- Page 1 Washing Machine WMB 71001 M+ User’s Manual Document Number 2820524209 / 21-08-14.(14:12)
- Page 2 This product was manufactured using the latest technology in environmentally friendly conditions.
- Page 3 1 Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • This product can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack expe- rience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out.
- Page 4 • Place the product on a rigid, flat and level surface. • Do not place it on a long-pile rug or similar surfaces. • Do not place the product on a high platform or near the edge on a cascaded surface. •...
- Page 5 1.6 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal domestic and other wastes at the end of its servi- ce life.
- Page 6 2.4 Connecting water supply InformatIons The water supply pressure required to run the product is between 1 to 10 bars (0.1 – 1 MPa). It is necessary to have 10 – 80 liters of water flowing from the fully open tap in one minute to have your machine run smoothly.
- Page 7 • Use faster programmes for small quantities of lightly soiled WarnInG laundry. • Do not use high temperatures for laundry that is not heavily Damaged power cables must be replaced by the Authorized Service soiled or stained. Agents. • Do not use detergent in excess of the amount 2.8 first use recommended on the detergent package.
- Page 8 3.7 Choosing the detergent type Laundry types and their average weights in the following table are given as examples. The type of detergent to be used depends on the type and colour of the fabric. Laundry type Weight (g) • Use different detergents for coloured and white laundry. Bathrobe 1200 •...
- Page 9 3.10 tips for efficient washing Clothes Delicates/ Light colours and whites Colours Dark colours Woolens/Silks (Recommended (Recommended (Recommended temperature (Recommended temperature temperature range temperature range range based on soiling level: range based on soiling level: based on soiling level: based on soiling level: 40-90ºC) cold-40ºC) cold-40ºC)
-
Page 10: Cottons
4 operating the product 4.1 Control panel 1 - Programme Selection knob (Uppermost position On / Off) 2 - Door open indicator 3 - Programme Follow-up indicator 4 - Start / Pause button 5 - Spin Speed Adjustment button 4.2 Preparing the machine •... -
Page 11: Mini
• mini Use this programme to wash your lightly soiled cotton clothes in a short time. • Cottons with Prewash Prefer this programme only for heavily soiled cotton clothes. InformatIons Not using this programme with prewash will save energy, water, detergent and time. -
Page 12: Table Of Contents
4.8 Programme and consumption table Programme Cottons with Prewash 1.65 1400 2.10 1400 Cottons 0.66 1400 Cold 0.15 1400 60** 1.14 1400 Cottons Eco 60** 0.94 1400 40** 0.72 1400 1.10 Synthetics 0.58 Cold 0.11 Delicates 0.32 Woollens 0.40 Hand Wash 0.20 Mini 30 0.21... - Page 13 4.9 starting the programme 4.11 Cancelling the programme Press Start / Pause button to start the programme. To cancel the programme, turn the Programme Selection knob Programme follow-up light showing the startup of the to select another programme. Previous programme will be programme will turn on.
- Page 14 5 maintenance and cleaning 5.3 Cleaning the body and control panel Wipe the body of the machine with soapy water or non- Service life of the product extends and frequently faced corrosive mild gel detergents as necessary, and dry with a problems decrease if cleaned at regular intervals.
- Page 15 Open the filter cover by pulling it from both sides at the top. InformatIons You can remove the filter cover by slightly pushing downwards with a thin plastic tipped tool, through the gap above the filter cover. Do not use metal tipped tools to remove the cover. Follow the steps below to discharge the water.
- Page 16 6 technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Beko Model name WMB71001M+ Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 1.142...
- Page 17 7 troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. Previous programme will be cancelled.
