USER GUIDE
SAFETY • INSTALLATION & INTEGRATION • OPERATING INSTRUCTIONS • MAINTENANCE • SERVICE
Integrated Panel/Integrated Frame
Cabinet
> 3-5/16"
(> 89 mm)
Floor
* Panel can extend beyond the door frame.
** A minimum of 1" (25 mm) from the floor
is required for proper ventilation.
U-Line
Unit
3-5/16" (89 mm)
to
4-5/16" (114 mm)
Extended Integrated Panel/Extended Integrated Frame
Cabinet
Integrated Panel
U-Line
Unit
3-5/16" (89 mm)
to
4-5/16" (114 mm)
U-Line
Unit
*
3-5/16" (89 mm)
to
1" (25 mm)**
Floor
u-line.com
Integrated Panel
U-Line
Unit
3-5/16" (89 mm)
to
1" (25 mm)**
Integrated Panel Dimensions 5
