R-Scan Array Specifications

The table below lists specification of the R-Scan Array system.
Dimensions (w × d × h)
Weight without probe
Circumferential scanning
Maximum scan speed
Scan grid
Typical near surface resolution
Typical single line scan width
Scanner control
Encoder resolution
Delay line wedge height
Umbilical cable
A full technical specification sheet is available to download from the web address below;
R-Scan Array Specification Sheet
117 × 159 × 116 mm (4.6 × 6.2 × 4.5 in)
1.2 Kg (2.6 lbs)
100 mm (4 in) to flat plate
1 x 1 mm resolution = 220 mm/sec (Based on 40mm
range using M2M instrument)
(0.04 x 0.04 in resolution = 8.6 in/sec (at 1.5 in range))
Configurable from 1 × 1 mm (0.04 × 0.04 in)
1.5 mm (0.06 in)
61 mm (Based on 4 element aperture) (2.4 in)
Manual (On board indexing and pause/resume controls)
3.14 pts/mm (79.76 pts/In)
15mm & 30mm (0.591 In & 1.181 In)
5 m (16 ft) standard.
7.5 m (24 ft), 15 m (49 ft) and 30 m (98 ft) optional
