Model: SR9600
Device Type: Surround Receiver
GENERAL INFORMATION
SIMPLWINDOWS NAME:
CATEGORY:
VERSION:
SUMMARY:
GENERAL NOTES:
CRESTRON HARDWARE REQUIRED:
SETUP OF CRESTRON HARDWARE:
VENDOR FIRMWARE:
VENDOR SETUP:
CABLE DIAGRAM:
Marantz SR9600
Receiver/Processor
V1.0
This module controls and provides true feedback for the Marantz SR9600.
This module provides control for both zones on the SR9600. It also provides true
feedback.
NOTE: IN THE PREFERENCES MENU, YOU MUST SET THE STBY MODE TO NORMAL.
IF YOU DO NOT CHANGE THIS SETTING, YOU WILL NOT BE ABLE TO TURN THE
RECEIVER ON VIA RS232.
NOTE: THIS MODULE IS FOR 2 SERIES PROCESSORS ONLY.
C2COM, ST-COM
RS232
Baud: 9600
Parity: None
Data Bits: 8
Stop Bits: 1
None
IN THE PREFERENCES MENU, YOU MUST SET THE STBY MODE TO NORMAL. IF YOU
DO NOT CHANGE THIS SETTING, YOU WILL NOT BE ABLE TO TURN THE RECEIVER
ON VIA RS232.
CNSP-123
