The Brakes

    D100 2014-07 Adjust the brakes WARNING: Risk of injury – Brakes may only be adjusted by your specialist dealer. Adjust the brakes according following rules: 1. Install the wheels according § 2.2.  2. Disconnect the brakes by pulling lever backwards.
  • Page 20: Adjusting The Armpad

    Remove both screws under the armpad. Place the correct number of blocks under and above the tubes, see table 3. Install the armpad with the required holes for depth adjustment. Maintenance For the maintenance manual of the wheelchairs refer to the Vermeiren website: www.vermeiren.be. Page 18 ...
  • Page 21 Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date:  For service checklists an additional technical information, please see our specialist dealers nearest to you. More information on our website at: www.vermeiren.com.
