To ease and reduce installation time, we suggest you consider the following points before starting:
1. Determine most suitable locations for all components to be placed. These components include: the module itself,
valet/program button, possible relays, and antenna/receiver (RS900ER III only).
2. Allow enough wire to create a service loop with strain relief, should servicing be required. This will also allow easier
access and mounting.
3. Use a Volt/Ohm meter to test and locate all connections. Test Lights can damage a vehicle's computer systems.
4. Record all color codes of vehicle wiring to be used for reference. This will save time by not having to re-test the same
wires over again.
5. Additional Parts, which are not included with this unit, may be needed for your particular vehicle. These items may
include extra relays, Anti-Theft System Bypass modules, or Transponder Bypass modules.
TECHNICAL SUPPORT: 1-800-998-6880
Monday - Friday 8:00am - 4:30pm Pacific Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
RS900ERIII/RS901III
SERIES
REMOTE ENGINE STARTING SYSTEM
INSTALLATION INSTRUCTIONS
PRE-INSTALLATION CONSIDERATIONS
III
This device complies with FCC Rules part 15. Operation is subject
to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any
interference that may be received, including interference that may
cause undesired operation. The manufacturer is not responsible
for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modification could void the
user's authority to use the equipment.
Advertisement
Table of Contents
Related Manuals for CrimeStopper RS-901.III
Summary of Contents for CrimeStopper RS-901.III
-
Page 1: Installation Instructions
Anti-Theft System Bypass modules, or Transponder Bypass modules. TECHNICAL SUPPORT: 1-800-998-6880 Monday - Friday 8:00am - 4:30pm Pacific Time Web Site: www.crimestopper.com E-mail: tech-support@crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. RS900ERIII/RS901III SERIES INSTALLATION INSTRUCTIONS This device complies with FCC Rules part 15. Operation is subject... -
Page 2: Installation Cautions & Warnings
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 INSTALLATION CAUTIONS & WARNINGS **FOR SAFETY REASONS, DO NOT INSTALL RS900/901 in vehicles with MANUAL TRANSMISSIONS.** If accidentally left in gear, a remote started vehicle could become a self-propelled threat to life and property. WARNING: This system does NOT have engine overrev protection. - Page 3 scrape away paint and attach using a sheet metal screw & star washer. This wire must be connected to a proper ground or undesirable and inconsistent operation will occur. YELLOW & YELLOW/WHITE: (-) IGN. / ACC. OUTPUTS YELLOW (YELLOW/WHITE) 2nd IGN 1 (2nd IGN2 /ACC WITH YEL/WHT) PIN 4: YELLOW/BLACK: (-) ANTI-GRIND/STARTER KILL OUTPUT (OPTIONAL) Use this wire for the negative side of the Anti-Grind/Starter Disable relay.
- Page 4 locked with the transmitter. The output can also be programmed to activate passively. See diagram below. WIRING INSTRUCTIONS PIN 5: TAN: (-) AUX OUTPUT (TRUNK POP) This output will provide a ground pulse when button #3 (Trunk) on the remote transmitter is pushed to activate a factory electric trunk release or other optional accessory.
-
Page 5: Ignition Switch Wiring
When installing the RS900 III in TACH REFERENCE mode, this wire must be connected to a valid source of AC voltage. This wire allows the RS900 to sense the engine and control the starter motor. 6 PIN HIGH-CURRENT CONNECTORS: PIN 1: BROWN 14 GA.: STARTER OUTPUT (30A) PIN 2: GRAY 14 GA.: ACCESSORY / IGNITION 2 (30A) -
Page 6: Power Door Lock Wiring
3 PIN DOOR LOCK PLUG: PIN 1: GREEN: (-) Negative pulse for LOCK PIN 2: RED: +12V Coil Power for external relays TERM 86. PIN 3: BLUE: (-) Negative pulse for UNLOCK DETERMINING DOOR LOCK TYPE: We recommend determining the type of locking system the vehicle has before connecting any wires. -
Page 7: "Smart" Tachless Mode
REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE MASTER SWITCH This RS900 Series III includes custom monitoring circuitry allowing the unit to start an engine without the use of a Tach Wire. The module actively monitors the vehicle over the life of the installation regardless of weather or battery conditions. The “Smart”... - Page 8 Tach source due to RF noise or Computer Data. The RS-900 may not detect a clean signal. Call Crimestopper for Tech Support if you cannot locate a proper tach source for your vehicle. “SMART” TACHLESS MODE...
-
Page 9: Transmitter Programming
TACH REFERENCE PROGRAMMING: 1. Open hood (Gray wire must be grounded). 2. Connect WHITE/RED wire to a valid Tach source. 3. Start engine with key. 4. Press program button 5 times, then wait for 5 light flashes. 5. Wait at least one second then push program button slowly (4) times, you should get a light flash after each button press. -
Page 10: Option Programming
This system has several installer programmable features as listed in the chart below. Option Programming: 1. Open hood (Gray wire grounded) 2. Turn Key to the ON position 3. Press program / valet button 5 times, after a few seconds the unit will flash the lights 5 times. 4. -
Page 11: Remote Start Troubleshooting
REMOTE START TROUBLESHOOTING UNIT FLASHES LIGHTS ONCE AND WILL NOT ATTEMPT A START: The unit is in Valet mode. Turn IGN ON, press and hold valet/programming button for about 4 seconds unit LED goes out. Unit is now out of valet mode and should perform a remote start. UNIT FLASHES LIGHTS TWICE AND WILL NOT ATTEMPT A START: The unit sees a fault at the Brake (Purple wire is active) or the Hood is OPEN (Gray wire grounded). - Page 12 ENGINE TRANSMISSION COIL PARKING LIGHTS 12A MAX. SMART TACH JUMPERS RS-900ER SERIES III ANTENNA/ RECEIVER PLUG (-) LOCK OUTPUT PROGRAM/ +12 V FOR RELAYS OVERRIDE SWITCH (-) UNLOCK OUTPUT NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL PUMP H/V/AC CONTROL IGN 1 WHITE BROWN GRAY...
