  • Page 1 V RM IR N lbatros II I N S T R U C T I O N M...
  • Page 2 No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without written permission of the publisher, or processed, duplicated or distributed by using electronic systems. © N.V. Vermeiren N.V. 2012...

  • Page 3: Table Of Contents

    Albatros II 2012-09 Contents Preface ....................2 Product description ..............3 Intended Use ........................ 3 Technical specifications ....................4 Drawing ........................6 Explanation of the symbols ..................7 Delivery ........................7 Use ..................... 7 General notes ....................... 7 Use of the JUMBO system (battery, control box + included battery charger) ..10 Operating the lift .......................

  • Page 4: Preface

    First of all we want to thank you for putting your trust in us by selecting one of our products. The Vermeiren patient hoists are the result of many years of research and experience. During the development, special attention was given to the ease of use and the serviceability of the patient hoist.

  • Page 5: Product Description

    When used on mats, carpeted floors or loose floor coverings, the floor covering can get damaged. Use only Vermeiren approved accessories. Make sure that the end of the adjustment motor has a safety measurement. Therefore, use the patient hoist only in the middle of the adjustment range and not at the end of the hoist motor.

  • Page 6: Technical Specifications

    Albatros II 2012-09 Technical specifications Forward direction Page 4...
  • Page 7 Albatros II 2012-09 Brand Vermeiren Address Vermeirenplein 1/15, B-2920 Kalmthout Type Patient hoist Model Albatros II Measurement in Dimensions drawing Lowest CAP position* 1060 mm Highest CAP position* 1687 mm Lifting range (range of heights) 637 mm Leg length 1000 mm...

  • Page 8: Drawing

    Albatros II 2012-09 Brand Vermeiren Address Vermeirenplein 1/15, B-2920 Kalmthout Type Patient hoist Model Albatros II Measurement in Dimensions drawing Battery protection class IPX5 Manual control protection class IPX5 Motor protection class IP54 Insulation class II - Type B Operational performance approx.

  • Page 9: Explanation Of The Symbols

    Read the instruction manual before use! Separate recovery and recycling of electric and electronic devices. CE declaration of conformity Delivery The Vermeiren Albatros II patient hoist shall be delivered with: • chassis including 4 casters (2 with brakes) • pole, including handles for pushing •...
  • Page 10 Albatros II 2012-09 2.1.1 Instructions for lifting patient Phase I – Preparation. In this phase, the patient should stay on the footplate and put his feet in the special footrests with the velcro fastening. Then stabilize your feet and legs under your knees by using the velcro belt on the foot- and leg support.
  • Page 11 Albatros II 2012-09 Buttons for waist belt attachment View properly how the patient is stabilized. Page 9...

  • Page 12: Use Of The Jumbo System (Battery, Control Box + Included Battery Charger)

    Albatros II 2012-09 Use of the JUMBO system (battery, control box + included battery charger) JUMBO is a modular system combining an actuator, a control box and a battery in a flexible solution, specially developed for patient hoists. 2.2.1 Battery The battery is above the control box and is replaceable with an integrated clip system.

  • Page 13: Operating The Lift

    2012-09 2.2.4 Charging the batteries Use only the control box with included battery charger on the Albatros II or the external charger meant to be mounted on the wall. We recommend that you should regularly recharge the batteries in order to ensure that the hoist remains usable and to extend the lifespan of the batteries.
  • Page 14 Albatros II 2012-09 2.3.2 Parking brakes Secure the two casters at the back of the chassis by pressing the caster brake plates down gently to their end stops with the tip of your foot. To release the brake, push the brake plate gently back up again with the front of your foot until the casters are free.
  • Page 15 Albatros II 2012-09 2.3.5 Thorax support To stabilize and support your thorax, the lift is equipped with thorax pillow and velcro belts to stabilize. The thorax support can be adjusted in 2 different positions 1045 mm, 1200 mm. These positions are measured from the footplate until the top of the thorax support.

  • Page 16: Slings

    WARNING: Risk of injury – Only use appropriate slings for the patients. WARNING: Risk of injury – Do not use damaged slings. The Albatros II patient hoist must only be used with slings designed for the Vermeiren Albatros II patient hoists.

  • Page 17: Emergency

    Albatros II 2012-09 Emergency In cases for emergency the emergency stop and the function for lowering in an emergency must be used. 2.6.1 Emergency stop In emergencies, and during assembly and disassembly, the emergency stop is activated by pressing the red button on the control box.

  • Page 18: Installation And Adjustment

    Installation and adjustment The instructions in this chapter are for the specialist dealer. To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility. A list of Vermeiren facilities can be found on the last page.
  • Page 19 Albatros II 2012-09 3.2.2 Assembly WARNING: Risk of clamping - Take care that no body parts and wires get trapped, crushed or cut during assembly. 1. Remove the safety spindle (locking pin) from the bottom end of the pole by gently pressing the button at the head of the spindle.
  • Page 20 Albatros II 2012-09 Remove the cantilever arm from the top end of the pole . This is possible by pulling on the pen 5. Mount the slide column with the foot support attachment in the tube of the patient hoist frame.
  • Page 21 Albatros II 2012-09 Pull the actuator gently out the black clip Attach the actuator on the cantilever locking pin . Take care that actuator positioned very well between cantilever arm. 9. Attach the footplate with the hooks to the chassis of the patient hoist.
  • Page 22 Albatros II 2012-09 3.2.3 Dismantling WARNING: Risk of clamping - Take care that no body parts and wires get trapped, crushed or cut during dismantling. WARNING: Risk of injury - Check the emergency stop (red pushbutton on the control box) is activated, to avoid unintentional adjustment movements.
  • Page 23 Albatros II 2012-09 5. Dismantle actuator (motor) from the cantilever arm by removing the locking 6. Move the actuator to the bottom position and place the actuator in the black clip 7. Remove the slide and slide holder from the cantilver with the locking pin 8.
  • Page 24 Albatros II 2012-09 9. Move the cantilever arm to bottom position Fasten the pen on the top end of the pole in the hole of the cantilever arm 10. Remove the safety spindle (locking pin) from the bottom end of the pole by gently pressing the button at the head of the spindle.

  • Page 25: Maintenance

    Albatros II 2012-09 Maintenance For the maintenance manual of the patient hoists refer to the Vermeiren website: www.vermeiren.be. Ordernumbers Casters (ø 100 mm) 1903403 Braked casters (ø 100 mm) 1903402 E Control box Albatros 1906137 E Motor 7,5KN Albatros 1906229...
  • Page 26 Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date: • For service checklists an additional technical information, please see our specialist dealers nearest to you. More information on our website at: www.vermeiren.com.
  • Page 29 Notes ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 30 Notes ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 32 Fax: +41(0)31 818 40 98 website: www.reatime.it website: www.vermeiren.ch e-mail: info@reatime.it e-mail: info@vermeiren.ch Poland The Netherlands Vermeiren Polska Sp. z o.o Vermeiren Nederland B.V. Domstraat 50 Łączna PL-55-100 Trzebnica NL-3864 PR Nijkerkerveen Tel: +48(0)71 387 42 00 Tel: +31(0)33 2536424...
