Crestron C2N-TXM-C50 Datasheet

XM Radio Extension Cable: C2N-TXM-C50

Description

The C2N-TXM-C50 is a 50-foot indoor/outdoor extension cable for the Crestron C2N-TXM
XM Satellite Radio Tuner. Up to two extension cables may be added to the 20-foot antenna
cable supplied with the XM Tuner, for a maximum length of 120 feet. When attaching the
extension cable, insert the connector from the antenna into the rubber boot supplied with the
extension cable, plug it into the extension cable as shown, and cover the connection with the
rubber boot. Plug the other end of the extension cable into the XM Tuner XM ANT connector. If
necessary, use the same procedure to connect a second extension cable. (Refer to the
following illustration.)

Cable Specifications

Length
Cable Type
Gain
Noise Factor

Further Inquiries

If after reviewing this sheet, you cannot locate specific information or have questions, please
take advantage of Crestron's award winning customer service team by calling:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
Tel: 888.CRESTRON
Fax: 201.767.7576
50 Feet
RG-58 coaxial
0dB ±1dB @ 2.3 GHz
5dB
•
In the US and Canada, call Crestron's corporate headquarters at
1-888-CRESTRON [1-888-273-7876].
•
In Europe, call Crestron International at +32-15-50-99-50.
•
In Asia, call Crestron Asia at +852-2341-2016.
•
In Latin America, call Crestron Latin America at +5255-5093-2160.
•
In Australia and New Zealand, call Crestron Pacific at +613-9480-2999.
Current Draw
Frequency Range
Impedance
VSWR
Data Sheet – DOC. 6264
XM Radio Extension Cable: C2N-TXM-C50
Specifications subject to change without notice.
10mA, Typ.
2.3 – 2.4 GHz
50 Ω
<2:1
02.04
