- Page 1 Washing Machine User’s Manual WMB 81433 LM Document Number= 2820524361_EN / 12-10-15.(11:54)
-
Page 2: Important Instructions For Safety And Environment
1 Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. 1.1 General safety • This product can be used by children at and above 8 years old and by persons whose physical, sensory or mental capabilities were not fully developed or who lack expe- rience and knowledge provided that they are supervised or trained on the safe usage of the product and the risks it brings out. -
Page 3: Intended Use
• The product must be unplugged during installation, maintenance, cleaning and repai- ring procedures. • Always have the installation and repairing procedures carried out by the Authorized Service Agent. Manufacturer shall not be held liable for damages that may arise from procedures carried out by unauthorized persons. -
Page 4: Compliance With Weee Directive
recycling of electrical and electronic equipment. Please consult your local authorities to learn the nearest collection point. Help protect the environment and natural resour- ces by recycling used products. For children's safety, cut the power cable and break the locking mechanism of the loading door so that it will be non-functional before dis- posing of the product. -
Page 5: Removing The Transportation Locks
2.3 Removing the transportation locks 2.4 Connecting water supply The water supply pressure required to run the product is WARNING: Do not remove the transportation locks between 1 to 10 bars (0.1 – 1 MPa). It is necessary to before taking out the packaging reinforcement. have 10 –... - Page 6 2. Tighten all hose nuts by hand. Never use a tool when the connection between the extension hose and the tightening the nuts. drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak. 2.6 Adjusting the feet WARNING: In order to ensure that the product...
- Page 7 3 Preparation 3.4 Initial use Before starting to use the product, make sure that all 3.1 Sorting the laundry preparations are made in accordance with the instructions in • Sort laundry according to type of fabric, colour, and sections “Important safety instructions” and “Installation”. degree of soiling and allowable water temperature.
- Page 8 Detergent Drawer problems of excessive foam, poor rinsing, financial The detergent drawer is composed of three compartments: savings and finally, environmental protection. – (1) for prewash • Use lesser detergent for small amounts or lightly soiled – (2) for main wash clothes.
-
Page 9: Tips For Efficient Washing
Using starch Clothes • Add liquid starch, powder starch or the fabric dye into the Colours softener compartment. (Recommended temperature range based • Do not use softener and starch together in a washing on soiling level: cold -40 °C) cycle. •... -
Page 10: Operating The Product
4 Operating the product 4.1 Control panel 1 - Programme Selection knob (Uppermost position On / Off) 5 - Start / Pause button 2 - Display 6 - Auxiliary Function buttons 3 - Delayed Start Indicator 7 - Spin Speed Adjustment button 4 - Programme Follow-up indicator 8 - Temperature Adjustment button 4.2 Preparing the machine... -
Page 11: Special Programmes
• Hand wash • Spin + Drain Use this programme to wash your woolen/delicate clothes Use this programme to apply an additional spin cycle for that bear “not machine- washable” tags and for which hand your laundry or to drain the water in the machine. wash is recommended. -
Page 12: Programme And Consumption Table
4.9 Programme and consumption table Auxiliary functions Selectable Programme temperature range °C Cottons 2.30 1600 • • • • • • Cold-90 Cottons 1.65 1600 • • • • • • Cold-90 Cottons 0.82 1600 • • • • • •... -
Page 13: Auxiliary Function Selection
4.10 Auxiliary function selection If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button. Select the required auxiliary functions before starting Program resumes. Water is drained, laundry is spun and the the program. - Page 14 3. Press Start / Pause button to start the programme. If the machine does not pass to the spinning step, Rinse Hold function might be active or the automatic unbalanced 4.11 Starting the programme load detection system might be activated due to the 1.
-
Page 15: Maintenance And Cleaning
3 After cleaning, replace the siphon back to its seating and Depending on the step where the programme was push its front section downwards to make sure that the canceled in, you may have to put detergent and softener locking tab engages. again for the programme you have selected anew. -
Page 16: Cleaning The Water Intake Filters
5.4 Cleaning the water intake filters In order to clean the dirty filter and discharge the water: There is a filter at the end of each water intake valve at the 1 Unplug the machine to cut off the supply power. rear of the machine and also at the end of each water intake hose where they are connected to the tap. -
Page 17: Technical Specifications
6 Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark Beko Model name WMB 81433 LM Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) -
Page 18: Troubleshooting
7 Troubleshooting Program does not start after closing the door. • Start / Pause / Cancel button was not pressed. >>> *Press the Start / Pause / Cancel button. Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> To cancel the programme, turn the Programme Selection knob to select another programme. - Page 19 Cotton Woollens Hand BabyProtect Dark wash Dark wash Duvet Wash (Darkcare) (Darkcare) (Bedding) Extra rinse Quick Time delay Pre-wash Night mode Mixed 40 Drain Rinse Freshen (Rinse Plus) wash (Mix40) (Pump) Daily Shirts Super short Spin Delicate 20° 40° 40’ Hygiene 20°...
- Page 20 www.beko.com...
