CONGRATULATIONS on your choice of an On-Guard Series Remote Alarm System by Crimestopper
Security Products Inc. This booklet contains the information necessary for installing, using, and maintaining
your alarm system. If any questions arise, contact your installation dealer or Crimestopper Security Products
Inc. at the Tech Support number below.
*IMPORTANT INFORMATION: Primary and Optional Features:
-PRIMARY: These are features that must be connected in order for the system to operate properly; i.e. the
Siren, L.E.D., +12V Power, Ground, Doorpin, Override/Program/Valet Button etc.
-OPTIONAL: These are features to be connected if desired or agreed upon by the installing dealer. These
features may also require additional parts and/or labor fees. Consult with your installer beforehand; i.e. Door
Locks, Flashing Lights, Starter disable, Hood/Trunk trigger, and Auxiliary Remote Outputs etc.
TECH SUPPORT
Mon-Fri 8:00 AM-4:30 PM Pacific Time
(800) 998-6880
REV. A 11.2003
CS-2000 Series III
REMOTE CONTROL ALARM SYSTEM
INSTALLATION & OPERATING INSTRUCTIONS
INTRODUCTION
This device complies with FCC Rules part 15. Operation is subject to the following
two conditions: 1) This device may not cause interference, and (2) this device
must accept any interference that may be received, including interference that may
cause undesired operation. The manufacturer is not responsible for any radio o r
TV interference caused by unauthorized modification to this equipment. Such
modification could void the user's authority to operate the equipment.
Advertisement
Table of Contents
Related Manuals for CrimeStopper CS-2000.III
Summary of Contents for CrimeStopper CS-2000.III
- Page 1 CONGRATULATIONS on your choice of an On-Guard Series Remote Alarm System by Crimestopper Security Products Inc. This booklet contains the information necessary for installing, using, and maintaining your alarm system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the Tech Support number below.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Installation Cautions & Warnings…….………………………………………………………….………………2 Control Module & Component Mounting…………….………………………..………………..….…………..3 Wiring……..…………………………………………………………………………………………………….…….4-5 Power Door Lock Wiring...…………………………………………………….………..…………………………6 Transmitter Programming…………………………………………………………………………………………7 Option Programming………………………………………….………………………………..………………….8-10 Operating Instructions………………………..……………………………………………………..……..…….11-13 Car Jack Protection…………………………………………………………….……………………..……………14 System Wiring Diagram………………………………………………………………………………..….………15 INSTALLATION CAUTIONS & WARNINGS BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS, ABS BRAKES, ENGINE COMPUTERS, BATTERY etc.). -
Page 3: Control Module & Component Mounting
CONTROL MODULE MOUNTING DO NOT Mount the control unit in the engine compartment! DO NOT Mount the control unit or wiring harness where they can become entangled with moving parts such as brake/gas/clutch pedals, or the steering column! The alarm control module should be mounted in a concealed location. The Placement of the module will affect the distance from which the remote transmitter can control the unit. -
Page 4: Wiring
WIRING GREEN WIRE: (-) DOOR TRIGGER Identify the wire that reads ground when any door is open and 12 volts when all doors are closed. Some vehicles may have isolated door triggers. In this case you may need to run additional wires from other doors or go directly to the wire that triggers the vehicle’s interior dome light. -
Page 5: Wiring
BROWN/WHITE WIRE: (-) HORN PULSE / CHIRP OUTPUT (Optional, may require a relay) Connect to the Negative Horn Trigger wire usually located near the steering column. If the vehicle horn circuit requires +12V, then a relay is required. RELAY WIRING: Connect the Brown/White wire to terminal 85, connect relay terminals 86 and 87 to +12V constant power. -
Page 6: Power Door Lock Wiring
3 PIN DOOR LOCK PLUG (Optional): GREEN: (-) Negative LOCK Pulse, RED: +12V Coil Power for relays, BLUE: (-) Negative UNLOCK Pulse NEGATIVE TRIGGER DOORLOCK WIRING GREEN BLUE REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE MASTER SWITCH POWER DOOR LOCK WIRING POSITIVE TRIGGER DOORLOCK WIRING FACTORY POWER... -
Page 7: Remote Transmitter Programming
REMOTE TRANSMITTER PROGRAMMING 1. Turn Ignition ON. 2. Press the Program/Override Button 4 times. After a few second delay, the lights should flash 4 times. 3. Press button 1 on the remote control you wish to learn. You should get 2 light flashes indicating the unit is waiting for a 2 code, then press button #1 of a second transmitter or transceiver, the unit will flash 3 times indicating its waiting for the 3... -
Page 8: Option Programming
1. Turn the Ignition ON and press the Override/Program button 5 times. After a slight delay, the system will flash the lights 5 times. 2. Within the next few seconds, press the Override/Program button [again] the number of times that corresponds to the feature list below. - Page 9 OPTION PROGRAMMING 1. HORN CHIRPS / PULSES This option controls the system’s Horn-honk output. There are 3 selections: Button 1 (Lock) = Horn Pulse only when alarm is tripped. Button 2 (Unlock) = Horn Chirps for Arm / Disarm and Pulse when tripped. Buttons (1+2) = Horn Chirps for Arm, Disarm, and Pre-warning protection.
-
Page 10: Option Programming
OPTION PROGRAMMING 8. SILENT ARMING /DISARMING (CHIRP DEFEAT) With this feature, the system can be programmed to Arm and Disarm without the siren chirp using the regular Lock/Unlock Button. Flashing parking lights will be the only Arm/Disarm confirmation. 9. PARKING LIGHTS ON WITH DISARM Keeps parking lights on instead of 2 flashes when system is disarmed to assist in locating your vehicle in a crowded parking lot or structure. -
Page 11: Active Arming
ACTIVE ARMING To arm the alarm and lock the doors, press the #1 Button (Lock/Unlock Symbol) on the transmitter. You will hear a single siren chirp and the lights will flash once. The system will arm, the doors will lock and the starter will be disabled if these optional features are installed. -
Page 12: Ignition-Controlled Door Locks
OPERATING INSTRUCTIONS SILENT ARM/DISARM THROUGH REMOTE (BUTTON #2) This system can be armed and disarmed without siren chirps on an “as needed” basis. Press and quickly release Button #2 (TRUNK) to Arm and Disarm system without chirps. NOTE: If Button #2 is pressed too long, then trunk pop may activate if optional Trunk-pop feature is connected to the system. -
Page 13: Operating Instructions
OPERATING INSTRUCTIONS PASSIVE ARMING / PASSIVE LOCK MODES / PASSIVE CHIRP COUNTDOWN If programmed, passive (Automatic) Arming will occur 30 Seconds after the ignition is turned off and the last door has been closed. The LED will begin flashing rapidly while counting down. If a door is reopened, the system will wait (LED solid) for the door or zone to close before arming. -
Page 14: Carjack Protection
CARJACK PROTECTION ACTIVE CARJACK This feature provides Active Carjack protection and must be enabled before use through Alarm programming option (14) See page 8. When the Ignition is on (running), press button #2 (Trunk Symbol). Parking lights will flash TWICE to confirm the Carjack countdown sequence. 90 Seconds later, the unit will begin a Carjack Cycle consisting of 25 seconds of pre-warning chirps turning into a full system activation with siren/flashing light pulses for up to 5 min. -
Page 15: System Wiring Diagram
(-) NEG. DOOR PIN SWITCH (+) POSITIVE DOOR PIN SWITCH GREEN (-) DOOR TRIGGER VIOLET (+) DOOR TRIGGER IGN. BLACK CHASSIS GROUND FUSE YELLOW (+) SWITCHED IGN "ON" OPT. GRAY (-) REMOTE OUTPUT 1 RELAY BLUE (-) HOOD/TRUNK TRIGGER (-) NEG. BLACK/WHITE PIN SWITCH (-) DOME LIGHT OUTPUT... -
Page 16: Online Technical Support
ONLINE TECHNICAL SUPPORT Phone (800) 998-6880 www.crimestopper.com/techweb03.html FAX (805) 581-9500 © 2003 Crimestopper Security Products...
