- Page 1 NAS HDD Product Manual ST8000VN0012 ST6000VN0031 ST4000VN003 ST3000VN002 ST2000VN001 ST1000VN001 100764115, Rev. H January 2018...
-
Page 2: Document Revision History
Publication number: 100764115, Rev. H January 2018 Seagate, Seagate Technology and the Spiral logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Rescue and SeaTools are either trade- marks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other trademarks or registered trademarks are the property of their respective owners. -
Page 3: Table Of Contents
Seagate® Rescue™ Data Recovery Service ........ - Page 4 S.M.A.R.T. commands............. . 39 Seagate NAS HDD +SRS Product Manual, Rev. H...
- Page 5 Mounting dimensions (2TB,3TB and 4TB) ............30 Seagate NAS HDD +SRS Product Manual, Rev. H...
-
Page 6: Seagate® Technology Support Services
For information regarding online support and services, visit: http://www.seagate.com/contacts/ For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/recover/ For Seagate OEM, Distribution partner and reseller portals, visit: http://www.seagate.com/partners/ Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 7: Introduction
1.0 Introduction This manual describes the functional, mechanical and interface specifications for the following: Seagate® NAS HDD model drives: ST8000VN0012 ST6000VN0031 ST4000VN003 ST3000VN002 ST2000VN001 ST1000VN001 These drives provide the following key features: • 24x7 capability • Balance technology to support multiple drives in a system •... -
Page 8: About The Sata Interface
Note (slave) accessed at the same set of host bus addresses. A host adapter that emulates a master/slave environment manages two sets of shadow registers. This is not a typical SATA environment. Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 9: Drive Specifications
Operating temperature (drive case max °C) 20°C per hour max (operating) Temperature gradient 30°C per hour max (nonoperating) 5% to 90% (operating) Relative humidity 5% to 95% (nonoperating) Relative humidity gradient (max) 30% per hour Seagate NAS HDD +SRS Product Manual, Rev. H... - Page 10 *** During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. † Seagate does not recommend operating at sustained case temperatures above 60C. Operating at higher temperatures will reduce useful life of the product. Seagate NAS HDD +SRS Product Manual, Rev. H...
- Page 11 (–1000 ft to 10,000 ft) Altitude, non-operating –304m to12,192m (below mean sea level, max) (–1000ft to 40,000+ ft) Operational Shock (max) 80 Gs at 2ms Non-Operational Shock (max) 300 Gs at 2ms Seagate NAS HDD +SRS Product Manual, Rev. H...
-
Page 12: Formatted Capacity
When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. See Section 4.3.1, "Identify Device command" (words 60-61 and 100-103) for additional information about 48-bit addressing support of drives with capacities over 137GB. Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 13: Default Logical Geometry
Internal data transfer rate (Mb/s max) 2147 2TB, 3TB and 4TB 1813 1981 2546 Maximum sustained data transfer rate, OD read (MB/s) 1TB and 2TB 3TB and 4TB 6TB and 8TB I/O data-transfer rate (MB/s max) Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 14: Physical Characteristics
Ready to spindle stop (in seconds) 12 (max) 23 (max) 10 (typical) / 11 (max) Time-to-ready may be longer than normal if the drive power is removed without going through normal OS power down procedures. Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 15: Power Specifications
Avg 5V typ amps Avg 12V typ amps Power dissipation (2-disk values shown) — — Spinup 3.56 0.171 0.225 Idle* † 4.30 0.308 0.233 Operating 0.50 0.09 0.005 Standby 0.50 0.09 0.005 Sleep Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 16: Conducted Noise
10MHz. Equivalent resistance is calculated by dividing the nominal voltage by the typical RMS read/write current. Note 2.8.3 Voltage tolerance Voltage tolerance (including noise): • 5V ±5% • 12V ±10% Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 17: Power-Management Modes
If the standby timer reaches zero before any drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all com- mands and returns to Active mode when disk access is necessary. Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 18: Environmental Specifications
† Operating (Drive case max °C) 70° † Seagate does not recommend operating at sustained case temperatures above 60C. Operating at higher temperatures will reduce useful life of the product. 2.9.3 Temperature gradient Operating 20°C per hour (68°F per hour max), without condensation Non-operating 30°C per hour (86°F per hour max) -
Page 19: Shock
The maximum non-operating vibration levels that the drive may experience without incurring physical damage or degradation in performance when subsequently put into operation are specified below. 5Hz to 22Hz 3.0 Gs (Limited displacement) 22Hz to 350Hz 3.0 Gs 350Hz to 500Hz 3.0 Gs Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 20: Acoustics
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389-7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 21: Electromagnetic Immunity
I/O duty cycle affect the product MTBF. The MTBF will be degraded if used in an enterprise application. 2.12.1 Storage Maximum storage periods are 180 days within original unopened Seagate shipping package or 60 days unpackaged within the defined non-operating limits (refer to environmental section in this manual). Storage can be extended to 1 year packaged or unpackaged under optimal environmental conditions (25°C, <40% relative humidity non-condensing, and... -
Page 22: Seagate Rescue Data Recovery Service
3-year coverage (concurrent with bare drive warranty) If you suffer a data loss event within the three year Seagate Rescue Data Recovery warranty period, and you are eligible to participate in and submit a case under the Rescue program, contact SRS at (1-800-723-1183) in the US, or if you are calling from outside the US please visit our website for numbers in your local and language: http://www.seagate.com/contacts/contact-numbers/. - Page 23 Seagate reserves the right to refuse service to or the return of any storage devices that have been determined to violate these regulations.
-
Page 24: Agency And Safety Certifications
Interference/Electromagnetic Susceptibility (EMI/EMS) for Class B products. The selected system represents the most popular characteristics for test platforms. Although the test system with this Seagate model complies with the directives/standards, we cannot guarantee that all systems will comply. The computer manufacturer or system integrator shall confirm EMC compliance and provide the appropriate marking for their product. -
Page 25: Australian Rcm Compliance Mark
2.14.8 Morocco Commodity Mark To satisfy our OEM customers, Seagate has added the Moroccan Commodity Mark to the drives provided to the OEM for the sale of Customer Kits produced by our OEM customers that are intended to be incorporated into the OEM's finished system-level product by an end user. -
Page 26: Fcc Verification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 27: China Requirements -China Rohs 2
The European Union REACH (Registration, Evaluation, Authorization and Restriction of Chemicals) Regulation (EC) 1907/ 2006 regulates chemicals shipped into and used in Europe. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of REACH substances in these articles and materials. -
Page 28: Taiwan Requirements - Taiwan Rohs
Seagate recommends that data centers be kept clean by monitoring and controlling the dust and gaseous contamination. Gaseous contamination should be within ANSI/ISA S71.04-2013 G2 classification levels (as measured on copper and silver coupons), and dust contamination to ISO 14644-1 Class 8 standards, and MTBF rated conditions as defined in the Annualized Failure Rate (AFR) and Mean Time Between Failure (MTBF) section. -
Page 29: Configuring And Mounting The Drive
For installations which require cables, users can connect the drive as illustrated in Figure 1 Figure 1 Attaching SATA cabling Each cable is keyed to ensure correct orientation. Seagate NAS HDD +SRS drives support latching SATA connectors. Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 30: Drive Mounting
3.750±.010 3 MIN THREAD DEPTH Temperature 4.000±.010 .1 MAX FASTENER PENETRATION MOUNTING HOLES BOTH SIDES. Check Point MAX TORQUE 6 IN/LBS 1.028 MAX 26.11 MM .142±.015 2 2.000 C L OF DRIVE Seagate NAS HDD +SRS Product Manual, Rev. H... - Page 31 1.028 in max 26.11 mm 3X 6-32 UNC-2B 3x 0.250 ± .010 in 3 MIN THREAD DEPTH .140 0.45 MAX FASTENER PENETRATION 6.35 ± .25 mm MOUNTING HOLES BOTH SIDES BOTH SIDES Seagate NAS HDD +SRS Product Manual, Rev. H...
-
Page 32: Sata Interface
4.1 Hot-Plug compatibility Seagate NAS HDD +SRS drives incorporate connectors which enable users to hot plug these drives in accordance with the SATA Revision 3.2 specification. This specification can be downloaded from www.serialata.org. 4.2 SATA device plug connector pin definitions Table 11 summarizes the signals on the SATA interface and power connectors. -
Page 33: Supported Ata Commands
Read Sectors Without Retries Read Verify Sectors Read Verify Sectors Extended Read Verify Sectors Without Retries Recalibrate Security Disable Password Security Erase Prepare Security Erase Unit Security Freeze Security Set Password Security Unlock Seek Seagate NAS HDD +SRS Product Manual, Rev. H... - Page 34 Write DMA Extended Write DMA FUA Extended Write DMA Without Retries Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Uncorrectable Seagate NAS HDD +SRS Product Manual, Rev. H...
-
Page 35: Identify Device Command
Number of current logical heads xxxx Number of current logical sectors per logical track xxxx 57–58 Current capacity in sectors xxxx Number of sectors transferred during xxxx a Read Multiple or Write Multiple command Seagate NAS HDD +SRS Product Manual, Rev. H... - Page 36 Ultra DMA support and current mode xx7F (see note following this table) Security erase time 0039 Enhanced security erase time 0039 Master password revision code FFFE Hardware reset value xxxx Automatic acoustic management 8080 Seagate NAS HDD +SRS Product Manual, Rev. H...
- Page 37 Multiword DMA mode 2 is currently active. Word 84 SMART error login is supported. SMART self-test is supported. Media serial number is supported. Media Card Pass Through Command feature set is supported. Seagate NAS HDD +SRS Product Manual, Rev. H...
- Page 38 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate NAS HDD +SRS Product Manual, Rev. H...
-
Page 39: Set Features Command
Disable use of SATA features Enable read look-ahead (read cache) feature (default). Report full capacity available At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate NAS HDD +SRS Product Manual, Rev. H... -
Page 40: Commands
S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x04 (abort) is written to the Error register. Seagate NAS HDD +SRS Product Manual, Rev. H... - Page 41 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100764115, Rev. H...
