- Page 1 AMS Series Gigabit Managed Switches AMS-10T2SFP AMS-26T6SFP AMS-48T4SFP AMS-24T4S4SP AMS-48T4S4SP AMS-4T24S4SP Quick Install Guide Version: 1.0.1 Oct 2012...
-
Page 2: Table Of Contents
AMS Quick Install Guide About this Guide ............................3 Compliances and Safety Statements......................4 Introduction ......................8 Overview of AMS Series Layer 2+ SNMP Managed Switches ..........8 Front View of AMS-24T6SFP .......................... 9 Rear View of AMS-24T6SFP ........................... 9 Switch Architecture ............................ - Page 3 AMS Quick Install Guide Basic Troubleshooting Tips .......................... 26 8. Power and Cooling Problems..................28 Installation ..............................28 In-band Access ............................. 28 9. Specifications ......................29...
-
Page 4: About This Guide
Internet Protocol (IP), and Simple Network Management Protocol (SNMP). Warranty The AMS series comes with a standard 3 year warranty. For full Alloy warranty terms and conditions please follow the link below: http://www.alloy.com.au/Warranty... -
Page 5: Compliances And Safety Statements
AMS Quick Install Guide Compliances and Safety Statements Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 6 AMS Quick Install Guide - Radio-frequency electromagnetic field according to IEC 61000-4- 3:2006+A1:2007+A2:2010 - Electrical fast trsnsient/burst according to IEC 61000-4-4:2010 - Surge immunity test according to IEC 61000-4-5:2005 - Immunity to conducted disturbances, Induced by radio-frequency fields:IEC 61000-4-6:2008 - Power frequency magnetic field immunity test according to IEC 61000-4-8:2009 - Voltage dips, short interruptions and voltage variations immunity test according to IEC 61000-4-11:2004...
- Page 7 AMS Quick Install Guide SAFETY PRECAUTIONS Read the following information carefully before operating the device. Please follow the following precaution items to protect the device from risks and damage caused by fire and electric power: Use the power adapter that is included with the device package. ...
- Page 8 AMS Quick Install Guide Fig. Additional arrester installed between outdoor device and this switch NOTE: The switch is indoor device; if it will be used in outdoor environment or connects with some outdoor device, then it must use a lightning arrester to protect the switch WARNING: ...
-
Page 9: Introduction
AMS Quick Install Guide 1. Introduction Overview of AMS Series Layer 2+ SNMP Managed Switches With a comprehensive range of Layer 2+, QoS, Security and OAM features, AMS series switches are the ideal solution at the edge or aggregation layer of medium to large enterprise, campus, metropolitan, and Service Provider networks. -
Page 10: Front View Of Ams-24T6Sfp
AMS Quick Install Guide Front View of AMS-24T6SFP Power LED Console TP Port LED’s SFP Port LED’s Reset 10/100/1000Base-T RJ-45 Ports 100/1G Combo SFP Ports Rear View of AMS-24T6SFP IEC Power Socket Switch Architecture The switch performs at wire-speed, non-blocking switching fabric. This allows wire-speed transport of multiple packets at low latency on all ports simultaneously. -
Page 11: Description Of Hardware
AMS Quick Install Guide 2. Description of Hardware 1000Base-T Ports The AMS Series switches contain 4x 1000BASE-T RJ-45 ports (AMS-4T24S4SFP), 24x 1000BASE-T RJ- 45 ports (AMS-24T6SFP & AMS-24T4S4SFP) or 48x 1000BASE-T RJ-45 ports (AMS-48T4SFP & AMS- 48T4S4SFP). All RJ-45 ports support automatic MDI/MDI-X operation, auto-negotiation and IEEE 802.3x auto-negotiation of flow control, so the optimum data rate and transmission can be selected automatically. - Page 12 AMS Quick Install Guide MGBIC-SLC120 9/125 1550 120Km MGBICWDMS3.02 1G TX-1310/RX-1550 MGBICWDMS5.02 1G TX-1550/RX-1310 MGBICWDMS3.20 1G TX-1310/RX-1550 20Km MGBICWDMS5.20 1G TX-1550/RX-1310 20Km MGBICWDMS3.40 1G TX-1310/RX-1550 40Km MGBICWDMS5.40 1G TX-1550/RX-1310 40Km MGBICWDMS3.80 1G TX-1310/RX-1550 80Km MGBICWDMS5.80 1G TX-1550/RX-1310 80Km 100SFP-M02 100M 62.5/125 1310 100SFP-S20...
-
Page 13: Port And System Status Led's
AMS Quick Install Guide Port and System Status LED’s The AMS Series switches include a display panel for system and port indications that simplify installation and network troubleshooting. The LEDs are located on left hand side of the front panel or over the port sockets for easy viewing. -
Page 14: Power Sockets On Ams-4T24S4Sfp
AMS Quick Install Guide Power sockets on AMS-4T24S4SFP IEC Power Socket 48VDC Power Socket 3. Network Planning Installing the Switch Selecting a site The AMS Series switches can be rack mounted in a standard 19” equipment rack using the supplied Rack Mount Kit, or they can be installed on any flat surface. -
Page 15: Ethernet Cabling
AMS Quick Install Guide Ethernet Cabling To ensure proper operation when installing the switch into a network, make sure that the current cables are suitable for 100BASE-TX or 1000BASE-T operation. Check the following criteria against the current installation of your network: ... -
Page 16: Mounting
AMS Quick Install Guide WARNING: The mini-GBICs are Class 1 laser devices. Avoid direct eye exposure to the beam coming from the transmit port. Mounting The switch can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site as follows. -
Page 17: Desktop Mounting
AMS Quick Install Guide 2. Mount the device in the rack using four rack-mounting screws (not provided). Be sure to secure the lower rack-mounting screws first to prevent the brackets from being bent by the weight of the switch. 3. If installing a single switch, turn to “Connecting to a Power Source” at the end of this chapter. 4. -
Page 18: Installing An Optional Sfp Module
SFP module. CAUTION: Use only supported genuine Alloy SFP’s with your switch. Non-Alloy SFP’s might have compatible issues, and their use may result in product malfunction. Inserting a SFP Module into a slot 1. Consider network and cabling requirements to select an appropriate SFP transceiver type. -
Page 19: Connecting To A Power Source
AMS Quick Install Guide Connecting to a power source To switch the power off, please remove the power cord from the switch. To turn the power on, please insert the power cable into the switch. Inserting the power cord to switch and AC power socket 1. - Page 20 AMS Quick Install Guide Switch’s 8-Pin Serial Port Null Modem PC’s 9-Pin DTE Port ----------------- 2 RXD (receive data) 3 TXD (transmit data) 3 RXD (receive data) ----------------- 2 RXD (receive data) 5 SGND (Signal ground) ------------------- 5 SGND (Signal ground) NOTE: No other pins are used.
-
Page 21: Operation Of Web-Based Management
AMS Quick Install Guide 4. Operation of Web-based Management The default values of the AMS Series switches are listed in the table below: IP Address 192.168.1.1 Subnet Mask 255.255.255.0 Default Gateway 192.168.1.254 Username admin Password To access the web management of an AMS Series switch enter the default IP Address in web browser and hit enter. -
Page 22: Making Network Connections
AMS Quick Install Guide 5. Making Network Connections Connecting Network Devices The AMS Series switches are designed to be connected to 10, 100 or 1000Mbps network cards in PCs and servers, as well as to other switches and hubs. It may also be connected to remote devices using optional SFP transceivers. -
Page 23: Connecting To Pc's, Servers And Switches
AMS Quick Install Guide Connecting to PC’s, Servers and Switches 1. Attach one end of a twisted-pair cable segment to the device’s RJ-45 connector. 2. If the device is a network card and the switch is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet. -
Page 24: Network Wiring Connections
AMS Quick Install Guide Network Wiring Connections Today, the punch-down block is an integral part of many of the newer equipment racks. It is actually part of the patch panel. Instructions for making connections in the wiring closet with this type of equipment follows. -
Page 25: Fibre Optic Sfp Devices
AMS Quick Install Guide Fibre Optic SFP Devices An optional Gigabit SFP transceiver can be used for a backbone connection between switches, or for connecting to a high-speed server. Each single-mode fibre port requires 9/125 micron single-mode fibre optic cable with an LC connector at both ends. -
Page 26: Cable Labeling And Connection Records
AMS Quick Install Guide 6. Cable Labeling and Connection Records When planning a network installation, it is essential to label the opposing ends of cables and to record where each cable is connected. This will allow users to easily locate inter-connected devices, isolate faults and change your topology without need for unnecessary time consumption. -
Page 27: Troubleshooting
AMS Quick Install Guide 7. Troubleshooting Basic Troubleshooting Tips Most problems are caused by the following situations. Check for these items first when starting your troubleshooting: Connecting to devices that have a fixed full- duplex configuration. The RJ-45 ports are configured as “Auto”. That is, when connecting to attached devices, the switch will operate in one of two ways to determine the link speed and the communication mode (half duplex or full duplex): ... - Page 28 AMS Quick Install Guide Check the port configuration. A port on your Switch may not be operating as you expect because it has been put into a “ blocking” state by Spanning Tree, GVRP (automatic VLANs), or LACP (automatic trunking). (Note that the normal operation of the Spanning Tree, GVRP, and LACP features may put the port in a blocking state.) Or, the port just may have been configured as disabled through software.
- Page 29 AMS Quick Install Guide 8. Power and Cooling Problems Installation If the power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet.
- Page 30 AMS Quick Install Guide 9. Specifications AMS Series Model 10T2SFP 24T6SFP 48T4SFP 24T4S4SFP 48T4S4SFP 4T24S4SFP Interface Total Ports, comprising 10x GbE 26x GbE 48x GbE 28x GbE 52x GbE 28x GbE UTP (10/100/1000Mbps) UTP/(100M/1G) SFP SFP (100M/1G) SFP+ (1G/10G) General Jumbo Frames 9Kb on Gigabit Interfaces MAC Table...
- Page 31 AMS Quick Install Guide Works with DHCP Option 82 IGMP Snooping V1, V2 and v3 . Supports 1024 Multicast Groups IGMP Querier Supported IGMP Proxy Supported MLD Snooping v1 and v2 Security v1 and v2 are supported Supported IEEE 802.1x IEEE802.1x: RADIUS authentication, authorisation and accounting, MD5 hash, guest VLAN, single/multiple host mode and single/multiple sessions.
- Page 32 AMS Quick Install Guide based on DSCP and class of service (802.1p/ CoS) Classification Port based; 802.1p VLAN priority based; IPv4/IPv6 precedence/ type of service (ToS) / DSCP based; Differentiated Services (DiffServ); classification and re-marking ACLs, trusted QoS Rate Limiting Ingress policer;...
- Page 33 AMS Quick Install Guide IEEE 802.3ah Ethernet Simple link fault management (LFM) for Ethernet as defined in IEEE 802.3ah (MAC Layer OAM) IEEE 802.1ag Ethernet IEEE 802.1ag Ethernet CFM function that provides connectivity fault management Syn-E and IEEE1588v2 Both IEEE 1588v2 and ITU-T Sync-E Ethernet synchronization protocols, and can emulate link OAM and service OAM protocols (by request).
