- Page 1 BUILD YOUR OWN Pack 03...
- Page 2 CONTENTS Assembly Guide Stage 8: The headlight Stage 9: The brake caliper Stage 10: The front fender Editorial and design by Continuo Creative, 39-41 North Road, London N7 9DP. Published in the UK by De Agostini UK Ltd, Battersea Studios 2, 82 Silverthorne Road, London SW8 3HE.
- Page 3 Honda CB750 FOUR: Assembly Guide Stage 8 The headlight Hold the black tube housing the LED cables and gently pull the headlight LED through, as shown, while holding the two indicator cables in place. Your parts Headlight rim* Headlight retaining ring * Headlight reflector Headlight lens Front reflector bases ×...
- Page 4 Honda CB750 FOUR: Assembly Guide Pull the headlight LED cable Hold the black tube The headlight LED and its wiring should Pull the other end of the headlight LED now look like this, with the LED itself at cable to bring the LED closer to the hole in roughly a right angle to the red and the headlight case.
- Page 5 Honda CB750 FOUR: Assembly Guide Top = wide Hold the lens over the headlight case, with Gently push the reflector further into the the wide cutout at the top. case, aligning the cutout in the reflector Bottom = narrow with the corresponding projecting part of the headlight case.
- Page 6 Honda CB750 FOUR: Assembly Guide Make sure the retaining ring is properly set Align the projections on the headlight into the rim. rim with the cutouts in the headlight case (all circled). Turn the retaining ring about 1cm in a clockwise direction to lock it into position.
- Page 7 Honda CB750 FOUR: Assembly Guide Insert the pin on the rear of the mount Take one of the front reflector mounts into the hole on the recessed side of one of and check that the recessed part is clear the reflector bases. Repeat Steps 20-23 to of any dust, then hold it and the reflector assemble the second reflector.
- Page 8 Honda CB750 FOUR: Assembly Guide Stage 9 The brake caliper The pins of caliper B fit into the holes of caliper A, as shown. Your parts Caliper A Caliper B Front brake disc Screws (type N) × 2 Screws (type U) × 2 Front wheel axle nut Front wheel axle Cross wrench...
- Page 9 Honda CB750 FOUR: Assembly Guide Check that the caliper looks like this from Fit the holes in caliper A’s mounting the rear, with the circled holes aligned. bracket onto the projections on the fork. Press caliper A firmly into place, so that it is Locate the projection on the front brake flush with the fork.
- Page 10 Honda CB750 FOUR: Assembly Guide Stage 10 The front fender Threading the holes The holes L3, L4, R3 and R4, circled in blue in these photos, should be tapped prior to assembly. You should use a type C screw to tap the holes, as it has the correct diameter, and use the cross wrench received with Stage 9 to screw it in.
- Page 11 Honda CB750 FOUR: Assembly Guide Remove the brake caliper fitted in the Hold the caliper holder in position and place previous stage. a type L screw into the left-hand hole. Take the caliper holder and place it over the two circled holes on the left side of the front fender’s mounting bracket.
- Page 12 Honda CB750 FOUR: Assembly Guide Use the Allen key to tighten a type K screw Tighten a type K screw into hole R1. into the hole in the fender bracket aligned with hole L1 on the left fork. Once you have secured hole L1, tighten a type K screw into hole L2.
- Page 13 Honda CB750 FOUR: Assembly Guide Tighten a type U screw into the hole at the rear of the caliper, to secure it to the fork. Place one of the front fender stays over the rear of the fender, aligning the two projections with the two holes (arrowed).
- Page 14 Honda CB750 FOUR: Assembly Guide Align one of the holes of the rear Insert the projections of the second fender stay with the hole in the fork. stay into the holes near the front of Tighten another type C screw into Place a type C screw into the small the fender.
- Page 15 Honda CB750 FOUR: Assembly Guide Place the front wheel between the forks, carefully guiding the brake disc into the slot in the brake caliper (circled). Align the holes at the ends of the forks with the hole at the centre of the wheel hub. Insert the front wheel axle through the aligned holes.
- Page 16 Honda CB750 FOUR:...
