Home Decorators Collection ALTURA Use And Care Manual page 8

Assembly - Hanging the Fan
1
Attaching the fan to the electrical
box
WARNING: To reduce the risk fo fire, electric shock or personal
injury, mount to outlet box marked "acceptable for fan support
of 35 lbs (15.9 kg) or less", and use screws provided with the
outlet box.
□
Pass the 120-Volt supply wires through the center hole in the
mounting bracket (A).
□
Install the ceiling mounting bracket (A) on the outlet box (MM) by
sliding the mounting bracket (A) over the two screws (LL) provided
with the outlet box (MM). If necessary, use leveling washers (not
included) between the mounting bracket (A) and the outlet box
(MM). Note that the flat side of the mounting bracket (A) is toward
the outlet box (MM).
□
Securely tighten the two mounting screws (LL).
2
Hanging the fan
□
Carefully lift the fan motor assembly (E) up to the mounting
bracket (A).
□
Seat the hanger ball portion of the ball/downrod assembly
(B) in the mounting bracket (A) socket. Ensure that the tab
on the mounting bracket (A) socket is properly seated in the
groove in the hanger ball.
8
A
B
C
HH
D
E
