RS900/RS901
RS999 FM FLASHBACK™
NEW FEATURES!
Timed Crank mode,
Diesel Delay time, &
Pos. or Neg. glow
plug input.
Congratulations on your choice of a Crimestopper CoolStart™ remote engine starter! This installation Handbook covers
the following models: RS900 V Remote Start & Keyless Entry System, RS901 Upgrade/Expansion module (No remotes
or antenna), and the 2-Way RS999FM system with Flashback paging technology.
This installation book is designed for the installer or individual with an existing understanding of automotive electrical
systems, along with the ability to test and connect wires for proper operation. To ease installation, we suggest that you
READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDLINE and the
information contained herein may differ from your vehicle.
DISCLAIMER:
Crimestopper Security Products, Inc. and its vendors shall not be liable for any accident resulting from the use of this
product. This system is designed to be professionally installed into a vehicle in which all systems and associated
components are in perfect working condition.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV B 09.2002 S/W: RS900V=614, RS999FM=594
SERIES V
REMOTE ENGINE STARTING SYSTEM
INSTALLATION INSTRUCTIONS
INTRODUCTION
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.
Advertisement
Table of Contents
Related Manuals for CrimeStopper RS-901.V
Summary of Contents for CrimeStopper RS-901.V
- Page 1 DISCLAIMER: Crimestopper Security Products, Inc. and its vendors shall not be liable for any accident resulting from the use of this product. This system is designed to be professionally installed into a vehicle in which all systems and associated components are in perfect working condition.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Pre-Installation Considerations……….………...……...………………………………………………………………..………2 Cautions & Warnings…….……………...….……..…..……………………………………………………………….…………3 Wiring……..……………………………...……………………………………………………………………………….…….3- Ignition Switch Wiring…………….……………………...……………………………………………………………….…….6- Power Door Lock Wiring...…………………………………………….…………….……..…………...………………..……8- Smart Tachless, Tach Reference, Tach Finder, & Timed Crank Modes……………………..…..………...……………9- Diesel Glow Plug Delay..………………….………………………………………...………………………..…………………13 Programming Options……...……………………….……………………………………...……………..…………………13- Transmitter / Transceiver Programming……………………….………………………….…………...………...………...….18 2 Vehicle Operation.……………………………….…………………………………………...…………………….…………19 Troubleshooting “Before You Call” Section……………..………………………………..………………….………….…….20 Jumper Pin, Antenna, &... -
Page 3: Cautions & Warnings
PLAN OUT YOUR INSTALLATION and determine most suitable locations for all components to be placed. These components include: the module itself, valet/program button, possible relays, and antenna/receiver (RS900/999FM only, RS901 model does not include antenna or remotes.) Allow enough wire to create a service loop with strain relief, should servicing be required. - Page 4 PIN 3: YELLOW/BLACK: (-) IGNITION OUTPUT -or- ANTI-GRIND/STARTER DISABLE OUTPUT This negative output wire is programmable and can function two different ways. It can be used as a Negative Ignition output for GM Anti-theft and Transponder Bypass modules, or it can be programmed to function as an Anti grind/Starter Disable output.
- Page 5 MOTOR START PIN 4: BROWN: (-) AUX OUTPUT (TRUNK POP) This output will provide a ground pulse when button #3 (Trunk) on the remote transmitter is pushed to activate a factory electric trunk release or other optional accessory. System can also be programmed to DISARM/UNLOCK when trunk pop is activated to prevent unnecessary triggering of Factory Alarm systems.
- Page 6 wire is used, the RS900/901/999FM system will wait until light turns off before attempting a remote start. Note: This input is jumper selectable for Positive or Negative type signals. See system wiring diagram for jumper configuration. PIN 8: PURPLE: (+12V) BRAKE RESET Connect the Purple wire to the side of brake pedal switch that shows +12 volts ONLY when pedal is depressed.
- Page 7 (2) RED: +12V POWER INPUT WIRES (30A Fused): Connect to both of these leads to +12V Constant Power. We recommend the BATTERY POSTIVE TERMINAL. PINK: +12V IGNITION OUTPUT 30A: Connect to circuit in the vehicle that provides true Ignition Power for systems such as Spark and Fuel. Typically, this wire turns ON with the second position of the key, STAYS ON WHEN CRANKING, and continues ON as the vehicle runs.
- Page 8 7-PIN High Current Connector PARKING LIGHTS WHITE FUSE (+) or (-) PINK/WHITE FUEL ENGINE PUMP COIL IGN 2 ACC 2 STRT 2 IF NECESSARY NOTE: Heavy duty/High Current Ignition circuits greater than 30 AMPS. Industrial vehicles, dual AC, etc. require high- current relays.
- Page 9 POSITIVE TRIGGER DOORLOCK WIRING GREEN FACTORY POWER LOCKING RELAYS Crimestopper Doorlock Accessories: CS-6600DLM: Dual-relay plug-in module for Reverse Polarity, Positive, or Aftermarket Motors. CS-6500DLI: Plug-in pulse inverter that converts the Negative outputs of the system to Positive type for Positive Door Lock systems.
-
Page 10: "Smart Tachless" Mode
REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE MASTER SWITCH This RS900/901/999FM systems includes a unique voltage monitor system called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. These modules actively monitor the voltage level of the vehicle to control the starter motor each time a remote start is requested. - Page 11 HOW to REDUCE “SMART TACHLESS” CRANKING TIME: In the event “Smart Tachless” mode slightly over-cranks the starter motor, the settings can be changed. The purpose of adjusting the “Smart Tachless” Mode, is to lower the voltage reference threshold [required by the unit] which reduces the cranking time.
- Page 12 TACH FINDER MODE: This CoolStart system includes a Tach Finder mode to assist in locating a valid or viable tach source for your installation. Follow the Tach Finder steps below to locate and /or verify a tach signal. When following the steps, the unit will begin to flash the parking lights if you have the Red/White wire connected to a valid tach source.
-
Page 13: Diesel Glow Plug Delay
This new feature provides an easy method of starting the vehicle without locating an exact tach wire. It uses a timed cranking output combined with the use of the Red/White tach wire as an engine ON/OFF monitor. The Red/White Tach wire must still be used in this mode of operation. -
Page 14: Programming
This new feature provides a solution for diesel vehicle without having to connect to the Glow Plug-“Wait to Start Circuit”. This may be due to a variety of reasons. If your vehicle does not have a viable “Wait to Start Circuit”, or you cannot locate and identify the circuit, then change your system to “Diesel Glow Plug Delay”... - Page 15 Option Option Description Tach Learning Autolock with Ignition Door Lock Pulse Time Double Unlock Pulse OEM Interface (RS901 MODEL ONLY) Passive Starter Disable Horn Chirps on remote start ON or OFF Lock During and After Remote Start Abort Smart Tachless Reference Voltage Setting #9 Smart Tachless Reference Voltage Setting #10...
-
Page 16: Programmable Options
PROGRAMMABLE OPTIONS CHART CONTINUED Diesel Glow Plug Delay Remote Start Engine Run Time Option reset 1. Tach Learning: The unit will program the Tach signal from the Red/White wire when button 2 is pressed at this option level. See pages 9-10 Tach Ref/Tach programming. - Page 17 PROGRAMMABLE OPTIONS 6. Passive Starter Disable: Note: Yellow/Black Negative Output must be programmed as an “Anti-Grind” for this feature. See option 12. This option controls the unit’s Negative Anti-Grind output allowing it to come on automatically 1 min after the ignition has been turned off.
-
Page 18: Programmable Option Reset
16. Pre-Set Starter Cranking Time: (Requires Option #15 in “Timed Crank” Setting) This option controls the starter output cranking time. Choices are 0.5, 0.75, 1.25, or 1.50 seconds. 17. Diesel Glow Plug Delay: This option controls the system’s Diesel vehicle interface. Using this option you can control whether the unit monitors the vehicle’s glow plug circuit using the Pink input wire (Default), or you may select a specific delay time before cranking. - Page 19 900 V TRANSMITTER / 999FM TRANSCEIVER CODE LEARNING Transmitter/Transceiver Code Learning: (Excludes RS901) Note: Remote Transmitters/Transceivers come pre-programmed from the Factory. When re-learning remotes or adding remotes, ALL your system’s remote codes must be learned at time of programming!! These systems allow storage of up to 4 different remote codes in memory.
-
Page 20: Vehicle Operation
2-VEHICLE OPERATION Both the RS-900 V and RS-999FM systems can be used for 2 car operation. A single RS900V remote can control two independent vehicles with RS900 V systems installed. A single RS-999FM transceiver remote can operate two independent cars with RS-999FM systems installed. NOTE: These systems ARE NOT interchangeable. -
Page 21: Troubleshooting "Before You Call" Section
TROUBLESHOOTING: “BEFORE YOU CALL” SECTION UNIT WILL NOT ATTEMPT A START (KEYLESS ENTRY FUNCTIONS NORMALLY): The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for about 6 seconds then turn key off. Unit is now out of valet mode and should perform a remote start. If optional LED is installed, then it will be on solid when in Valet. - Page 22 Jumper pins are used to change/configure the operation of the on board multi-function output PINK/WHITE wire, the Parking Light WHITE wire and the PINK glow plug input wire. See the diagrams below for Jumper Pin configurations. CONTROL MODULE JP1 JUMPERS: IGN2 / ACC2 / STR2 PINK WHITE JUMPER PIN DIAGRAMS...
-
Page 23: Antenna Diagram
GLOW PLUG PINK WIRE: Jumper Select for Postive or Negative Type "Wait" Circuits ANTENNA DIAGRAM... - Page 24 ANTENNA LOCATIONS WINDSHIELD White Plug RS-900 V RS-999FM Black Plug...
- Page 25 COIL TRANSMISSION ENGINE START #2 JUMPER STARTER SELECT +/- PARKING LIGHT JUMPER RS900/901 SERIES ANTENNA/RECEIVER PLUG (OPTIONAL) (-) UNLOCK OUTPUT PROGRAM +12 V FOR RELAYS SWITCH (-) LOCK OUTPUT NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL PUMP H/V/AC CONTROL (If necessary) BROWN GRAY PINK...
