Speaker Installation
Spectrum
™
Connection of speakers
The IMA-840 has four channels of amplified audio, rated for a minimum 4-ohm speaker load (two 8-ohm
speakers each, connected in parallel provide 4 ohms impedance).
There are two blue phoenix style speaker connectors on the back panel, each providing two pairs of
speaker terminals. The top connector provides connection to two different channels as does the bottom
connector.
9
