- Page 1 User manual AMP523MK2 audac.eu...
- Page 2 This manual is put together with much care, and is as complete as could be on the publication date. However, updates on the specifications, functionality or software may have occurred since publication. To obtain the latest version of both manual and software, please visit the Audac website @ www.audac.eu. AMP523MK2 - User manual...
- Page 3 AMP523MK2 Quick start guide � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �...
- Page 4 AMP523MK2 - User manual...
- Page 5 The switching between the inputs, volume regulation and other function controls can be done with the use af the AUDAC Touch™2 app. RS232 connection makes it possible to control the AMP523MK2 with any device supporting serial communi- cation such as a computer or even a home or industrial automation system.
- Page 6 Refer all servicing to qualified personnel. Opening the chassis for any reason will void the manufacturer’s warranty. Do not get the unit wet. If liquid is spilled on the unit, shut it off immediately and take it to a dealer for service. Disconnect the unit during storms to prevent damage. AMP523MK2 - User manual...
- Page 7 Please dispose this product at your local collection point or recycling centre for electrical and electronic waste. This will make sure that it will be recycled in an environmentally friendly manner, and will help to protect the environment in which we all live. AMP523MK2 - User manual...
-
Page 8: Connections And Connectors
Chapter 1 Connections and connectors CONNECTION STANDARDS The in- and output connections for AUDAC audio equipment are performed according to international wiring standards for professional audio equipment RCA (COAXIAL): Unbalanced analogue audio input connections Tip: Signal Sleeve: Ground For balanced line input connections... - Page 9 No parity No Handshaking RS232 & TCP/IP The AMP523MK2 RS232 and TCP/IP ports accept the same commands. The complete command set is available in the AMP523MK2 commands user manual which is freely available on www.audac.eu RJ45 (Audio, +24V DC) For connection to Wall Panels...
-
Page 10: Front Panel
Overview AMP523MK2 Front panel The front panel of the AMP523MK2 contains the audio in- and output connections. The available inputs are 4 stereo unbalanced line-level inputs and one balanced microphone input (with phantom power). These all are performed using an 18-pins terminal block connector (combined with the line- level audio output). - Page 11 Rear panel 4) RS232 control port: All the control and configuration ports are located on the rear panel of the AMP523MK2, including the 24 Volts power With this connector, the AMP523MK2 can be connected connection. to external control hardware using RS232. This makes it...
-
Page 12: Connecting Audio Inputs
Chapter 3 AMP523MK2 Quick start guide This chapter guides you through the setup process for a basic AMP523MK2 project where to a line level audio source and a microphone are connected directly. An external volume controller and remote wall mixer are installed remotely. -
Page 13: Connecting The Power Supply
Device settings of the AMP523MK2 in the AUDAC TOUCH™ 2 app. Ready Your system is now ready for use. Go to the main screen of the AMP523MK2 and you are in full control of all the functions. AMP523MK2 - User manual... -
Page 14: User Interface & Configuration
Chapter 4 User interface & configuration To get access to the control and configuration settings, the AMP523MK2 should be connected to a computer or an Ethernet LAN network. For more information about network connections and settings, see IP basics in chapter 6. - Page 15 AUDAC TOUCH™2 When the Audac Touch™2 app is opened, the dashboard window opens. Here control panels can be created as desired using widgets. Navigate through the menu to devices. The menu appears by clicking on the menu icon at the top left of the screen.
- Page 16 On this page all connected devices are shown. Available devices can be found by using the scan button on the right side of the screen. In this list you select the device you want to control. AMP523MK2 - User manual...
-
Page 17: Login Screen
A password should be entered to get access to the interface. Once the correct password is entered, click the “OK” button, and you will be redirected to the main screen of the AMP523MK2. (The factor y default password for the AMP523MK2 is ‘AMP523’) NOTE The password can be changed in the device menu in the app >>... -
Page 18: Mute Button
The top right corner indicates a setup button which redirects you to the general configuration menu of the AMP523MK2. Save Use the ‘Save zone settings’ button in the top right corner when made any changes to the main screen configuration. If not saved the device will start with the default/previously saved settings. AMP523MK2 - User manual... -
Page 19: Configuration Screen
The settings control panel comes up after clicking the “SETTINGS” button in the top right corner of the main screen. In this window, all settings for the AMP523MK2 can be configured, including network setttings, wall panel address settings (optional), input gain, output tone, phantom power and priority for the microphone input and password settings. - Page 20 After this is entered, push the “OK button. If the old password is correct, and the new password filled in both fields match, the old password will be changed into the new password. The factory default password is “AMP523”. AMP523MK2 - User manual...
- Page 21 BE CAREFUL It does not recall the previously saved settings, but it recalls the original factory setting and the previously made settings will be lost. Click the “OK” button to reset the settings to factory default. AMP523MK2 - User manual...
-
Page 22: Input Gain
Configuration >> Input settings This window, input settings such as input gain adjustment and phantom power enabling can be made. Network settings screen for AMP523MK2 Input gain The left side shows all input channels combined with a slider whereby the input gain can get adjusted. Default gain for every input is set to 0 dB. - Page 23 In this window, output settings such as two band tone control and switching between mono and stereo can be made. Network settings screen for AMP523MK2 Two band tone control To get the two-band tone control one must click on the icon under ‘Tone’. This will bring up a window with two faders (Bass and Treble) for the two-band tone control adjustment.
- Page 24 In the “priorities” tab, a choice is made as to which device will be prioritized. Select the edit icon next to the priority item to make adjustments. Activated priorities are indicated by a blue dot. AMP523MK2 - User manual...
-
Page 25: Input Level
For example, to make sure a priority message is always heard at the maximum volume, ... The default output level for priority messages is set to 0 dB and can be adjusted between 0 dB and -∞ dB, in steps of 1 dB. AMP523MK2 - User manual... - Page 26 Add wallpanel / All-in-one wallpanel Connect the MWX45 wall panel to the “RS485 + AUDIO” RJ45 input on the AMP523MK2. Once connected, press the ‘Add wallpanel’ button on the ‘Peripherals’ menu. The message ‘Push the upper button on the wall panel to confirm the address’...
- Page 27 Configuration >> Network settings This window allows you to adjust the network settings of the AMP523MK2. The IP address is default set to 192.168.0.193 and the subnetmask is default set to 255.255.255.0. The settings can be changed by adjusting the parameters in the shown fields.
-
Page 28: Peripheral Connections
Chapter 5 Peripheral connections In addition to the direct line and microphone inputs on the AMP523MK2, additional wall line and microphone inputs can be connected. It provides the possibility for connecting one additional wall line input unit (WLI) and one additional wall microphone input unit (WMI). For controlling the standard functions like input selection and general volume control, an additional MWX45 wall panel can get added to the system. - Page 29 AUDAC products is “192.168.000.xxx”. If your network is using a different IP range, the AUDAC products will not be accessible from your network. You can change the IP address of the AUDAC products to make them work properly in your network. This can be done in the settings menu, and is described extensively in the “Settings”...
-
Page 30: Technical Specifications
Power supply 24V DC PSD241 switching power supply included 100 ~ 240V AC / 47 63 Hz Cooling Passive Protection Over - heat Short circuit Limiter Dimensions (WxHxD) 108 x 44 x 164 mm Weight 0.4 Kg AMP523MK2 - User manual... - Page 31 Shipping weight & Volume 1.00 Kg - 0.0072 Cbm Compatible devices MWX45 Digital wall controller WLI18 Wall line input unit WMI18 Wall microphone input unit Optional Accessoiries MBS1xx Mounting brackets TR3030 100V Line Transformer 30 Watt AMP523MK2 - User manual...
