- Page 1 LMX2531LQ1700E Evaluation Board Operating Instructions National Semiconductor Corporation Wireless Communications, RF Products Group 2900 Semiconductor Dr. M/S A2-600 Santa Clara, CA, 95052-8090 LMX2531LQ1700EFPEB Rev 1.20.2006...
-
Page 2: Table Of Contents
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S ABLE OF ONTENTS ........................ -
Page 3: General Description
CodeLoader software included can be run on a PC to facilitate the LMX2531LQ1700E internal register programming for the evaluation and measurement. In addition to this cable assembly, there is a microwire buffer board that ensures that the proper voltage levels are provided to the microwire inputs and also this reduces digital noise from computers through the parallel port. -
Page 4: Phase Noise
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Phase Noise... -
Page 5: Phase Noise With Narrow Loop Filter (Internal Divide By 2 Disabled)
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Phase Noise with Narrow Loop Filter (Internal Divide by 2 Disabled) The plots to the left show the true phase noise capability of the... -
Page 6: Phase Noise With Narrow Loop Filter (Internal Divide By 2 Enabled)
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Phase Noise with Narrow Loop Filter (Internal Divide by 2 Enabled) The plots to the left show the true phase noise capability of the... -
Page 7: Spurs (Internal Divide By 2 Disabled)
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Spurs (Internal Divide by 2 Disabled) Spur at 200 kHz offset at a worst case frequency of 1630.2 MHz is -85.6 dBc. -
Page 8: Spurs (Internal Divide By 2 Enabled)
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Spurs (Internal Divide by 2 Enabled) Spur at 200 kHz offset at a frequency of 835.1 MHz is better than -95.5 dBc. -
Page 9: Codeloader Settings
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S CodeLoader Settings For the CodeLoader program, the default reference oscillator used for these instructions was 10 MHz, but there is a mode for a 61.44 MHz oscillator as well. - Page 10 L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S CodeLoader is set up to load the registers and initialize the part in the correct way.
-
Page 11: Schematic
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Schematic POWER VccVCO... -
Page 12: Bill Of Materials
Header POWER FCI Electronics 52601-S10-8 Metal/Plastic Header uWire Johnson Components 142-0701-851 Metal Fout, OSCin, Vcc PCB Board National Semiconductor LMX2531LQEBPCB 62 mil Thick 1st Layer 10 mils National Semiconductor LMX2531 LLP36 Silicon LMX2531 Place Across: Com Con Connectors CCIJ255G 2-Pin... -
Page 13: Top Layer
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Top Layer... -
Page 14: Mid Layer 1 "Ground Plane
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Mid Layer 1 "Ground Plane"... -
Page 15: Mid Layer 2 "Power
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Mid Layer 2 "Power"... -
Page 16: Bottom Layer "Signal
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Bottom Layer "Signal"... -
Page 17: Top Build Diagram
L M X 2 5 3 1 L Q 1 7 0 0 E E V A L U A T I O N B O A R D O P E R A T I N G I N S T R U C T I O N S Top Build Diagram... - Page 18 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
