- Page 1 Crestron SMK-12/15/17 Swivel Mount Kit Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2006 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron SMK-12/15/17 Contents Swivel Mount Kit: SMK-12/15/17 Introduction ... 1 Supplied Hardware ... 1 Installation ... 2 Further Inquiries ... 5 Future Updates... 5 Return and Warranty Policies ... 6 Merchandise Returns / Repair Service ... 6 CRESTRON Limited Warranty... 6 Installation Guide - DOC. -
Page 5: Swivel Mount Kit: Smk-12/15/17
The SMK-12/15/17 is a sturdy mounting option that provides cable management, wire strain relief, and prevents unauthorized users from disconnecting and removing the touchpanel. The opening at the rear of the SMK-12/15/17 is sized to accommodate all of the cables that would typically be connected to the touchpanel, allowing them to be hidden from view by routing them down through the mounting surface through the center opening. -
Page 6: Installation
This section provides an installation procedure for each kit. The only tools required are a suitable drill and a #3 Phillips screwdriver. To attach the SMK-12/15/17 Swivel Mount Kit to the touchpanel and install the assembly on a suitable mounting surface, refer to the following illustrations and perform the associated procedures. - Page 7 6. Place the touchpanel face down on a padded surface to prevent damage to the display screen. 7. Place the Swivel Mount Plate on the bottom of the touchpanel and attach it using the four provided #8-32 x ¼” screws.
- Page 8 8. Route the cables from the interface box up through the Security Plate, through the mounting surface, through the Swivel Mount Assembly, and then through the opening in the base of the touchpanel. Connect the cables to the appropriate touchpanel ports. Route the cables carefully to avoid chafing.
-
Page 9: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (www.crestron.com) for a listing of Crestron worldwide offices. You can also log onto the online section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 10: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures. - Page 11 Crestron SMK-12/15/17 Swivel Mount Kit This page intentionally left blank. Swivel Mount Kit: SMK-12/15/17 • 7 Installation Guide – DOC. 6467...
- Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6467 15 Volvo Drive Rockleigh, NJ 07647 (2014696) Tel: 888.CRESTRON 02.06 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
