- Page 1 VERMEIREN Luna 2, Luna Basic 2, Luna UL 2 INSTALLATION MANUAL...
-
Page 3: Table Of Contents
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Content Content Content ........................... 1 Preface ............................ 2 This product....................... 3 Scope of delivery ....................... 5 Assembly ........................6 Tools ..........................6 Assembling the bed ..................... 7 Strain relief and power cable ..................10 Cable placement ....................... -
Page 4: Preface
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Preface Preface To support you on the installation and repairs of this nursing bed, we provide you with this installation manual. Please read it carefully. If you still have questions after reading this manual, do not hesitate to contact Vermeiren. -
Page 5: This Product
Luna 2, Luna Basic 2, Luna UL 2 2021-03 This product This product Luna 2 1. Head panel 2. Lifting pole 3. Mattress retainer 4. Side rail 5. Foot panel 6. Castor 7. Foot end 8. Head end 9. Handset 10. - Page 6 Luna 2, Luna Basic 2, Luna UL 2 2021-03 This product 1. Head panel 2. Lifting pole 3. Mattress retainer 4. Side rail 5. Foot panel 6. Castor 7. Foot end 8. Head end 9. Handset Luna UL 2 10. Identification plate...
-
Page 7: Scope Of Delivery
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Scope of delivery Scope of delivery The following components are part of the delivery: Head and feet end incl. motors + wooden panels Slatted frame, foot-end incl. motor Slatted frame, head-end incl. transformer and motor ... -
Page 8: Assembly
Prevent trapping your hands when assembling, disassembling or using the bed. Make sure that no body parts or objects are present when adjusting hinges, joints or other clamps. Only use genuine spare or replacement parts approved by Vermeiren. Important remarks ... -
Page 9: Assembling The Bed
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Assembly Assembling the bed Risk of injuries CAUTION Keep your fingers and the electric cables away from moving parts, and make sure that they do not become trapped between components during assembly. - Page 10 Luna 2, Luna Basic 2, Luna UL 2 2021-03 Assembly 1. Loosen the fixing screws (2), if necessary. 2. Erect both slatted frames (1) and insert them into each other. 3. Retighten the fixing screws (2) of the slatted frame connection.
- Page 11 Luna 2, Luna Basic 2, Luna UL 2 2021-03 Assembly 1. Insert the stop (5) and screw (6) in the top or lower hole according to the desired height of the side rails. 2. Loosen the locknuts (4), if necessary.
-
Page 12: Strain Relief And Power Cable
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Assembly 3.2.4 Split side rails Mind the difference between head-end and foot-end rails (head-end rails are shorter than foot-end rails). 1. Take one of the split side rails. 2. Place the split side rail attachments (1) over the mattress frame support (2). -
Page 13: Cable Placement
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Assembly 3. Fasten the power cable by properly tightening the relief unit of the power cable (4). 4. Fasten the position of the relief unit by properly tightening the fixing screws (5). -
Page 14: Transport
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Assembly Transport Risk of injuries or damage CAUTION Attach all bed parts and transport trolley firmly to the vehicle, to prevent them from moving during transport. 3.5.1 Luna 2, Luna Basic 2 1. - Page 15 2021-03 Assembly 3.5.2 Vertical transport set Luna 2, Luna Basic 2, Luna UL 2 1. Grasp the head end and hold it with the motor to the inside of the transport set. 2. Slide the bedframe tube over de short tube (1) on the transport set.
-
Page 16: Lifting Pole (Optional)
Luna 2, Luna Basic 2, Luna UL 2 2021-03 Assembly Lifting pole (optional) The lifting pole can be mounted on either side of the head end. 1 = Lifting pole 2 = Socket 3 = Groove 4 = Upper frame lifting pole... - Page 20 No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without written permission of the publisher, or processed, duplicated or distributed by using electronic systems. © Vermeiren Group 2021...
