Trim Ring Mount Kits
2 • Trim Ring Mount Kits: TMK-4L & WMKT-4L
Supplied Hardware of the TMK-4L and WMKT-4L
DESCRIPTION
Metal Plate, Mounting
(WMKT-4L only)
Metal Trim Ring
Overlay Template, Cutout
(WMKT-4L only)
The dimensions of the TMK-4L/WMKT-4L are shown below.
Dimensional Drawing
5.55 in
(14.10 cm)
2.21 in
(5.61 cm)
Crestron TMK-4L & WMKT-4L
PART NUMBER
2013242
2013241
4007975
6.75 in
(17.15 cm)
MOUNTING PLATE
(WMKT-4L only)
3.91 in
(9.93 cm)
5.88 in
(14.94 cm)
(1.27 cm)
TRIM RING
Installation Guide – DOC. 6390
QUANTITY
1
1
1
0.06 in
(0.15 cm)
3.91 in
(9.93 cm)
0.50 in
