F E A T U R E S D I A G R A M
6
1
4
5
11
13
Hub (inside)
14. Turntable
(glass)
16. Coupling
ACCESSORIES:
Check to make sure the following accessories are
provided:
(14) Turntable (15) Turntable support (16) Coupling
Place the coupling into the turntable motor shaft and then place
the turntable support in the centre of the oven floor so that it can
freely rotate around the coupling. Place the turntable onto the
turntable support so that it locates firmly into the coupling. To
avoid turntable damage, ensure dishes and containers are lifted
clear of the turntable rim when removing them from the oven.
NOTE: When you order accessories, please mention two items: part
name and model name to your dealer or SHARP authorised service
agent.
2
10
3
7
8
4
12
15. Turntable
support
OVEN
1.
Door handle
2.
Oven lamp
3.
Door hinges
4.
Door safety latches
5.
Door
9
6.
Door seals and sealing surfaces
7.
Turntable motor shaft
8.
Oven cavity
9.
Control panel
10. Waveguide cover (DO NOT REMOVE)
11. Power supply cord
12. Ventilation openings
13. Outer cabinet
8
