CrimeStopper RS-901.II Installation Instructions Manual

CrimeStopper RS-901.II Installation Instructions Manual

Remote engine starting system
Hide thumbs Also See for RS-901.II:
Table of Contents

Advertisement

Quick Links

This Remote Start Module provides the following features:
SELECTABLE ENGINE SPEED SENSING:
Tach & "Smart Tachless" Modes
DYNAMIC CODE:
Anti-Code Grabbing Protection
PROGRAMMABLE RUN TIME:
12, 24, 36, or 48 minutes
VALET MODE / OVERRIDE
4 ON-BOARD RELAYS:
Main Ignition (IGN1)
IGN2 / Accessory
Starter
Parking Light
REMOTE KEYLESS ENTRY:
Controls power door locks
CODE / TACH LEARNING CIRCUITRY
RS900ERII/RS901II
SERIES II
REMOTE ENGINE STARTING SYSTEM

INSTALLATION INSTRUCTIONS

DEDICATED OUTPUTS FOR:
OEM Factory Alarm Disarm
OEM Factory Alarm Re-Arm
Starter Disable / Anti-Grind Output
Aux. Output (Trunk pop)
433Mhz TRANSMITTER FREQUENCY
Better range / Less RF interference
HOST ALARM ACTIVATION:
Lets an Alarm AUX trigger
a remote start
DIESEL START COMPATIBILITY
SECURITY STARTER DISABLE
HOOD / BRAKE SAFETY CIRCUITRY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-901.II and is the answer not in the manual?

Questions and answers

Related Manuals for CrimeStopper RS-901.II

Summary of Contents for CrimeStopper RS-901.II

  • Page 1: Installation Instructions

    This Remote Start Module provides the following features: SELECTABLE ENGINE SPEED SENSING: Tach & “Smart Tachless” Modes DYNAMIC CODE: Anti-Code Grabbing Protection PROGRAMMABLE RUN TIME: 12, 24, 36, or 48 minutes VALET MODE / OVERRIDE 4 ON-BOARD RELAYS: Main Ignition (IGN1) IGN2 / Accessory Starter Parking Light...
  • Page 2 Monday - Friday 8:00am - 4:30pm Pacific Time Web Site: www.crimestopper.com E-mail: tech-support@crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. 1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 To ease and reduce installation time, we suggest you consider the following points before starting.

  • Page 3: Wiring Instructions

    WIRING INSTRUCTIONS PROGRAM/OVERRIDE SWITCH: 2 PIN PLUG This switch is used primarily for programming features of the RS900/901. However, if the Anti-Grind/Starter disable feature is installed, you MUST INSTALL this switch. This switch will allow the user to override the starter disable in the event of a non-operating remote control.
  • Page 4 This is a mandatory connection. PIN 4: YELLOW/BLACK: (-) ANTI-GRIND/STARTER KILL OUTPUT Use this wire for the negative side of the Anti-Grind/Starter Disable relay. It can also be used for the sensor disable circuit for a host alarm for RS901. This output activates whenever a remote start is requested, and when the vehicle is remotely locked with the transmitter.
  • Page 5 PIN 6: GREEN: (-) START ACTIVATION TRIGGER This wire allows a host alarm (-) Negative Auxiliary Channel Output to activate a Remote Start. A one second ground pulse on this wire will trigger a remote start or turn off a remote started engine. WIRING INSTRUCTIONS PIN 7: GRAY: (-) HOOD SWITCH Connect the Gray wire to a switch that is at ground when the hood is open.
  • Page 6 Tach source. Some of the locations given may be too noisy for the system to detect a clean signal and/or the vehicle uses a Multi-spark ignition system that varies the spark. (Noisy meaning Electrical or RF interference) Call Crimestopper for Tech Support when you cannot locate a proper tach source for your vehicle.

  • Page 7: "Smart Tachless" Mode

    TACH SOURCE PROGRAMMING: 1. Open hood 2. Connect WHITE/RED wire to Ignition coil or RPM source. 3. Start engine with key. 4. Press program button 5 times, then wait for 5 light flashes. 5. Wait at least one second then push program button slowly (4) times, you should get a light flash after each button press.
  • Page 8 2) Connect the +12V input wires to the RS900 Series II. 3) The unit will automatically read and program itself for your vehicle when 12 volts is applied. SMART TACH JUMPERS: (Remove Access Door on top of module) The purpose of the jumpers is to reduce the cranking time of starter crank when in “Smart Tachless” mode only. PIN ORIENTATION: Looking at remote start upright with harnesses facing down (or towards you).

  • Page 10: Ignition Switch Wiring

    NOTE: Heavy duty Ignition circuits (greater than 30 AMPS) require high-current relays. Do not use the outputs of the RS900 Series II for High-Current systems or you will risk damaging the unit. Use Crimestopper Part #CS-403 relays for circuits up to 70 amps.

  • Page 11: Power Door Lock Wiring

    3 PIN DOOR LOCK PLUG: PIN 1: GREEN: (-) Negative pulse for LOCK PIN 2: RED: +12V Coil Power for external relays TERM 86. PIN 3: BLUE: (-) Negative pulse for UNLOCK DETERMINING DOOR LOCK TYPE: We recommend determining the type of locking system the vehicle has before connecting any wires.
  • Page 12 REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE MASTER SWITCH GROUND/OPEN LOCKING SYSTEM GREEN BLUE DOOR MICRO DOOR LOCK CONTROL MODULE SWITCH AFTERMARKET MOTOR/DOOR LOCK WIRING GREEN FUSED +12V BLUE MERCEDES-BENZ VACUUM SYSTEM GREEN FUSED +12V BLUE DOOR MICROSWITCH FUSED +12V FUSED +12V GROUND...

  • Page 13: Transmitter Programming

    Transmitter Code Learning: (Excludes RS901) Note: All transmitter codes must be learned at time of programming!! The RS900 allows storage of up to 4 different transmitter codes. 1. Open Hood. (Ground Gray wire.) 2. Turn key to the ON position. (Doors will lock if Autolock is programmed) 3.
