3 Basket 2 Shelf Unit
Assembly Instructions -
Dimensions
Width - 54.5cm
Depth - 33cm
Height - 65cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
906/4638
MADE IN
BRITAIN
Issue 2 - 02/07/12
Advertisement
Related Manuals for Argos 906/4638
Summary of Contents for Argos 906/4638
- Page 1 3 Basket 2 Shelf Unit Assembly Instructions - 906/4638 Please keep for future reference Dimensions Width - 54.5cm Depth - 33cm MADE IN Height - 65cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 13kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below These 2 holes are on the opposite surface Left Side Right Side Divider (D1469A)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the left side Insert 4 large locking nuts into the left side Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
- Page 6 Assembly Instructions Step 4 Prepare the base Screw the 4 feet onto the base using screws Note: The feet must be fitted close to the edges of the base for maximum stability, as shown. Finished front edge Turn the base over Turn the base over Screw 6 metal dowels into the base...
- Page 7 Assembly Instructions Step 5 Note: The right side only has Join the right side and holes on the surface shown. base Push the right side onto the base Use a screwdriver to tighten the 2 large locking nuts fitted to the right side Note: Turn the large locking nuts...
- Page 8 Assembly Instructions Step 7 Fit the left side Push the left side onto the base Use a screwdriver to tighten the 2 large locking nuts fitted to the left side Finished front edge Step 8 Prepare the back Tap 4 wooden dowels into the back Note: Wooden dowels must not stick out from...
- Page 9 Assembly Instructions Step 9 1 hole Fit the back 2 holes Position the back between the left side and right side gently push in its wooden dowels Step 10 Prepare the top Screw 6 metal dowels into the top Finished front edge...
- Page 10 Assembly Instructions Step 11 Fit the top Lower the top down onto the assembly. Finished front edge Use a screwdriver to tighten the 6 large locking nuts fitted to the left side , right side and upright Step 12 Fit the shelf studs For each of the 3 shelves , insert 4 shelf...
- Page 11 Assembly Instructions Step 13 Fit the shelves Lower the 3 shelves down onto the shelf studs Finished front edge Front of unit Step 14 Secure the shelves Back of unit 2 people are needed here At the front of the unit, hold the shelves position.
- Page 12 Step 15 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2773...
