USER INSTRUCTIONS
INSTRUCCIONES PARA EL USUARIO
ROPE LIFELINE SYSTEM
Complies with ANSI Z359.1-2007, OSHA 1910
and 1926 regulations and requirements.
SISTEMA DE CUERDA
SALVAVIDAS TRENZADA
Cumplen con los requisitos y normas
ANSI Z359.1-2007, OSHA 1910 y 1926.
(This manual applies to all L242 series models.)
(Este manual aplica a todos los modelos serie L242.)
Werner Co. Fall Protection
93 Werner Rd.
Greenville, PA 16125
FALL PROTECTION
PROTECCIÓN CONTRA CAÍDAS
724-588-2000
888-523-3371 toll free/ llamada gratuita
888-456-8458 fax

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPGEAR L242 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Werner UPGEAR L242 Series

  • Page 1 Cumplen con los requisitos y normas ANSI Z359.1-2007, OSHA 1910 y 1926. (This manual applies to all L242 series models.) (Este manual aplica a todos los modelos serie L242.) Werner Co. Fall Protection 724-588-2000 93 Werner Rd. 888-523-3371 toll free/ llamada gratuita...
  • Page 2 CAUTION! If use of fall protection equipment is necessary then the work environment is dangerous and potentially deadly. Werner Co. products are designed to eliminate as much of the hazard only as possible but can do that ONLY if they are used correctly. Use this equipment as it...
  • Page 3: Table Of Contents

    ROPE LIFELINE SYSTEM USER INSTRUCTIONS Contents WARNINGS ......................4 I. BefoRe USING lIfelINe ................4 a. Inspect ........................4 b. Compatibility ......................6 c. Anchorage Strength ....................6 d. Clearance ........................7 e. Rescue Plan......................7 f. Training ........................7 II. PRodUCT deSCRIPTIoNS ................7 III.INSTAllATIoN ANd USe ................8 a.
  • Page 4: Warnings

    IF YOU HAVE ANY QUESTIONS ABOUT ANYTHING IN THESE INSTRUCTIONS, THE EQUIPMENT, OR PROPER USE OF THE EQUIPMENT, CONTACT WERNER CO. FOR MORE INFORMATION. I. Before Using the lifeline Before using this equipment the user should take certain steps to ensure that it is in good condition and safe for use.
  • Page 5 Warning: No alteration or modification of any fall protection equipment is permitted for any reason unless authorized in writing by Werner Co. Page 5...
  • Page 6: Compatibility

    Compatibility. Verify compatibility of all subsystems being used. Werner products connected to Werner products should be compatible, but PRoPeR CoNNeCTIoN connection to other products should be verified for compatibility to ensure there is no possibility of accidental detachment from side-loading, rollout, non-standard closures, etc.
  • Page 7: Clearance

    If a worker falls and is forced to remain suspended for any length of time, physical damage to the body or even death can result. For this reason Werner Co., OSHA, ANSI and most local regulations require that a rescue plan and the means to implement the rescue plan are in place before use of this equipment.
  • Page 8: Iii.installation And Use

    III. Installation and Use a. Connect the Snap Hook Connect the snap hook on the lanyard to ONLY to the back D-ring of the harness. Do not connect to any other part of the harness." b. Connecting to an Anchorage Connect the snap hook on the rope lifeline to the anchor Warning:...
  • Page 9: Use Warnings, Restrictions And Cautions

    (rope grab and lanyard, rope grab and carabiner) and lifeline properties. The chart to the right shows the approximate elongation for new Werner Co. lifelines in dry conditions. The lifeline Stretch elongation specified is for an length applied static load of 1,800 lbs.
  • Page 10: Fall Distance

    Maximum capacity for this product is 310 lbs (140.6 kg) for the combined weight of a worker and all tools. For any weight over 310 lbs (140.6 kg) contact Werner Co. for more information. The employer should ensure that all other elements of the fall protection system are adequate to support any higher weights.
  • Page 11: Components/Subsystems

    When working with such chemicals, frequent inspection of this equipment must be performed. Consult Werner Co. if doubt exists concerning using this equipment around chemical hazards. 3. HEAT: This equipment is not designed for use in high temperature environments.
  • Page 12 c. This manual should always accompany the product or be on file with the employer for access when needed. Record the identification details for the lanyard and record the inspections in the inspection log. It is important to keep this log current, complete, and available as needed.
  • Page 13 ROPE LIFELINE SYSTEM USER INSTRUCTIONS Shock pack Indicator label Page 13...
  • Page 14 front back Id label Page 14...
  • Page 15 ROPE LIFELINE SYSTEM USER INSTRUCTIONS Warning label front / back Page 15...
  • Page 16: Equipment Record

    SERIAL NUMBER DATE MANUFACTURED SPECIFICATIONS Werner Co. Rope lifeline System Certified to meet ANSI Z359.1-2007, OSHA 1910 and 1926 standards and regulations for the component of a complete personal fall arrest system. Individually bar coded model and serial numbers, location and date of manufacture are on product label.
  • Page 17 ROPE LIFELINE SYSTEM USER INSTRUCTIONS NoTeS Page 17...
  • Page 18 Si el uso de equipos de protección contra caídas es necesario, entonces el ambiente de trabajo es peligroso y potencialmente mortal. Los productos Werner Co. están diseñados para eliminar peligros tanto como sea posible pero SÓLO si estos productos se utilizan correctamente.
  • Page 19 SISTEMA DE CUERDA SALVAVIDAS TRENZADA INSTRUCCIONES PARA EL USUARIO Contenido AdVeRTeNCIAS ....................20 I. ANTeS de UTIlIZAR lA CUeRdA SAlVAVIdAS ......... 20 a. Inspeccione ......................20 b. Compatibilidad .......................22 c. Resistencia del anclaje ..................22 d. espacio libre ......................23 e. Plan de rescate .......................23 f.
  • Page 20: Advertencias

    SI USTED TIENE ALGUNA PREGUNTA ACERCA DE ALGO DE ESTAS INSTRUCCIONES, EL EQUIPO O EL USO APROPIADO DEL EQUIPO, COMUNÍQUESE CON WERNER CO. PARA OBTENER MÁS INFORMACIÓN. I. Antes de utilizar la cuerda salvavidas Antes de utilizar este equipo, el usuario debe realizar ciertos pasos para garantizar que éste está...
  • Page 21 Advertencia: No se permite ninguna alteración ni modificación de ningún equipo de protección contra caídas, por ningún motivo, a menos que sea autorizado por escrito por Werner Co. Página 21...
  • Page 22: Compatibilidad

    Verifique la compatibilidad de todos los subsistemas que se están utilizando. productos Werner CoNeXIÓN APRoPIAdA conectados con productos Werner son compatibles, pero la conexión con otros productos debe verificarse en cuanto a compatibilidad para garantizar que no hay posibilidad de desconexión accidental por carga lateral, rodaje, cierres no-estándares, etc.
  • Page 23: Espacio Libre

    Si un trabajador cae y queda obligado a permanecer suspendido durante cualquier período de tiempo, podría producirse daño físico o incluso la muerte. Por este motivo, Werner Co., las regulaciones de OSHA, ANSI, CSA, y la mayoría de las regulaciones locales exigen la existencia de un plan de rescate y los medios para ejecutar un plan de rescate, antes del uso de este equipo.
  • Page 24: Iii.instalación Y Uso

    III. Instalación y uso a. Conecte el gancho de cierre resortado Conecte el gancho de cierre resortado de la cuerda de sujeción SÓLO con el anillo en “D” de espalda del arnés. No conecte con ninguna otra parte del arnés". b.
  • Page 25: Tenga En Cuenta Las Advertencias, Restricciones Y Precauciones

    3 m (10 pies) 0.3 m (1 pie) Werner Co. en condiciones secas. El alargamiento especificado es para una 6.1 m (20 pies) 0.61 m (2 pies) SWING FALL HAZARD carga estática aplicada de 1.800 lbs.
  • Page 26: Distancia De Caída

    La capacidad máxima para este producto es 310 lbs (140.6 kg) para el peso combinado de un trabajador y todas las herramientas. Para cualquier peso superior a 310 lbs (140.6 kg), comuníquese con Werner Co. para obtener más información. El empleador debe garantizar que todos los otros elementos del sistema de protección contra caídas son apropiados...
  • Page 27: Componentes/Subsistemas

    Las chispas calientes podrían quemar o dañar este equipo. Consulte con Werner Co. para obtener detalles sobre los ambientes de alta temperatura. 4. PELIGROS ELÉCTRICOS: Debido a la posibilidad de flujo de corriente eléctrica a través de este equipo o los componentes conectivos, tenga...
  • Page 28 Etiqueta del indicador de impacto del paquete Página 28...
  • Page 29 SISTEMA DE CUERDA SALVAVIDAS TRENZADA INSTRUCCIONES PARA EL USUARIO parte delantera parte trasera Etiqueta de identificación Página 29...
  • Page 30 Parte delantera / trasera de etiqueta de advertencia Página 30...
  • Page 31: Registro Del Equipo

    FECHA DE FABRICACIÓN ESPECIFICACIONES Sistema de cuerda salvavidas trenzada de Werner Co. Certificado para cumplir las regulaciones y normas ANSI Z359.1-2007, OSHA 1910 y 1926 para los componentes de cuerdas de sujeción de sistemas personales completos de detención de caídas.
  • Page 32 Werner Fall Protection 93 Werner Rd. Greenville, PA 16125 • • 724-588-2000 888-523-3371 toll free 888-456-8458 fax PN105070 ©2012 Werner Co. RevA 2/13...
