Item #695 515
Model #AL14-22-BN
USE AND CARE GUIDE
BENTLEY III 22 INCH CEILING FAN
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday
1-800-986-3460
HOMEDEPOT.COM/HOMEDECORATORS
THANK YOU
THANK YOU
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection BENTLEY III AL14-22-BN
Summary of Contents for Home Decorators Collection BENTLEY III AL14-22-BN
- Page 1 USE AND CARE GUIDE BENTLEY III 22 INCH CEILING FAN Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............Disassembling Your Fan ..........Safety Information ............Operation ..............Remote Control Operating Instructions ........Warranty ................. Installing the Remote Control Holder ........Pre-Installation .............. Care and Cleaning ............Specifications ................Tools Required ................. Troubleshooting ............ -
Page 3: Safety Information
Safety Information To reduce the risk of electric shock, ensure electricity has However, there is no guarantee that interference will not occur been turned off at the circuit breaker or fuse box before in a particular installation. If this equipment does cause harmful beginning. -
Page 4: Warranty
Warranty We warrant the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser. We also warrant that all other fan parts, excluding any glass or acrylic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of two years after the date of purchase by the original purchaser. -
Page 5: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED HARDWARE INCLUDED NOTE: Hardware shown to actual size unless noted otherwise in the table below. Part Part Description Description Quantity Quantity Collar setscrew (preassembled) Plastic wire nut (not to scale) Canopy mounting bracket screw (preassembled) Remote control holder mounting screw (not to scale) Clevis pin (preassembled) Cotter pin (preassembled) Hex wrench (not to scale) -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS PACKAGE CONTENTS Part Part Description Description Quantity Quantity Part Part Description Description Quantity Quantity Mounting bracket (preassembled) Rear guard (preassembled) Canopy Blade (preassembled) Canopy bottom cover (preassembled) Front guard (preassembled) Hanger ball/downrod assembly Receiver Coupling cover Remote control Motor head (preassembled) Remote control holder... -
Page 7: Installation
Installation MOUNTING OPTIONS MOUNTING OPTIONS WARNING: To reduce the risk of fire, electric shock, or WARNING: This fan is not suitable for sloped ceilings. other personal injury, mount the fan only on an outlet box or supporting system marked acceptable for fan support of 35 lbs (15.9 kg) or less and use mounting screws provided with the outlet box. -
Page 8: Assembly
Assembly Preparing the canopy Preparing the motor □ □ Remove the canopy bottom cover (C) from the canopy Remove the clevis pin (EE), cotter pin (FF), and loosen (B) by turning the canopy bottom cover (C) counter- the two collar setscrews (AA) at the top of the motor clockwise. -
Page 9: Hanging The Fan
Assembly — Hanging the Fan Hanging the fan from the mounting Installing the mounting bracket bracket to the electrical box □ Carefully lift the fan motor head (F) up to the mount- WARNING: To reduce the risk of fire, electric shock, or ing bracket (A) and seat the hanger ball/downrod other personal injury, mount the fan only on an outlet box or assembly (D) in the mounting bracket (A) socket. - Page 10 Assembly — Hanging the Fan (continued) Preparing the receiver and remote control WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. If you feel you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician.
- Page 11 Assembly — Hanging the Fan (continued) □ If your outlet box (MM) has a ground wire (green Making the electrical connections or bare copper) connect it to the fan ground wires; otherwise connect the hanger ball/downrod assembly (D) ground wire to the mounting bracket (A). WARNING: Check to see that all connections are tight, □...
- Page 12 Assembly — Hanging the Fan (continued) Attaching the canopy bottom Installing the canopy cover to the canopy WARNING: Make sure the tab on the mounting bracket (A) NOTE: The stopper (PP) must be removed before operating properly sits in the groove in the hanger ball/downrod your fan.
-
Page 13: Disassembling Your Fan
Disassembling Your Fan This fan comes with a pre-assembled rear guard (G), blade (H), and front guard (I) for your easy installation. Check that all screws are tight and securely in place. If you need to disassemble the fan for any reason such as cleaning, follow these steps below: □... -
Page 14: Operation
Operation REMOTE CONTROL OPERATING INSTRUCTIONS REMOTE CONTROL OPERATING INSTRUCTIONS □ Install the 12V MN21/A23 battery (KK) (included) into the remote control (K). To prevent damage to the remote control (K), remove the battery if not used for long periods. □ Restore power to the ceiling fan and test for proper operation. HI , MED, LOW buttons: Sets the fan speed. -
Page 15: Care And Cleaning
Care and Cleaning Do not Do not □ Check the support connections, brackets, and blade □ Use water when cleaning. Water could damage the motor, attachments twice a year. Make sure they are secure. or the wood, or possibly cause an electrical shock. Because of the fan’s natural movement, some connections may become loose over time. -
Page 16: Service Parts
Service Parts Part Part Description Description Part Part Description Description Mounting bracket (preassembled) Collar setscrew (preassembled) Canopy Plastic wire nut Canopy bottom cover (preassembled) Canopy mounting bracket screw (preassembled) Hanger ball/downrod assembly Remote control holder mounting screw Coupling cover Clevis pin (preassembled) Motor head (preassembled) Cotter pin (preassembled) Rear guard(preassembled) - Page 17 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use. AL14-22-BN00001-A...
