- Page 1 Crestron SRD-SPL-4 Four-Way Amplified Splitter Installation Guide...
- Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON All brand names, product names and trademarks are the property of their respective owners. ©2008 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Crestron SRD-SPL-4 Contents Four-Way Amplified Splitter: SRD-SPL-4 Introduction...1 Block Diagram...2 Specifications...2 Included Items ...3 Installation ...4 Problem Solving...5 Troubleshooting...5 Further Inquiries ...6 Future Updates...6 Return and Warranty Policies ...7 Merchandise Returns / Repair Service...7 CRESTRON Limited Warranty...7 Installation Guide – DOC. 6727A Four-Way Amplified Splitter Contents •... -
Page 5: Four-Way Amplified Splitter: Srd-Spl-4
Crestron SRD-SPL-4 Four-Way Amplified Splitter: SRD-SPL-4 Introduction The SRD-SPL-4 is a high quality amplified splitter optimized to split a single antenna signal to feed up to four satellite radio tuners as part of a ® Crestron XM or SIRIUS line amplifier is rated to provide 8 dB (minimum) of gain in the satellite radio band (2320-2345 MHz), and is powered from the DC bias voltage (4.5 VDC to 6.5 VDC nominal) provided by the antenna connections on any of the satellite radio tuners downstream. -
Page 6: Block Diagram
Four-Way Amplified Splitter Block Diagram The following diagram illustrates a typical application using the SRD-SPL-4 splitter. SRD-SPL-4 Block Diagram Specifications Following are specifications for the SRD-SPL-4. SRD-SPL-4 Specifications SPECIFICATION Splitter gain @ 2.335 GHz Max noise figure Max input signal Current consumption DC power passing DC voltage drop (output to... -
Page 7: Included Items
Crestron SRD-SPL-4 SRD-SPL-4 Specifications (Continued) SPECIFICATION Humidity Overall dimensions: Height Width Depth Included Items The items included in the SRD-SPL-4 are listed and shown below. SRD-SPL-4 Included Items 4-way Splitter with Mounting Screws F-female to SMB-plug, 3 ft cables SMB-jack to F-male Adapter 20 dB Power Passing Attenuator F-male to F-male Coupler Installation Guide –... -
Page 8: Industry Compliance
Four-Way Amplified Splitter Industry Compliance As of the date of manufacture, the SRD-SPL-4 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. Installation Installation of the SRD-SPL-4 splitter consists of the following. Refer also to the “Block Diagram”... -
Page 9: Problem Solving
Crestron SRD-SPL-4 Problem Solving Troubleshooting The table after this paragraph provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. SRD-SPL-4 Installation Troubleshooting TROUBLE No signal reception. Radio display shows: “Antenna Disconnected”, or “Acquiring Signal”... -
Page 10: Further Inquiries
Four-Way Amplified Splitter SRD-SPL-4 Installation Troubleshooting (Continued) TROUBLE Limited reception or channels available for XM and/or SIRIUS tuners. Further Inquiries If you cannot locate specific information or have questions after reviewing this guide, please take advantage of Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. -
Page 11: Return And Warranty Policies
Crestron SRD-SPL-4 Return and Warranty Policies Merchandise Returns / Repair Service 1. No merchandise may be returned for credit, exchange or service without prior authorization from CRESTRON. To obtain warranty service for CRESTRON products, contact an authorized CRESTRON dealer. Only authorized CRESTRON dealers may contact the factory and request an RMA (Return Merchandise Authorization) number. - Page 12 Crestron Electronics, Inc. Installation Guide – DOC. 6727A 15 Volvo Drive Rockleigh, NJ 07647 (2021581) Tel: 888.CRESTRON 08.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
